4320-00-913-2397
Centrifugal Pump Unit
4320009132397 009132397 28821D
An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation. View more Centrifugal Pump Unit
May 2023
6
Marketplace 4320-00-913-2397
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-913-2397 3+ Documents (More...)
Centrifugal Pump Unit 4320009132397 009132397 More... ) https//www.nsnlookup.com /cage Frederick
Restrictions 4320-00-913-2397
4320-00-913-2397 is a Centrifugal Pump Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4320-00-913-2397
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-913-2397
- US Navy (N2H4)
- Effective Date:
- 19 Jul 1999
- Former MOE Rule:
- N1H5
- Supplementary Collaborators:
- GH
- Supplementary Receivers:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Mar 2004
Approved Sources 4320-00-913-2397
- Part Number
- Manufacturer
- Status
- 28821D
- Manufacturer
- 23515 - Frederick Custom Machining Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 4320-00-913-2397
- Characteristic
- Specifications
- FIIG
- Specifications
- A19400
- Centrifugal Pump Design [AHZE]
- Radial Flow
- Centrifugal Pump Impeller Quantity [AHZF]
- 1
- Centrifugal Pump Impeller Suction Type [AHZG]
- Single
- Cooling Method [AENK]
- Self Ventilated
- Current Rating In Amps [AMPS]
- 14.0
- Current Type [ACDC]
- Ac
- Discharge Connection Quantity [AAYV]
- 1
- Discharge Connection Type [AAYW]
- Round Flange
- Environmental Protection [ADZC]
- Splashtight
- Frequency In Hertz [FREQ]
- 60.0
- Maximum Discharge Flow Rate [AHYV]
- 310.0 Gallons Per Minute
- Media For Which Designed [ACKL]
- Water, Salt
- Operating Speed At Rated Capacity [AHYZ]
- 3500.0 Revolutions Per Minute
- Inclosure Type [AKNA]
- Fully Inclosed
- Intake Connection Quantity [AAYT]
- 1
- Intake Connection Type [AAYU]
- Round Flange
- Prime Mover Cooling Medium [AAXS]
- Air
- Prime Mover Quantity [AAXH]
- 1
- Prime Mover Type [AKDJ]
- Electric Motor
- Pump Quantity [AENC]
- 1
- Pumping Element Operating Position [AHZA]
- Horizontal
- Phase [FAAZ]
- Three
- Total Head [AHYX]
- 70.000 Feet
- Voltage In Volts [ELEC]
- 440.0
- Stage Quantity [AAYD]
- 1
NATO Stock Numbers Related to 4320-00-913-2397
Freight Information 4320-00-913-2397
4320-00-913-2397 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 128000. A Sub NMFC of X. It has a NMFC Description of PUMPS PWR NOI/WORKING HEADS/PARTS. 4320-00-913-2397 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 4320-00-913-2397 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64870 which rates the freight between FCL and LCL. 4320-00-913-2397 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-913-2397 is not classified as a special type of cargo when transported by water. 4320-00-913-2397 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4320-00-913-2397
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- ASTM-D6251, Type III, Class 2, Overseas Cleated Plywood Box or ASTM-D6880, Class 2, Heavy Duty Nailed Wood Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
