4320-00-911-1835
Centrifugal Pump Impeller
4320009111835 009111835 5123183 5123622 K-5123183 TE52244 PC5123183 PC5123622
An item consisting of blades or paddles equally spaced around the periphery of a hub, rotor, or wheel. It is the rotating part of a PUMP, CENTRIFUGAL. View more Centrifugal Pump Impeller
Managed by United States
NSN Created on 29 Jun 1966
Data Last Changed
August 2025
August 2025
NATO Update Count
41
41
NATO Data Quality
Marketplace 4320-00-911-1835
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-911-1835 3+ Documents (More...)
5123183 5123622 K-5123183 TE52244 PC5123183 PC5123622 An item consisting of blades or paddles equally
RQST NE Related Documents Centrifugal Pump Impeller 4320009111835 Day 4320-00-911-1835 RQST NE Restrictions
Centrifugal Pump Impeller 4320009111835 www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
RQST NE Related Documents Centrifugal Pump Impeller 4320009111835 Day 4320-00-911-1835 RQST NE Restrictions
Centrifugal Pump Impeller 4320009111835 www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
4320-01-019-7684Centrifugal Pump Impeller4320010197684 010197684 Cancelled - Replaced by NSN 4320-00-911-1835
Documents 4320-01-019-7684 2+ Documents ( More https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
Centrifugal Pump Impeller 4320009111835 www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
Documents 4320-01-019-7684 2+ Documents ( More https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
Centrifugal Pump Impeller 4320009111835 www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
Supply Items to 4320-01-449-8624 4320-01-113-1893 https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-911-1835
Centrifugal Pump Impeller 4320009111835 379-3295 4320-00-126-3711 4320-00-398-6504 4320-00-126-
Centrifugal Pump Impeller 4320009111835 379-3295 4320-00-126-3711 4320-00-398-6504 4320-00-126-
Restrictions 4320-00-911-1835
4320-00-911-1835 is a Centrifugal Pump Impeller that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4320-00-911-1835
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-911-1835
- US Army (A920)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBF
- MOE Rule:
- BGX1
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- BAX1
- US Coast Guard (C911)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- C001
- US Air Force (FGGC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- FGAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Austria (WB01)
- Effective Date:
- 1 Aug 2006
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Jan 1998
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jun 1994
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4320-00-911-1835
- Part Number
- Manufacturer
- Status
- 5123183
- Manufacturer
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Primary Buy
- Primary Buy
- 5123622
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Secondary Buy
- Secondary Buy
- K-5123183
- 55380 - Hatch & Kirk, Inc. (Active)
- Secondary Buy
- Secondary Buy
- TE52244
- 82679 - The Technical Material Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- PC5123183
- C7432 - Power Components (Deutschland) Gmbh (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- PC5123622
- C7432 - Power Components (Deutschland) Gmbh (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- K-5123183
- 18954 - Korody-Colyer Corp A Cr Industries (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4320-00-911-1835
- Characteristic
- Specifications
- FIIG
- Specifications
- T114-C
- Blade Quantity [AJLB]
- 5
- Blade Type [ANCT]
- Backward Curve
- Design Type [APGF]
- Single Width
- Hub Length [AJLJ]
- 0.125 Inches Nominal
- Hub Location [BDJW]
- Back Side
- Hub Bore Diameter [BDDS]
- 0.656 Inches Nominal
- Hub Projection Length Beyond Wheel Side [CPWW]
- 0.188 Inches Nominal
- Hub Quantity [BLKK]
- 1
- Material [MATT]
- Copper Alloy
- Mounting Method [AXGY]
- Thread
- Rotation Direction For Which Designed [AYSY]
- Counterclockwise
- Screw Thread Series Designator [AJYP]
- Unc
- Overall Diameter [ADAV]
- 4.125 Inches Nominal
- Overall Width [ABMK]
- 1.438 Inches Nominal
- Special Features [FEAT]
- Bore Tapered To 0.469 In. Dia
- Thread Diameter [AWDP]
- 0.312 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Quantity [AZRW]
- 18 Per Inch
Weapon Systems (WSDC) 4320-00-911-1835
DLA Procurement Analysis 4320-00-911-1835
- Last Stock Position:
- 70 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4320-00-911-1835
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 2023
- US Coast Guard (GP)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Jan 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- X
- Formerly 2930
- X
- Defense Logistics Agency (DS)
- I
- X
- Formerly 2930
- X
- US Coast Guard (GP)
- C
- X
- Formerly 2930
- X
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 4320-00-911-1835
Freight Information 4320-00-911-1835
4320-00-911-1835 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 120800. A Sub NMFC of Z. It has a NMFC Description of ENGINES, INTERNAL COMBUSTION, NOI. 4320-00-911-1835 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61410 which rates the freight between FCL and LCL. 4320-00-911-1835 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-911-1835 is not classified as a special type of cargo when transported by water. 4320-00-911-1835 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4320-00-911-1835
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 5.0" H x 5.0" W x 2.0" L
- --
- --
- --
- Any Suitable Process
- 5.0" H x 5.0" W x 2.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-121, Type I, Medium Duty, Greaseproof, Waterproof Barrier
- PPP-C-1120, Class A, Water Resistant Bound Fiber
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- MIL-PRF-121, Type I, Medium Duty, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 4320-00-911-1835 1 Records
Contracting Technical Data File (CTDF) 4320-00-911-1835 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
