4710-00-278-3281
Metallic Tube
4710002783281 002783281 SAE-AMS-T-6845 AMST6845-I-0.375X0.028 MIL-T-6845 AMS-T-6845 4710PL1398269 10169091 4710PL1379295
A straight, hollow product, welded or seamless, of round, square, or any other cross section and continuous periphery, which does not conform in cross sectional dimensions to recognized pipe standards, or those in Tables 1 through 10, Appendix C, FIIG A004A. It is designed to convey fluids, gasses, and/or semisolids. It may be rolled into coils for ease in handling. For items designed to join a tube or tube fitting to another tube, pipe, or hose or fitting, see ADAPTER (as modified); COUPLING (as modified); or NIPPLE (as modified). Excludes TUBE, BENT (as modified); PIPE, METALLIC; SPACER, SLEEVE; METAL BAR (hollow); and items with fittings, except end protectors. View more Metallic Tube
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
November 2023
November 2023
NATO Update Count
51
51
NATO Data Quality
Marketplace 4710-00-278-3281
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4710-00-278-3281 5+ Documents (More...)
https//www.nsnlookup.com
/fsg-47/fsc-4710/us
/fsg-47/fsc-4710/us
4710-00-278-3281 Metallic Tube 4710002783281 002783281,
SAE-AMS-T-6845 AMST6845-I-0.375X0.028 MIL-T-6845 AMS-T-6845 4710PL1398269 10169091 4710PL1379295 A straight
a day Upgrade your Account Upgrade 4710-00-228-3274Metallic Bent Tube4710002283274 002283274 SAE-AMS-T-6845
A straight, hollow product, welded AMST6845-I-0.625X0.065 AMS-T-6845 MILT6845 us 4710-00-278-3281
a day Upgrade your Account Upgrade 4710-00-228-3274Metallic Bent Tube4710002283274 002283274 SAE-AMS-T-6845
A straight, hollow product, welded AMST6845-I-0.625X0.065 AMS-T-6845 MILT6845 us 4710-00-278-3281
Account Upgrade 4710-00-618-7585Metallic Tube4710006187585 006187585 Cancelled - Replaced by NSN 4710-00-278-3281
MIL-T-6845 TUBE,METALLIC 102 EA NS Request Quotation Subscribe to View Vendor Details...
4710006187585006187585 United States (US) 4. 4710 https//www.nsnlookup.com /fsg-47/fsc-4710/us 4710-00-278-3281
MIL-T-6845 TUBE,METALLIC 102 EA NS Request Quotation Subscribe to View Vendor Details...
4710006187585006187585 United States (US) 4. 4710 https//www.nsnlookup.com /fsg-47/fsc-4710/us 4710-00-278-3281
AMS-T-6845 MIL-T-6845 4710PL1397917 A straight, hollow product, welded or seamless, of round, square
/fsg-47/fsc-4710/us 4710-00-278-3281 Metallic Tube 4710002783281 002783281, for $1 a day Upgrade your
Account Upgrade 4710-00-278-3281Metallic Tube4710002783281 002783281 SAE-AMS-T-6845 AMST6845-I-0.375X0.028
/fsg-47/fsc-4710/us 4710-00-278-3281 Metallic Tube 4710002783281 002783281, for $1 a day Upgrade your
Account Upgrade 4710-00-278-3281Metallic Tube4710002783281 002783281 SAE-AMS-T-6845 AMST6845-I-0.375X0.028
EDC: | ADPEC : 9540-21-870-2802 is a Metallic Tube Similar Supply Items to 9540-21-870-2802 4710-00-278-3281
EDC: | ADPEC : 9999-25-151-5717 is a Metallic Tube Similar Supply Items to 9999-25-151-5717 4710-00-278-3281
Restrictions 4710-00-278-3281
4710-00-278-3281 is a Metallic Tube that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4710-00-278-3281
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4710-00-278-3281
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- CT
- US Air Force (FXGC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NICD
- Supplementary Collaborators:
- GTKEHXHD
- Poland (WP01)
- Effective Date:
- 1 Jul 2006
- Bulgaria (WU01)
- Effective Date:
- 1 Sep 2002
- Brazil (YA01)
- Effective Date:
- 1 Jan 2011
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4710-00-278-3281
- Part Number
- Manufacturer
- Status
- SAE-AMS-T-6845
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AMST6845-I-0.375X0.028
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- MIL-T-6845
- 78821 - Td Materials Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AMS-T-6845
- 0U583 - Sae International (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-T-6845
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AMS-T-6845
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 4710PL1398269
