4720-00-070-0441
Nonmetallic Hose Assembly
4720000700441 000700441 493518 8F8MS10FJS-25
A length of nonmetallic hose with fittings on one or both ends. For items without fittings, see HOSE, NONMETALLIC. Excludes HOSE ASSEMBLY, AIR DUCT; and HOSE ASSEMBLY, AIR DUCT, AIR BREATHING. View more Nonmetallic Hose Assembly
May 2023
19
Marketplace 4720-00-070-0441
Request a Quotation from participating marketplace vendors
Related Documents 4720-00-070-0441 5+ Documents (More...)
Photo 1/3 4720-00-070-0441 Photo 2/3 NSN 4720-00-070-0441 (Identification) 3/3 - - - 1.
RQST NE Updated Every Day 4720-00-070-0441 RQST Updated Every Day 4720-00-070-0441 RQST NE Related
Restrictions 4720-00-070-0441
4720-00-070-0441 is a Nonmetallic Hose Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 4720-00-070-0441
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4720-00-070-0441
- Part Number
- Manufacturer
- Status
- 493518
- Manufacturer
- 35311 - American Standard Inc (Obsolete)
- Original Design
- Original Design
- 8F8MS10FJS-25
- 73842 - Goodyear Tire And Rubber Co The (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8F8MS10FJS-25
- 63906 - Contitech Usa, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8F8MS10FJS-25
- 70434 - Anchor Swan Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4720-00-070-0441
- Characteristic
- Specifications
- FIIG
- Specifications
- A542A0
- End Connection Design [AKUU]
- Straight 1St End
- End Connection Design [AKUU]
- Straight 2Nd End
- Burst Test Pressure [CQBD]
- 8000.0 Pounds Per Square Inch
- Connection Style [AHNC]
- Inverted Flare 2Nd End
- Connection Style [AHNC]
- Swivel Nut Flare 1St End
- Connection Type [AWLS]
- Threaded External Pipe 2Nd End
- Connection Type [AWLS]
- Threaded Internal Tube 1St End
- Cross-Sectional Shape Style [AAGR]
- Round
- Exterior Color [ADJS]
- Black
- Features Provided [CBBL]
- Reusable End Fittings
- Maximum Operating Pressure [CQGM]
- 2000.0 Pounds Per Square Inch
- Measuring Method And Length [CRXX]
- 25.000 Inches Nominal Overall
- Media For Which Designed [MEDA]
- Hydraulic Fluid, Water Base And Fuel/Oil, Hydrocarbon Single Response
- Minimum Inside Bending Radius [ACKH]
- 7.000 Inches
- Nominal Thread Size [CQJX]
- 0.500 Inches 2Nd End
- Nominal Thread Size [CQJX]
- 0.750 Inches 1St End
- Outer Covering Environmental Protection [CRJM]
- Abrasion Resistant And Weatherproof
- Outside Diameter [ABKV]
- 0.906 Inches Nominal
- Inside Diameter [AARX]
- 0.500 Inches Nominal
- Inside Surface Condition [CRWL]
- Smooth
- Layer Composition And Location [CQCS]
- Outer Layer Molded Rubber, Synthetic And 1St Layer Braided Steel Wire
- Seat Angle [CQRB]
- 30.0 Degrees 2Nd End
- Seat Angle [CQRB]
- 37.0 Degrees 1St End
- Temp Rating [ABJH]
- -40.0 Deg Fahrenheit And 200.0 Deg Fahrenheit Single Response
- Thread Class [AAJD]
- 2B 1St End
- Thread Direction [AAJF]
- Right-Hand 1St End
- Thread Direction [AAJF]
- Right-Hand 2Nd End
- Thread Series Designator [THSD]
- Nptf 2Nd End
- Thread Series Designator [THSD]
- Unf 1St End
Similar Supply Items to 4720-00-070-0441
Freight Information 4720-00-070-0441
4720-00-070-0441 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051140. A Sub NMFC of Z. It has a NMFC Description of HOSE:NOI TUBING. 4720-00-070-0441 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 52350 which rates the freight between FCL and LCL. 4720-00-070-0441 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 736 for ocean manifesting and military sealift. 4720-00-070-0441 is not classified as a special type of cargo when transported by water. 4720-00-070-0441 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4720-00-070-0441
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Special requirement – See specific instructions or drawings provided
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
