4320-01-219-4322
Centrifugal Pump Unit
4320012194322 012194322 D-09N-0-98-036
An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation. View more Centrifugal Pump Unit
May 2023
5
Marketplace 4320-01-219-4322
Request a Quotation from participating marketplace vendors
Related Documents 4320-01-219-4322 2+ Documents (More...)
United States (US) 4. 4320-01-219-4322 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 4320-01-219-4322 RQST Updated Every Day 4320-01-219-4322 RQST NE Related Documents
Restrictions 4320-01-219-4322
IUID Required
4320-01-219-4322 is a Centrifugal Pump Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4320-01-219-4322
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-01-219-4322
- US Navy (N2H4)
- Effective Date:
- 1 Dec 1998
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GH
- Supplementary Receivers:
- GG
Approved Sources 4320-01-219-4322
- Part Number
- Manufacturer
- Status
- D-09N-0-98-036
- Manufacturer
- 10941 - Carver Pump Company (Active)
- Primary Buy
- Primary Buy
Datasheet 4320-01-219-4322
- Characteristic
- Specifications
- FIIG
- Specifications
- A19400
- Maximum Discharge Flow Rate [AHYV]
- 300.0 Gallons Per Minute
- Discharge Pressure [AHYW]
- 250.0 Pounds Per Square Inch Gage
- Total Head [AHYX]
- 191.700 Feet
- Operating Speed At Rated Capacity [AHYZ]
- 3565.0 Revolutions Per Minute
- Media For Which Designed [ACKL]
- Water, Salt
- Pumping Element Operating Position [AHZA]
- Horizontal
- Centrifugal Pump Design [AHZE]
- Axial Flow
- Centrifugal Pump Impeller Quantity [AHZF]
- 2
- Centrifugal Pump Impeller Suction Type [AHZG]
- Single
- Stage Quantity [AAYD]
- 2
- Pump Quantity [AENC]
- 1
- Intake Connection Quantity [AAYT]
- 1
- Intake Connection Type [AAYU]
- Round Flange
- Discharge Connection Quantity [AAYV]
- 1
- Discharge Connection Type [AAYW]
- Round Flange
- Prime Mover Type [AKDJ]
- Electric Motor
- Prime Mover Cooling Medium [AAXS]
- Air
- Prime Mover Quantity [AAXH]
- 1
- Prime Mover Power Rating [CSYL]
- 20.000 Horsepower
- Current Type [ACDC]
- Ac
- Voltage In Volts [ELEC]
- 440.0
- Frequency In Hertz [FREQ]
- 60.0
- Phase [FAAZ]
- Three
- Inclosure Type [AKNA]
- Fully Inclosed
- Cooling Method [AENK]
- Air To Air Cooled
Management Data 4320-01-219-4322
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 72316.00
- NET PRICE 72316.00
- R
Navy
- Cognizance:
- 7H
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4320-01-219-4322
Freight Information 4320-01-219-4322
4320-01-219-4322 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 128000. A Sub NMFC of X. It has a NMFC Description of PUMPS PWR NOI/WORKING HEADS/PARTS. 4320-01-219-4322 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64870 which rates the freight between FCL and LCL. 4320-01-219-4322 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-01-219-4322 is not classified as a special type of cargo when transported by water. 4320-01-219-4322 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4320-01-219-4322
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Special Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
