4720-00-289-5853

Preformed Hose

4720002895853 002895853 7521971 913346 913169 482F2 4720007521971

A length of nonmetallic hose, molded to a predetermined shape and size. View more Preformed Hose

Managed by United States

NSN Created on 1 Jan 1961

Data Last Changed
August 2023

NATO Update Count
21

NATO Data Quality

4720-00-289-5853 HOSE,PREFORMED 4720002895853 002895853 1/2 — 4720-00-289-5853 Photo 1/2

STYL Style C4 for 4720-00-289-5853 2/2 — NSN 4720-00-289-5853 (Identification) 2/2

Marketplace 4720-00-289-5853

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

913169 HOSE,PREFORMED 1 EA NS

Subscribe to View Vendor Details...

4720-00-289-5853 HOSE,PREFORMED 2 EA NS

Subscribe to View Vendor Details...

913346 HOSE,PREFORMED 81 EA NS

Subscribe to View Vendor Details...

913169 HOSE,PREFORMED 1 EA NS

Subscribe to View Vendor Details...

7521971 HOSE,PREFORMED 42 EA NS

Subscribe to View Vendor Details...

7521971 HOSE 1 EA NS

Subscribe to View Vendor Details...

4720-00-289-5853 HOSE RADIATOR UPPER 265 EA NS

Subscribe to View Vendor Details...

4720-00-289-5853 HOSE,PREFORMED 1 EA NS

Subscribe to View Vendor Details...

7521971 HOSE,PREFORMED 29 EA NS

Subscribe to View Vendor Details...

002895853.4720 HOSE,PREFORMED 1 EA NS

Updated Every Day

4720-00-289-5853 RQST NE

Updated Every Day

4720-00-289-5853 RQST

Updated Every Day

4720-00-289-5853 RQST NE

Related Documents 4720-00-289-5853 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-47/fsc-4720/us

4720-00-289-5853 Preformed Hose 4720002895853 002895853

7521971 913346 913169 482F2 4720007521971 A length of nonmetallic hose, molded to a predetermined shape
Details... 7521971 HOSE 1 EA NS Request Quotation Subscribe to View Vendor Details... 4720-00-289-5853
RQST NE Updated Every Day 4720-00-289-5853 RQST Updated Every Day 4720-00-289-5853 RQST NE Related

https//www.nsnlookup.com
/fsg-47/fsc-4720/us

4720-00-752-1971 Preformed Hose 4720007521971 007521971

Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 913346
4720-00-752-1971 HOSE RADIATOR UPPER 265 EA NS Request Quotation Subscribe to View Vendor Details... 7521971
Preformed Hose 4720002895853 002895853 Account Upgrade 4720-00-289-5853Preformed Hose4720002895853

https//www.nsnlookup.com
/fsg-53/fsc-5306/us

5306-00-752-1970 Machine Bolt 5306007521970 007521970,7521970

$1 a day Upgrade your Account Upgrade 5306-00-752-1970Machine Bolt5306007521970 007521970 7521970 913346
4720002895853 002895853 Account Upgrade 4720-00-289-5853Preformed Hose4720002895853 002895853 7521971
https//www.nsnlookup.com /fsg-47/fsc-4720/us 4720-00-289-5853 Preformed Hose 4720002895853 002895853

https//www.nsnlookup.com
/fsg-99/fsc-9999/dk

9999-22-606-0668 Preformed Hose 9999226060668 226060668

/fsg-47/fsc-4720/us 4720-00-993-4213 Preformed Hose 4720009934213 009934213 9999-22-607-8977 4720-00-289-5853
99992260606682260606689999-22-606-0668 is a Preformed Hose Similar Supply Items to 9999-22-606-0668 4720-00-289-5853
EDC: | ADPEC : 9999-22-606-0668 is a Preformed Hose Similar Supply Items to 9999-22-606-0668 4720-00-289-5853

https//www.nsnlookup.com
/fsg-99/fsc-9999/dk

9999-22-607-8977 Preformed Hose 9999226078977 226078977

/fsg-47/fsc-4720/us 4720-00-993-4213 Preformed Hose 4720009934213 009934213 9999-99-402-7118 4720-00-289-5853
99992260789772260789779999-22-607-8977 is a Preformed Hose Similar Supply Items to 9999-22-607-8977 4720-00-289-5853
EDC: | ADPEC : 9999-22-607-8977 is a Preformed Hose Similar Supply Items to 9999-22-607-8977 4720-00-289-5853

Restrictions 4720-00-289-5853

4720-00-289-5853 is a Preformed Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

End Users 4720-00-289-5853

US Army (A920)
Effective Date:: 1 Apr 2005
Former MOE Rule:: A181
Supplementary Receivers:: AZBD; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGC)
Effective Date:: 1 Apr 2005
Former MOE Rule:: FXAX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC40)
Effective Date:: 1 Apr 2005
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Apr 2005
Former MOE Rule:: NICD
Supplementary Collaborators:: HD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Nov 2006

Spain (YB01)
Effective Date:: 1 Apr 1991

Morocco (YP01)
Effective Date:: 1 Nov 2008

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Jul 2000

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 2005

Approved Sources 4720-00-289-5853

Part Number
Manufacturer
Status
7521971: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1
913346: 58275 - Sasco Inc Canadian Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
913169: 58275 - Sasco Inc Canadian Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
482F2: 56442 - Diamond Reo Truck Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
4720007521971: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
4720002895853: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 4720-00-289-5853

Characteristic
Specifications
FIIG: A542B0
Bend Radius [AGSJ]: 6.000 Inches Nominal
First Arm Length [CBZX]: 3.219 Inches Minimum And 3.281 Inches Maximum
Material [MATT]: Rubber Synthetic Overall
Inside Diameter [AARX]: 1.969 Inches Minimum And 2.031 Inches Maximum
Second Arm Length [CBZY]: 3.219 Inches Minimum And 3.281 Inches Maximum
Special Features [FEAT]: 1 In. Lg Of Hose Must Flex 50 Percent Of Id After 5 Hr At-65 Deg F W/O Cracking; -65 Deg F To 225 Deg F Designed Temp Range; Corrosion, Dust, Fungi, Oil And Water Resistant
Wall Thickness [AAGT]: 0.156 Inches Minimum And 0.219 Inches Maximum
Working Length [WKLG]: 9.250 Inches Minimum And 9.375 Inches Maximum
Style Designator [STYL]: Single Bend

Subscribe
View Data

DLA Procurement Analysis 4720-00-289-5853

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 4720-00-289-5853

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Feb 2020: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

Similar Supply Items to 4720-00-289-5853

Freight Information 4720-00-289-5853

4720-00-289-5853 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-289-5853 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-289-5853 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-289-5853 is not classified as a special type of cargo when transported by water. 4720-00-289-5853 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4720-00-289-5853

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 10.0" H x 4.0" W x 1.0" L; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Contracting Technical Data File (CTDF) 4720-00-289-5853 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: N

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: Y
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
