4320-01-430-4376

Centrifugal Pump Unit

4320014304376 014304376 4240-158-37-256

An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation. View more Centrifugal Pump Unit

Managed by United States

NSN Created on 29 Apr 1996

Data Last Changed
May 2023

NATO Update Count
1

NATO Data Quality

4320-01-430-4376 PUMP UNIT,CENTRIFUGAL 4320014304376 014304376 1/1 — 4320-01-430-4376 Photo 1/1

Marketplace 4320-01-430-4376

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

4320-01-430-4376 RQST NE

Restrictions 4320-01-430-4376

4320-01-430-4376 is a Centrifugal Pump Unit that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item where the Item Manager, Equipment Specialist or Product Specialist must provide special demilitarization instructions. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 4320-01-430-4376

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 4320-01-430-4376

US Navy (N1HE)
Effective Date:: 1 Apr 1996
Supplementary Receivers:: GG; AMC 3 AMSC H IMC P

Approved Sources 4320-01-430-4376

Part Number
Manufacturer
Status
4240-158-37-256: 16859 - Crane Co (Obsolete); Original Design; RNCC 3 RNVC 9 DAC C

Datasheet 4320-01-430-4376

Characteristic
Specifications
FIIG: A19400
Criticality Code Justification [CRTL]: Zzzy
Reference Number Differentiating Characteristics [ZZZY]: Material Will Be In Accordance With Naval Inventory Control Point, Mechanicsburg, Activity Hx Quality Control, Manufacturing And Testing Specifications

Management Data 4320-01-430-4376

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Navy (DN); EA; Subscribe; 1
Oct 2020: Department of the Navy (DN); EA; Subscribe; 1
Oct 2019: Department of the Navy (DN); EA; Subscribe; 1

Navy

Cognizance:

1H: Consumable material assigned to NAVICP MECH for inventory management
Naval Inventory Control Point, Mechanicsburg

Special Material ID:

X5: Navy Nuclear Reactor Plant (NNRP) component level material under the technical cognizant of NAVSEA 08, but managed by NAVICP MECH. This SMIC contains all component level nuclear material not qualifying for X1 or X4 SMIC assignment.

Issue, Repair, Requisition Restriction Code:

BL: Submit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipment

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Similar Supply Items to 4320-01-430-4376

Freight Information 4320-01-430-4376

4320-01-430-4376 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 128000. A Sub NMFC of X. It has a NMFC Description of PUMPS PWR NOI/WORKING HEADS/PARTS. 4320-01-430-4376 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 4320-01-430-4376 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64870 which rates the freight between FCL and LCL. 4320-01-430-4376 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-01-430-4376 is not classified as a special type of cargo when transported by water. 4320-01-430-4376 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 4320-01-430-4376

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Heated General Purpose – Heated 40 F and above

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; Method 50

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
