4710-01-012-4648
Metal Tube Assembly
4710010124648 010124648 11682756
A length of tubing, straight, or prebent to a predetermined angle, with added component(s) that forms an end connection on one or both ends. For flexible tube assemblies, see HOSE ASSEMBLY (as modified). For items having perforations in the tubing or attachments, see TUBE ASSEMBLY, FIRE EXTINGUISHING SYSTEM. Excludes items having integral preformed or plain ends, TUBE, BENT (as modified), and items which are branched or forked. View more Metal Tube Assembly
May 2025
31
Marketplace 4710-01-012-4648
Request a Quotation from participating marketplace vendors
Related Documents 4710-01-012-4648 1+ Documents (More...)
Photo 1/2 4710-01-012-4648 Photo 2/2 - - 1.
United States (US) 4. 4710-01-012-4648 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 4710-01-012-4648
4710-01-012-4648 is a Metal Tube Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4710-01-012-4648
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4710-01-012-4648
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Feb 1998
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 4710-01-012-4648
- Part Number
- Manufacturer
- Status
- 11682756
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 4710010124648
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 4710010124648
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 4710-01-012-4648
- Characteristic
- Specifications
- FIIG
- Specifications
- T383-D
- End Connection Style [AJFX]
- Flare First End
- End Connection Style [AJFX]
- Inverted Flare Second End
- Connection Special Design [AWPS]
- Union First End
- Connection Special Design [AWPS]
- Union Second End
- Design Form [ARJD]
- Prebent
- Material [MATT]
- Steel Corrosion Resisting And Steel Corrosion Resisting All Ends
- Mating End Quantity [AFQW]
- 1 First End
- Mating End Quantity [AFQW]
- 1 Second End
- Nominal Thread Size [CQJX]
- 0.562 Inches First End
- Nominal Thread Size [CQJX]
- 0.625 Inches Second End
- Seat Angle In Deg [AJFY]
- 45.0 Second End
- Seat Angle In Deg [AJFY]
- 45.0 First End
- Tubing Material [AHSA]
- Steel,Aisi 304
- Tube Outside Diameter [BBYQ]
- 0.250 Inches Minimum And 0.254 Inches Maximum
- Wall Thickness [AAGT]
- 0.082 Inches Minimum And 0.086 Inches Maximum
- Thread Class [AAJD]
- 2A Second End
- Thread Class [AAJD]
- 2B First End
- Thread Direction [AAJF]
- Right-Hand First End
- Thread Direction [AAJF]
- Right-Hand Second End
- Thread Series Designator [THSD]
- Unf First End
- Thread Series Designator [THSD]
- Unf Second End
Weapon Systems (WSDC) 4710-01-012-4648
DLA Procurement Analysis 4710-01-012-4648
- Last Stock Position:
- 61 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4710-01-012-4648
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2023
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 4710-01-012-4648
Freight Information 4710-01-012-4648
4710-01-012-4648 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4710-01-012-4648 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4710-01-012-4648 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4710-01-012-4648 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4710-01-012-4648 is not classified as a special type of cargo when transported by water. 4710-01-012-4648 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4710-01-012-4648
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