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 10169091
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
- 4710PL1379295
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 4710-00-278-3281
- Characteristic
- Specifications
- FIIG
- Specifications
- A004A0
- End Item Identification [AGAV]
- Grumman A10 Aircraft
- Construction [CQCF]
- Seamless
- Cross-Sectional Shape Style [AAGR]
- Plain Round
- Diameter [ABMZ]
- 0.375 Inches Nominal
- First End Style [AAGZ]
- Plain
- Heat Treatment [HEAT]
- Cold Drawn 1/8 Hard Condition
- Material [MATT]
- Steel Comp 304
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch
- Maximum Operating Temp [AEHZ]
- 800.0 Deg Fahrenheit
- Measuring Method And Length [CRXX]
- 60.000 Inches Minimum Random And 240.000 Inches Maximum Random
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type
- Second End Relationship With First End [CQBB]
- Identical
- Special Features [FEAT]
- Erf694709,Fuel Transp. Stand; Aerospace Vehicle Hydraulic Systems
- Wall Thickness [AAGT]
- 0.028 Inches Nominal
- Specification/Standard Data [ZZZK]
- 81349-Mil-T-6845 Government Specification
- Surface Condition And Location [CQHT]
- Outside Polished
- Surface Treatment [SFTT]
- Passivate Inside
- Surface Treatment [SFTT]
- Passivate Outside
Weapon Systems (WSDC) 4710-00-278-3281
DLA Procurement Analysis 4710-00-278-3281
- Last Stock Position:
- 37697 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4710-00-278-3281
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- FT
- Subscribe
- FT
- Feb 2022
- Defense Logistics Agency (DS)
- FT
- Subscribe
- FT
- Oct 2021
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- Oct 2020
- Defense Logistics Agency (DS)
- FT
- Subscribe
- FT
- Feb 2020
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- 7
- Substitute For 4710-01-148-9345
- AAA
- 7
- Department of the Army (DA)
- A
- Dod I&S Family Master Nsn - - -
- ABA
- Defense Logistics Agency (DS)
- I
- 7
- Substitute For 4710-01-148-9345
- AAA
- 7
- Defense Logistics Agency (DS)
- I
- Dod I&S Family Master Nsn - - -
- ABA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 4710-00-278-3281
Freight Information 4710-00-278-3281
4710-00-278-3281 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 052190. A Sub NMFC of Z. It has a NMFC Description of PIPE,TUBING,OR PIPE OR TUBING FITTI. 4710-00-278-3281 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 30000 which rates the freight between FCL and LCL. 4710-00-278-3281 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4710-00-278-3281 is not classified as a special type of cargo when transported by water. 4710-00-278-3281 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4710-00-278-3281
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 240.0" H x 0.4" W x 0.1" L
- --
- --
- --
- Any Suitable Process
- 240.0" H x 0.4" W x 0.1" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- Vendor's Wood Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 4710-00-278-3281 11 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M422V2285
- 08 Mar 2022
- Subscribe
- 36821
- Subscribe
- Subscribe
- Subscribe
- SPE7M422V1504
- 19 Jan 2022
- Subscribe
- 10
- Subscribe
- Subscribe
- Subscribe
- SPE7M322V0634
- 03 Jan 2022
- Subscribe
- 10839
- Subscribe
- Subscribe
- Subscribe
- SPE7M319P1292
- 06 Dec 2018
- Subscribe
- 472
- Subscribe
- Subscribe
- Subscribe
- SPE7M318V6111
- 10 Sep 2018
- Subscribe
- 1300
- Subscribe
- Subscribe
- Subscribe
- SPE7M118F1A79
- 04 Jul 2018
- Subscribe
- 865
- Subscribe
- Subscribe
- Subscribe
- SPE7M118F85GC
- 31 May 2018
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE7M118F69DS
- 04 May 2018
- Subscribe
- 2281
- Subscribe
- Subscribe
- Subscribe
- SPE7M318V3136
- 20 Apr 2018
- Subscribe
- 100
- Subscribe
- Subscribe
- Subscribe
- SPE7M118F57ZM
- 19 Apr 2018
- Subscribe
- 78
- Subscribe
- Subscribe
- Subscribe
- SPE7M118F24FL
- 02 Mar 2018
- Subscribe
- 644
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4710-00-278-3281 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
