4330-01-232-2061
Fluid Filter Element
4330012322061 012322061 11463994
A replaceable device designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous material (metallic or non-metallic), stacked disks, wound wire, or the like, constructed so the fluid can flow through the device while the solid particles are retained. It may be designed to fit into a FILTER, FLUID (or similar cavity), or it may have an integral outer casing and mounting facilities and be designed to connect directly to an engine, compressor, or the like. The degree of removal of particles must be nominally rated at less than 50 microns or absolutely rated at less than 75 microns. Excludes FILTER ELEMENT, AIR CONDITIONING. See also STRAINER ELEMENT, SEDIMENT. View more Fluid Filter Element
August 2025
20
Marketplace 4330-01-232-2061
Request a Quotation from participating marketplace vendors
Related Documents 4330-01-232-2061 1+ Documents (More...)
Photo 1/2 NSN 4330-01-232-2061 (Identification) 2/2 - - 1.
United States (US) 4. 4330-01-232-2061 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 4330-01-232-2061
4330-01-232-2061 is a Fluid Filter Element that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4330-01-232-2061
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4330-01-232-2061
- US Army (A920)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- BD
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Dec 2010
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 May 2008
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4330-01-232-2061
- Part Number
- Manufacturer
- Status
- 11463994
- Manufacturer
- 0GJ88 - Arben Enterprises, Inc (Active)
- Primary Buy
- Primary Buy
- 11463994
- 18876 - Us Army Aviation And Missile Command (Active)
- Primary Buy
- Primary Buy
- 11463994
- 8D457 - Industrial Filters And Equipment (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4330-01-232-2061
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Drop Pressure [ADNP]
- 10.0 Pounds Per Square Inch
- End Item Identification [AGAV]
- 1430-01-087-6330 Semitrailer Mounted Radar Set
- Body Diameter [ABPM]
- 2.710 Inches Nominal
- Body Inside Diameter [ADAS]
- 1.527 Inches Nominal
- Body Overall Length [AZTL]
- 19.540 Inches Minimum And 19.620 Inches Maximum
- Criticality Code Justification [CRTL]
- Feat
- Design Type [APGF]
- Nonreusable
- Differential Pressure [ADNQ]
- 20.0 Pounds Per Square Inch
- Filtering Media Design [CRXW]
- Porous 1St Filtering Media Response
- Filtering Media Design [CRXW]
- Woven 2Nd Filtering Media Response
- Filtering System For Which Designed [CXZX]
- Full Flow
- Flow Direction [ADNK]
- Outside In
- Material [MATT]
- Plastic Polycarbonate Container/Cartridge
- Material [MATT]
- Resin Natural Filtering Medium And Carbon Activated Filtering Medium And Nylon Filtering Medium
- Material [MATT]
- Rubber Synthetic Seal
- Media For Which Designed [MEDA]
- Water/Alcohol Mixture
- Style Designator [STYL]
- Cylindrical W/ Container (Rigid)
- Special Features [FEAT]
- Weapon System Essential
- Temp Rating [AZKQ]
- -50.0 Deg Fahrenheit Minimum And 160.0 Deg Fahrenheit Maximum
Weapon Systems (WSDC) 4330-01-232-2061
DLA Procurement Analysis 4330-01-232-2061
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4330-01-232-2061
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 4330-01-232-2061
Freight Information 4330-01-232-2061
4330-01-232-2061 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 4330-01-232-2061 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4330-01-232-2061 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 4330-01-232-2061 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4330-01-232-2061 is not classified as a special type of cargo when transported by water. 4330-01-232-2061 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4330-01-232-2061
