4520-01-135-2770
Portable Duct Type Heater
4520011352770 011352770 PH400-D
A heater equipped with integral connection(s) for attaching duct(s) to direct heat to engine surface, railroad cars, warehouses, tents, and the like. It is equipped with a blower (fan) and must be mounted on skids, wheels, and the like or capable of being hand-carried. Excludes HEATER, SPACE. View more Portable Duct Type Heater
May 2023
14
Marketplace 4520-01-135-2770
Request a Quotation from participating marketplace vendors
Related Documents 4520-01-135-2770 5+ Documents (More...)
4520-01-135-2770 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-45/fsc-4520/us 4520-01-135-2770
Portable Duct Type Heater 4520011352770 Updated Every Day 4520-01-135-2770 RQST Updated Every Day 4520
Portable Duct Type Heater 4520011352770 Quotation Updated Every Day 4520-01-135-2770 RQST NE https
Features [FEAT]Metallic Perforated Cylinder With Perforated FlangeEnd Item Identification [AGAV] 4520-01-135-2770
; This Item Replaces Nsn 4820011018661 https//www.nsnlookup.com /fsg-45/fsc-4520/us 4520-01-135-2770
Portable Duct Type Heater 4520011352770 www.nsnlookup.com /fsg-45/fsc-4520/us 4520-00-980 https//www.nsnlookup.com
/fsg-48/fsc-4810/us
Portable Duct Type Heater 4520011352770 /fsg-48/fsc-4820/us 4820-01-101-8661 Temperature Regulating
Solenoid Valve 4810012927628 012927628 ThruSupplementary Features [SUPP]Applicable On H-1 Heater,Nsn 4520011352770
Portable Duct Type Heater 4520011352770 FlangeEnd Item Identification [AGAV] 4520-01-135-2770 https
Hydrocarbon Single ResponseOutside Diameter [ABKV]0.250 Inches NominalSpecial Features [FEAT]U/O 4520011352770
Restrictions 4520-01-135-2770
IUID Required
4520-01-135-2770 is a Portable Duct Type Heater that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Non-Critical Munitions List Item or a Non-Sensitive Commerce Control List Item and cannnot be in the possession of any party outside of the USA who is a not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4520-01-135-2770
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4520-01-135-2770
- US Air Force (FGG4)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MF5S)
- Effective Date:
- 7 Mar 2002
- Spain (YB01)
- Effective Date:
- 1 Mar 2000
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2004
Approved Sources 4520-01-135-2770
- Part Number
- Manufacturer
- Status
- PH400-D
- Manufacturer
- 92878 - Hdt Expeditionary Systems Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 4520-01-135-2770
- Characteristic
- Specifications
- FIIG
- Specifications
- A01300
- Air Circulation Device [ABBA]
- Propeller Fan
- Circulated Air Type [ABBE]
- Cooling Or Heated
- Depth [AEJZ]
- 68.500 Inches Nominal
- Fuel Feed Method [CSGC]
- Internal Pump
- Fuel Type [FUEL]
- Jp-4 Jet Fuel And Jp-5 Jet Fuel And Df-A Arctic Diesel Fuel Oil And Df-1 Winter Diesel Fuel Oil And Df-2 Regular Diesel Fuel Oil
- Functional Description [FTLD]
- Burns Dls Or Jet Fuel To Preheat Acft Engines & Fuselage Or Heat Gnd Vehicles,Maint. Bldg,Fld Shelter & Temporary Struct; Provides Forced Fresh Ventilation W/O Heating
- Heat Delivery Direction [ABAX]
- Horizontal
- Heat Delivery Rate [CQXD]
- 400000.0 British Thermal Unit
- Heat Discharge Outlet Type [ABAY]
- Stationary
- Heat Directing Device [ABAZ]
- Flexible Ducts
- Heat Outlet Quantity [ABAW]
- 1
- Heat Medium Type [ABAM]
- Air
- Heating Element Type [BDXJ]
- Combustion Chamber
- Height [HGTH]
- 44.000 Inches Nominal
- Ignition Method [BLJC]
- Electrode
- Maximum Air Flow Rate [ABBD]
- 1500.0 Cubic Feet Per Minute
- Mounting Type [AAXX]
- Trailer
- Operating Control Type [ALYC]
- Hand Switch
- Integral Fuel Tank Capacity [CRJT]
- 35.0 Gallons
- Prime Mover Type [AKDJ]
- Diesel Engine
- Quantity [NMBR]
- 1
- Reference Data And Literature [RDAL]
- To. 35E7-2-11-11
- Special Features [FEAT]
- 12 In. Duct,Or 12 In. Duct Adap Assy W/ 6 In. Duct Adap For 3,6 In. Ducts Or,12 In. Duct W/ 6 In. Duct Adap & 3,6 In. Ducts; Unsafe In Exp Atm;6 Oper Temp; May Be Used Ins Bldg When Exhaust Gasses Are Conducted To Osd Atm Via Addl Pipes Connected To The Exhaust
- Width [ABGL]
- 51.500 Inches Nominal
- Speed Adjustments [ABBB]
- Single Speed
Management Data 4520-01-135-2770
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 4520-01-310-1881
- 3
- Department of the Air Force (DF)
- L
- R
- Refer To 369-6152
- 369-6152
- R
- Department of the Air Force (DF)
- L
- R
- Refer To Alert Eu-S-84-0
- ALERT EU-S-84-0
- R
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4520-01-056-4269
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4520-01-073-8309
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4520-01-310-0691
- J
- Department of the Air Force (DF)
- L
- R
- Refer To T.O. 35-1-25
- T.O. 35-1-25
- R
Air Force
- Budget:
- M
- 57X3080 - Other Base Maintenance and Support Equipment
- Price Validation Code:
- X
- The current standard price has been validated and the previous price was erroneous.
The item was overpriced and the contractor has refunded the overcharge or DoD activities did not actually pay the previous price. The price paid is within the analyzed acceptable range.
If the difference from the previous price exceeds $99.99 or if the price change exceeds 500 percent and the extended value of any affected transaction exceeds $99.99, then reverse-post procedures will apply where the stock fund has overcharged unit O&M Funds. These corrections will be limited to the current fiscal year.
ZOP or Standard Price challenges are permissible but should be supported by adequate justification.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
NATO Stock Numbers Related to 4520-01-135-2770
Freight Information 4520-01-135-2770
4520-01-135-2770 has freight characteristics managed by the General Services Administration (GSA).It has a National Motor Freight Classification (NMFC) of 026290. A Sub NMFC of Z. It has a NMFC Description of FURNACE NOI/PARTS NOI. 4520-01-135-2770 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 42310 which rates the freight between FCL and LCL. 4520-01-135-2770 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72E for ocean manifesting and military sealift. 4520-01-135-2770 is not classified as a special type of cargo when transported by water. 4520-01-135-2770 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4520-01-135-2770
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 77.0" H x 57.5" W x 49.5" L
- --
- --
- --
- Special Requirements
- 77.0" H x 57.5" W x 49.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- No Requirement
- Not Applicable
- ASTM-D6256, Class 2, Overseas, Wood-Cleated Skidded Box
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
