4320-00-398-6504
Centrifugal Pump Impeller
4320003986504 003986504 CA7988-18-1 CA7988-18
An item consisting of blades or paddles equally spaced around the periphery of a hub, rotor, or wheel. It is the rotating part of a PUMP, CENTRIFUGAL. View more Centrifugal Pump Impeller
May 2023
7
Marketplace 4320-00-398-6504
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-398-6504 4+ Documents (More...)
RQST NE Updated Every Day 4320-00-398-6504 RQST Updated Every Day 4320-00-398-6504 RQST NE Related Documents
4320-00-398-6504 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-398-6504
Centrifugal Pump Impeller 4320003986504 day Upgrade your Account Upgrade 4320-00-398-6504Centrifugal
Pump Impeller4320003986504 003986504 CA7988 -18-1 CA7988-18 An item consisting of blades or paddles
Restrictions 4320-00-398-6504
4320-00-398-6504 is a Centrifugal Pump Impeller that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4320-00-398-6504
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-398-6504
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
Approved Sources 4320-00-398-6504
- Part Number
- Manufacturer
- Status
- CA7988-18-1
- Manufacturer
- 83130 - Air & Liquid Systems Corporation (Active)
- Primary Buy
- Primary Buy
- CA7988-18
- 83130 - Air & Liquid Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4320-00-398-6504
- Characteristic
- Specifications
- FIIG
- Specifications
- T114-C
- End Item Identification [AGAV]
- Buffalo Pump Inc,Model Ca8192 Condensate Pump
- Blade Quantity [AJLB]
- 1
- Blade Type [ANCT]
- Any Acceptable
- Design Type [APGF]
- Single Width
- Hub Location [BDJW]
- Front Side
- Hub Location [BDJW]
- Single Inside Center
- Hub Location [BDJW]
- Back Side
- Hub Bore Diameter [BDDS]
- 1.129 Inches Nominal
- Hub Bore Diameter [BDDS]
- 5.000 Inches Nominal
- Hub Bore Diameter [BDDS]
- 5.562 Inches Nominal
- Hub Projection Length Beyond Wheel Side [CPWW]
- 0.562 Inches Nominal
- Hub Projection Length Beyond Wheel Side [CPWW]
- 0.625 Inches Nominal
- Hub Quantity [BLKK]
- 3
- Mounting Method [AXGY]
- Key And Thread
- Keyway Depth [ABRV]
- 2.000 Inches Nominal
- Keyway Length [AFYS]
- 0.188 Inches Nominal
- Keyway Quantity [AEVE]
- 1
- Keyway Type [CPWX]
- Rectangular
- Keyway Width [ABRR]
- 0.105 Inches Nominal
- Rotation Direction For Which Designed [AYSY]
- Counterclockwise
- Screw Thread Series Designator [AJYP]
- Unc
- Overall Diameter [ADAV]
- 9.500 Inches Nominal
- Overall Width [ABMK]
- 3.125 Inches Nominal
- Special Features [FEAT]
- First Stage,Includes P/N Ca5870-28 Wearing Ring 1,P/N Ca5870-29 Wearing Ring 1 And Sutds
- Thread Quantity [AZRW]
- 11 Per Inch
- Thread Diameter [AWDP]
- 0.625 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
Weapon Systems (WSDC) 4320-00-398-6504
DLA Procurement Analysis 4320-00-398-6504
Management Data 4320-00-398-6504
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4320-00-398-6504
Freight Information 4320-00-398-6504
4320-00-398-6504 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 120800. A Sub NMFC of Z. It has a NMFC Description of ENGINES, INTERNAL COMBUSTION, NOI. 4320-00-398-6504 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61410 which rates the freight between FCL and LCL. 4320-00-398-6504 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-398-6504 is not classified as a special type of cargo when transported by water. 4320-00-398-6504 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