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 22.0" H x 4.0" W x 4.0" L
- --
- --
- --
- Any Suitable Process
- 22.0" H x 4.0" W x 4.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Type I, shelf life
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 4330-01-232-2061 40 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M123P5521
- 05 May 2023
- Subscribe
- 90
- Subscribe
- Subscribe
- Subscribe
- SPE7M123V3932
- 13 Feb 2023
- Subscribe
- 84
- Subscribe
- Subscribe
- Subscribe
- SPE7M122V8319
- 01 Jun 2022
- Subscribe
- 43
- Subscribe
- Subscribe
- Subscribe
- SPE7M122V7694
- 10 May 2022
- Subscribe
- 25
- Subscribe
- Subscribe
- Subscribe
- SPE7M122V4751
- 16 Mar 2022
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE7M122V2559
- 13 Dec 2021
- Subscribe
- 11
- Subscribe
- Subscribe
- Subscribe
- SPE7M122P1979
- 03 Dec 2021
- Subscribe
- 127
- Subscribe
- Subscribe
- Subscribe
- SPE7M121P6724
- 10 Aug 2021
- Subscribe
- 150
- Subscribe
- Subscribe
- Subscribe
- SPE7M121V6972
- 21 Jul 2021
- Subscribe
- 62
- Subscribe
- Subscribe
- Subscribe
- SPE7M119V2250
- 10 Dec 2018
- Subscribe
- 61
- Subscribe
- Subscribe
- Subscribe
- SPE7M119V1183
- 31 Oct 2018
- Subscribe
- 14
- Subscribe
- Subscribe
- Subscribe
- SPE7M119V0890
- 22 Oct 2018
- Subscribe
- 29
- Subscribe
- Subscribe
- Subscribe
- SPE7M118V127Z
- 11 Sep 2018
- Subscribe
- 113
- Subscribe
- Subscribe
- Subscribe
- SPE7M118V050R
- 16 Jul 2018
- Subscribe
- 30
- Subscribe
- Subscribe
- Subscribe
- SPE7M118P5141
- 05 Jun 2018
- Subscribe
- 80
- Subscribe
- Subscribe
- Subscribe
- SPE7M118V8675
- 09 May 2018
- Subscribe
- 106
- Subscribe
- Subscribe
- Subscribe
- SPE7M118V7351
- 05 Apr 2018
- Subscribe
- 59
- Subscribe
- Subscribe
- Subscribe
- SPE7M117P7356
- 26 Jul 2017
- Subscribe
- 119
- Subscribe
- Subscribe
- Subscribe
- SPE7M017V8385
- 05 May 2017
- Subscribe
- 29
- Subscribe
- Subscribe
- Subscribe
- SPE7M117V7437
- 03 Apr 2017
- Subscribe
- 28
- Subscribe
- Subscribe
- Subscribe
- SPE7M117V6382
- 27 Feb 2017
- Subscribe
- 11
- Subscribe
- Subscribe
- Subscribe
- SPE7M117P3926
- 14 Feb 2017
- Subscribe
- 19
- Subscribe
- Subscribe
- Subscribe
- SPE7M117V5861
- 13 Feb 2017
- Subscribe
- 9
- Subscribe
- Subscribe
- Subscribe
- SPE7M117P2522
- 27 Dec 2016
- Subscribe
- 70
- Subscribe
- Subscribe
- Subscribe
- SPE7M116M5940
- 31 May 2016
- Subscribe
- 71
- Subscribe
- Subscribe
- Subscribe
- SPE7M116M4854
- 25 Apr 2016
- Subscribe
- 112
- Subscribe
- Subscribe
- Subscribe
- SPE7M916M2357
- 18 Apr 2016
- Subscribe
- 83
- Subscribe
- Subscribe
- Subscribe
- SPE7M916V2049
- 14 Mar 2016
- Subscribe
- 31
- Subscribe
- Subscribe
- Subscribe
- SPE7M916M1700
- 25 Feb 2016
- Subscribe
- 103
- Subscribe
- Subscribe
- Subscribe
- SPE7M816V0545
- 09 Feb 2016
- Subscribe
- 30
- Subscribe
- Subscribe
- Subscribe
- SPE7M116M2452
- 15 Jan 2016
- Subscribe
- 39
- Subscribe
- Subscribe
- Subscribe
- SPE7M115M5182
- 15 Apr 2015
- Subscribe
- 90
- Subscribe
- Subscribe
- Subscribe
- SPE7M115V2757
- 06 Nov 2014
- Subscribe
- 100
- Subscribe
- Subscribe
- Subscribe
- SPE7M115V0664
- 09 Oct 2014
- Subscribe
- 87
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V5297
- 29 May 2014
- Subscribe
- 75
- Subscribe
- Subscribe
- Subscribe
- SPE7M314V3978
- 27 Mar 2014
- Subscribe
- 60
- Subscribe
- Subscribe
- Subscribe
- SPE7M314M2355
- 25 Feb 2014
- Subscribe
- 52
- Subscribe
- Subscribe
- Subscribe
- SPE7M313V4053
- 04 Sep 2013
- Subscribe
- 59
- Subscribe
- Subscribe
- Subscribe
- SPE7M313V0886
- 27 Mar 2013
- Subscribe
- 53
- Subscribe
- Subscribe
- Subscribe
- SPM7M413M3956
- 11 Mar 2013
- Subscribe
- 95
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4330-01-232-2061 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
