4720-00-215-7739
Air Duct Hose
4720002157739 002157739 SCAT10-480 F6X-4001-20-480 S1053K20T120-0 S1053K20T120-00 S1053K20T132-00
A flexible, tubular item of light wall construction. It must have single or multiple layers of nonmetallic material, but may contain metal wire reinforcement, foil type liner, and/or woven or braided cover. It is designed to convey under low pressure gaseous material, such as air and fumes, and light weight solid materials, such as dust, powders, and fibers. For items with couplings, see HOSE ASSEMBLY, AIR DUCT. For items of sleeve section design rated for high pressure use, see SLEEVE, SEAL, COUPLING. Excludes hose, nonmetallic. View more Air Duct Hose
August 2025
20
Marketplace 4720-00-215-7739
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-215-7739 3+ Documents (More...)
Photo 1/3 NSN 4720-00-215-7739 (Identification) 2/3 NSN 4720-00-215-7739 (Identification) 3/3 -
HOSE,AIR DUCT RQST NS Request Quotation Updated Every Day 4720-00-215-7739 RQST NE Updated Every
Air Duct Hose 4720002157739 002157739 Every Day 4720-00-215-7739 RQST NE Updated Every https//www.nsnlookup.com
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 4720-00-215-7739
Restrictions 4720-00-215-7739
4720-00-215-7739 is a Air Duct Hose that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4720-00-215-7739
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 1995
- Portugal (ZP01)
- Effective Date:
- 1 Dec 2001
- Greece (ZU01)
- Effective Date:
- 1 Mar 2006
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Aug 2007
Approved Sources 4720-00-215-7739
- Part Number
- Manufacturer
- Status
- S1053K20T132-00
- Manufacturer
- 7EK50 - Textron Aviation Inc (Active)
- Primary Buy
- Primary Buy
- S1053K20T132-00
- 71379 - Cessna Aircraft Company (Replaced)
- Original Design
- Original Design
- SCAT10-480
- 21868 - Hbd Industries, Inc (Active)
- Advisory Reference
- Advisory Reference
- F6X-4001-20-480
- 16632 - Flexfab Llc (Active)
- Advisory Reference
- Advisory Reference
- S1053K20T120-0
- 71379 - Cessna Aircraft Company (Replaced)
- Advisory Reference
- Advisory Reference
- S1053K20T120-00
- 71379 - Cessna Aircraft Company (Replaced)
- Advisory Reference
- Advisory Reference
Datasheet 4720-00-215-7739
- Characteristic
- Specifications
- FIIG
- Specifications
- A229A0
- Connection Type [AWLS]
- Plain Both Ends
- Cross-Sectional Shape Style [AAGR]
- Round
- Material [MATT]
- Fiberglass 1St Ply And Rubber Silicone Class Q 1St Ply
- Material [MATT]
- Fiberglass 2Nd Ply And Rubber Silicone Class Q 2Nd Ply
- Material [MATT]
- Steel Reinforcing Wire
- Measuring Method And Length [CRXX]
- 132.000 Inches Nominal Overall
- Minimum Inside Bending Radius [ACKH]
- 0.625 Inches
- Inside Diameter [AARX]
- 2.500 Inches Nominal First End
- Style Designator [STYL]
- Helically Wound Continous Wire Supported
Similar Supply Items to 4720-00-215-7739
Freight Information 4720-00-215-7739
4720-00-215-7739 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051035. A Sub NMFC of Z. It has a NMFC Description of DUCTS:AIR SYSTEM. 4720-00-215-7739 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33815 which rates the freight between FCL and LCL. 4720-00-215-7739 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-215-7739 is not classified as a special type of cargo when transported by water. 4720-00-215-7739 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-215-7739
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
