4320-01-524-9304
Power Driven Hydraulic Pumping Unit
4320015249304 015249304 PUJ-1200E
An item consisting of power driven hydraulic pump(s) with instruments, controls and the like assembled on a common mounting. It may include engine(s) or motor(s) or be designed to be mounted on a vehicle which provides the power. It may include a hydraulic fluid reservoir, pressure fluid filters, accumulators, boosters, hose and hose reels or racks. It is used in the operation of hydraulic tools or equipment and/or checking of hydraulic systems. See also TEST STAND, HYDRAULIC SYSTEM COMPONENTS. Excludes FILLER, HYDRAULIC SYSTEM, GUIDED MISSILE. View more Power Driven Hydraulic Pumping Unit
May 2023
3
Marketplace 4320-01-524-9304
Request a Quotation from participating marketplace vendors
Related Documents 4320-01-524-9304 2+ Documents (More...)
4320-01-524-9304 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-01-524-9304
4320-01-524-9304 RQST NE Related Documents 4320-01-524-9304 1+ Documents ( More... ) https//www.nsnlookup.com
Restrictions 4320-01-524-9304
4320-01-524-9304 is a Power Driven Hydraulic Pumping Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4320-01-524-9304
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-01-524-9304
- Australia (ZA01)
- Effective Date:
- 1 Oct 2004
- United Kingdom (ZK01)
- Effective Date:
- 1 Dec 2012
Approved Sources 4320-01-524-9304
- Part Number
- Manufacturer
- Status
- PUJ-1200E
- Manufacturer
- 26952 - Enerpac Tool Group Corp (Active)
- Original Design
- Original Design
- PUJ-1200E
- Z2754 - Actuant Australia Ltd (Active)
- Secondary Buy
- Secondary Buy
- PUJ-1200E
- ZT877 - Applied Power Australia Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4320-01-524-9304
- Characteristic
- Specifications
- FIIG
- Specifications
- T103-N
- Portability [APCB]
- Portable
- Mounting Type [AAXX]
- Base
- Maximum Operating Pressure [AAJJ]
- 713.8 Kilograms Per Square Centimeter
- Pump Quantity [AENC]
- 1
- Pump Drive Type [AYJJ]
- Electric Motor
- Operation Method [APHE]
- Power
- Outlet Quantity [AYJT]
- 1
Similar Supply Items to 4320-01-524-9304
Freight Information 4320-01-524-9304
4320-01-524-9304 has freight characteristics managed by Australia.. 4320-01-524-9304 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
