4520-01-504-8269
Air Conditioning-Heating Adapter
4520015048269 015048269 18D4432-1
A fitting, tubular at one end and other than tubular at the other end. It is used to connect two sections of air conditioning-heating pipe or to connect air conditioning-heating pipe to air conditioning-heating units. View more Air Conditioning-Heating Adapter
November 2023
2
Marketplace 4520-01-504-8269
Request a Quotation from participating marketplace vendors
Related Documents 4520-01-504-8269 2+ Documents (More...)
Updated Every Day 4520-01-504-8269 RQST NE Related Documents 4520-01-504-8269 2+ Documents ( More...
) https//www.nsnlookup.com /fsg-45/fsc-4520/us 4520-01-504-8269 Air Conditioning-Heating Adapter 015048269
Air Conditioning-Heating Adapter 015048269 Documents 4520-01-504-8269 2+ Documents ( More... https
Restrictions 4520-01-504-8269
4520-01-504-8269 is a Air Conditioning-Heating Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4520-01-504-8269
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4520-01-504-8269
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- KE
Approved Sources 4520-01-504-8269
- Part Number
- Manufacturer
- Status
- 18D4432-1
- Manufacturer
- 96916 - Fleet Readiness Center East (Active)
- Primary Buy
- Primary Buy
Datasheet 4520-01-504-8269
- Characteristic
- Specifications
- FIIG
- Specifications
- T114-A
- Elbow Opening Width [AHWQ]
- 3.000 Inches Nominal
- Adjustability Feature [AMQT]
- Not Included
- Construction Type [ADTS]
- Single
- End Item Identification [AGAV]
- 5999-01-498-0566: Interface Device Adapter Assy; 0Preader Bar
- Material [MATT]
- Aluminum Alloy
- Part Name Assigned By Controlling Agency [CXCY]
- Inlet Air Hood
- Overall Height [ABKW]
- 4.600 Inches Nominal
- Overall Length [ABHP]
- 7.240 Inches Nominal
- Overall Width [ABMK]
- 5.100 Inches Nominal
- Special Features [FEAT]
- Made From 3.000 X 0.125 Inch Wall Tube Aluminum Alloy, 6061-T6 Per Qq-A-25-/8 And 0.125 Inch Sheet Of Same Aluminum; Finished With Chromate Conversion Coating Per Mil-C-5541, Class 3, Color Irridescent Yellow; 1 Coat Of Epoxy Powder Coating, 2 Mils Thick, Color Blue, Number 15050 Per Fed-Std-595 On Exterior Surfaces And Edges Only
- Style Designator [STYL]
- Nonadjustable
- Surface Treatment [SFTT]
- Chromium
Weapon Systems (WSDC) 4520-01-504-8269
DLA Procurement Analysis 4520-01-504-8269
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4520-01-504-8269
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4520-01-504-8269
Freight Information 4520-01-504-8269
4520-01-504-8269 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 062010. A Sub NMFC of Z. It has a NMFC Description of FITTINGS CONDUIT NOI. 4520-01-504-8269 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34496 which rates the freight between FCL and LCL. 4520-01-504-8269 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72E for ocean manifesting and military sealift. 4520-01-504-8269 is not classified as a special type of cargo when transported by water. 4520-01-504-8269 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4520-01-504-8269
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Any Suitable Container
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 4520-01-504-8269 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
