4720-00-115-0170
Nonmetallic Hose Assembly
4720001150170 001150170 MIL-DTL-8795 AE1000621H0194 MS28741-8-0194 360-8D0194
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
Managed by United States
NSN Created on 11 Oct 1968
Data Last Changed
July 2025
July 2025
NATO Update Count
35
35
NATO Data Quality
Marketplace 4720-00-115-0170
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
AE1000621H0194 HOSE ASSEMBLY,NONMETALLIC RQST NS
MS28741-8-0194 HOSE ASSEMBLY,NONMETALLIC RQST NS
360-8D0194 HOSE ASSEMBLY,NONMETALLIC RQST NS
4720-00-115-0170 HOSE ASSEMBLY,NONMETALLIC 100 EA NS
MS28741-8-0194 HOSE ASSEMBLY,NONMETALLIC 100 EA NS
MS28741-8-0194 RQST NE
Updated Every Day 4720-00-115-0170 RQST NE
Updated Every Day 4720-00-115-0170 RQST
Updated Every Day 4720-00-115-0170 RQST NE
Related Documents 4720-00-115-0170 5+ Documents (More...)
MIL-DTL-8795 AE1000621H0194 MS28741-8-0194 360-8D0194 A length of nonmetallic hose with fittings on
. 4720-00-115-0170 HOSE ASSEMBLY,NONMETALLIC 100 EA NS Request Quotation MS28741-8-0194 HOSE ASSEMBLY
,NONMETALLIC 100 EA NS Request Quotation Updated Every Day MS28741-8-0194 RQST NE Updated Every Day 4720
. 4720-00-115-0170 HOSE ASSEMBLY,NONMETALLIC 100 EA NS Request Quotation MS28741-8-0194 HOSE ASSEMBLY
,NONMETALLIC 100 EA NS Request Quotation Updated Every Day MS28741-8-0194 RQST NE Updated Every Day 4720
Upgrade your Account Upgrade 4720-01-385-9102Nonmetallic Hose Assembly4720013859102 013859102 MIL-DTL-8795
Nonmetallic Hose Assembly 4720001150170 Upgrade your Account Upgrade 4720-00-115-0170Nonmetallic
Hose Assembly4720001150170 001150170 MIL-DTL-8795 Nonmetallic Hose Assembly 4720013859102 Upgrade your
Nonmetallic Hose Assembly 4720001150170 Upgrade your Account Upgrade 4720-00-115-0170Nonmetallic
Hose Assembly4720001150170 001150170 MIL-DTL-8795 Nonmetallic Hose Assembly 4720013859102 Upgrade your
Upgrade your Account Upgrade 4720-00-720-0242Nonmetallic Hose Assembly4720007200242 007200242 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-435-5042Nonmetallic Hose Assembly4720014355042 014355042 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-678-5444Nonmetallic Hose Assembly4720016785444 016785444 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-435-5042Nonmetallic Hose Assembly4720014355042 014355042 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-678-5444Nonmetallic Hose Assembly4720016785444 016785444 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-053-3616Nonmetallic Hose Assembly4720010533616 010533616 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-491-6872Nonmetallic Hose Assembly4720014916872 014916872 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-004-9147Nonmetallic Hose Assembly4720010049147 010049147 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-491-6872Nonmetallic Hose Assembly4720014916872 014916872 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-004-9147Nonmetallic Hose Assembly4720010049147 010049147 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-531-5278Nonmetallic Hose Assembly4720015315278 015315278 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-053-3616Nonmetallic Hose Assembly4720010533616 010533616 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-491-6872Nonmetallic Hose Assembly4720014916872 014916872 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-053-3616Nonmetallic Hose Assembly4720010533616 010533616 MIL-DTL-8795
Upgrade your Account Upgrade 4720-01-491-6872Nonmetallic Hose Assembly4720014916872 014916872 MIL-DTL-8795
Restrictions 4720-00-115-0170
4720-00-115-0170 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4720-00-115-0170
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4720-00-115-0170
- US Army (A920)
- Effective Date:
- 1 Oct 2007
- Supplementary Receivers:
- AZ
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Oct 1998
- France (ZF01)
- Effective Date:
- 1 Oct 2007
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4720-00-115-0170
- Part Number
- Manufacturer
- Status
- MS28741-8-0194
- Manufacturer
- 96906 - Military Standards (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-8795
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MS28741-8-0194
- 7EK50 - Textron Aviation Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0194
- 00624 - Eaton Aeroquip Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0194
- 98441 - Parker Hannifin Corp (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0194
- 32142 - Hydrasearch Company, Llc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0194
- 50599 - Parker-Hannifin Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MS28741-8-0194
- 15761 - Fournier Rubber & Supply Co (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AE1000621H0194
- 00624 - Eaton Aeroquip Llc (Active)
- Secondary Buy
- Secondary Buy
- MS28741-8-0194
- 14798 - Designed Metal Connections Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS28741-8-0194
- 70898 - Beechcraft Corporation (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 360-8D0194
- 00624 - Eaton Aeroquip Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4720001150170
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4720-00-115-0170
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- Burst Test Pressure [CQBD]
- 8000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Hydrostatic Test Pressure [CRDW]
- 4000.0 Pounds Per Square Inch
- Maximum Operating Pressure [CQGM]
- 2000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 19.500 Inches Nominal Working
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 4.625 Inches
- Nominal Thread Size [CQJX]
- 0.750 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Fuel Resistant And Hydraulic Solution Resistant And Mildew Resistant And Oil Resistant
- Outside Diameter [ABKV]
- 0.766 Inches Nominal
- Inside Diameter [AARX]
- 0.406 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- 2Nd Layer Rubber Impregnated Braided Steel Wire And Outer Layer Rubber Impregnated Braided Cotton Cord And 1St Layer Rubber Impregnated Braided Cotton Cord
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Vacuum In Torr [CRSM]
- 50.8
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 250.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 3B 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Series Designator [THSD]
- Unf 1St End
- Thread Quantity Per Inch [CMLP]
- 16 1St End
Weapon Systems (WSDC) 4720-00-115-0170
DLA Procurement Analysis 4720-00-115-0170
- Last Stock Position:
- 53 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4720-00-115-0170
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- May 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Mar 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- 7
- Substitute For 4720-01-385-9102
- AAA
- 7
- Defense Logistics Agency (DS)
- I
- Dod I&S Family Master Nsn - - -
- ABA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4720-00-115-0170
Freight Information 4720-00-115-0170
4720-00-115-0170 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-115-0170 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-115-0170 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 4720-00-115-0170 is not classified as a special type of cargo when transported by water. 4720-00-115-0170 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-115-0170
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 4720-00-115-0170 2 Records
Contracting Technical Data File (CTDF) 4720-00-115-0170 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
