4320-00-368-3186
Centrifugal Pump Unit
4320003683186 003683186 576139 777H440 777H
An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation. View more Centrifugal Pump Unit
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
May 2023
May 2023
NATO Update Count
36
36
NATO Data Quality
Marketplace 4320-00-368-3186
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-368-3186 5+ Documents (More...)
576139 777H440 777H An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover
United States (US) 4. 4320-00-368-3186 Marketplace Restrictions Approved Sources Datasheet Management
Day 4320-00-368-3186 RQST Updated Every Day 4320-00-368-3186 RQST NE Related Documents 4320-00-368-3186
United States (US) 4. 4320-00-368-3186 Marketplace Restrictions Approved Sources Datasheet Management
Day 4320-00-368-3186 RQST Updated Every Day 4320-00-368-3186 RQST NE Related Documents 4320-00-368-3186
enable JavaScript in your web browser . 4320-21-003-7629Centrifugal Pump Unit4320210037629 210037629 777H
www.nsnlookup.com /fsg-43/fsc-4320/ca 4320-21-003-7629 Centrifugal Pump Unit 4320210037629210037629 777H
https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-368-3186 Centrifugal Pump Unit 4320003683186 003683186
www.nsnlookup.com /fsg-43/fsc-4320/ca 4320-21-003-7629 Centrifugal Pump Unit 4320210037629210037629 777H
https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-368-3186 Centrifugal Pump Unit 4320003683186 003683186
to enable JavaScript in your web browser . 2540-33-107-1852Vehicular Seat2540331071852 331071852 576139
www.nsnlookup.com /fsg-25/fsc-2540/es 2540-33-107-1852 Vehicular Seat 2540331071852 331071852,576139 576139
to enable JavaScript in your web browser . 3040-33-153-8899Shouldered Shaft3040331538899 331538899 576139
www.nsnlookup.com /fsg-25/fsc-2540/es 2540-33-107-1852 Vehicular Seat 2540331071852 331071852,576139 576139
to enable JavaScript in your web browser . 3040-33-153-8899Shouldered Shaft3040331538899 331538899 576139
to enable JavaScript in your web browser . 3040-33-153-8899Shouldered Shaft3040331538899 331538899 576139
to enable JavaScript in your web browser . 2540-33-107-1852Vehicular Seat2540331071852 331071852 576139
Centrifugal Pump Unit 4320003683186 003683186 $1 a day Upgrade your Account Upgrade 4320-00-368
to enable JavaScript in your web browser . 2540-33-107-1852Vehicular Seat2540331071852 331071852 576139
Centrifugal Pump Unit 4320003683186 003683186 $1 a day Upgrade your Account Upgrade 4320-00-368
how to enable JavaScript in your web browser . 7430-37-518-3740Typewriter7430375183740 375183740 OMC-777H
https//www.nsnlookup.com /fsg-74/fsc-7430/kr 7430-37-518-3740 Typewriter 7430375183740375183740,OMC-777H
fsc-7430/kr 7430-37-517-8333 Computer Inspectio 7430375178333 375178333 7430375183740375183740,OMC-777H
https//www.nsnlookup.com /fsg-74/fsc-7430/kr 7430-37-518-3740 Typewriter 7430375183740375183740,OMC-777H
fsc-7430/kr 7430-37-517-8333 Computer Inspectio 7430375178333 375178333 7430375183740375183740,OMC-777H
Restrictions 4320-00-368-3186
IUID Required
4320-00-368-3186 is a Centrifugal Pump Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4320-00-368-3186
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-368-3186
- US Army (A211)
- Effective Date:
- 1 Jun 2014
- US Coast Guard (C184)
- Effective Date:
- 1 Jul 2010
- Former MOE Rule:
- C183
- US Navy (N2H4)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- HX
- Poland (WP01)
- Effective Date:
- 1 Mar 2005
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Malaysia (YW01)
- Effective Date:
- 1 Jun 1996
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Jun 2008
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Nov 1994
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4320-00-368-3186
- Part Number
- Manufacturer
- Status
- 576139
- Manufacturer
- 83590 - Smith Meter Inc Parts Opn (Active)
- Primary Buy
- Primary Buy
- 777H440
- 4T958 - R P M Supply Corporation (Active)
- Secondary Buy
- Secondary Buy
- 777H
- 83590 - Smith Meter Inc Parts Opn (Active)
- Secondary Buy
- Secondary Buy
- 777H440
- 96046 - Crane Pumps & Systems Pft Corp (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4320-00-368-3186
- Characteristic
- Specifications
- FIIG
- Specifications
- A19400
- Centrifugal Pump Impeller Quantity [AHZF]
- 1
- Centrifugal Pump Impeller Suction Type [AHZG]
- Single
- Centrifugal Pump Design [AHZE]
- Radial Flow
- Cooling Method [AENK]
- Self Ventilated
- Current Rating In Amps [AMPS]
- 7.5
- Current Type [ACDC]
- Ac
- Discharge Connection Quantity [AAYV]
- 1
- Discharge Connection Thread Size And Series/Type Designator [ASAZ]
- 2.500-7 1/2 Nh
- Discharge Connection Type [AAYW]
- Threaded Internal
- Environmental Protection [ADZC]
- Submersible
- Frequency In Hertz [FREQ]
- 60.0
- Maximum Discharge Flow Rate [AHYV]
- 180.0 Gallons Per Minute
- Media For Which Designed [ACKL]
- Water, Salt
- Operating Speed At Rated Capacity [AHYZ]
- 3450.0 Revolutions Per Minute
- Inclosure Type [AKNA]
- Fully Inclosed
- Intake Connection Quantity [AAYT]
- 1
- Intake Connection Thread Size And Series/Type Designator [ASWT]
- 2.500-7 1/2 Nh
- Intake Connection Type [AAYU]
- Threaded Internal
- Prime Mover Cooling Medium [AAXS]
- Air
- Prime Mover Quantity [AAXH]
- 1
- Prime Mover Type [AKDJ]
- Electric Motor
- Pump Quantity [AENC]
- 1
- Pumping Element Operating Position [AHZA]
- Vertical
- Phase [FAAZ]
- Three
- Special Features [FEAT]
- Controller Has Magnetic Casing,Unit Will Operate In Horizontalor Any Midway Position
- Voltage In Volts [ELEC]
- 440.0
- Stage Quantity [AAYD]
- 1
- Total Head [AHYX]
- 50.000 Feet
Management Data 4320-00-368-3186
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 16821.00
- NET PRICE 16821.00
- R
- US Coast Guard (GP)
- C
- R
- Refer To Net Price 16821.00
- NET PRICE 16821.00
- R
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- WA
- Line of Communication and Base Support Systems
Port Support and Watercraft Equipment
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 7H
- Issue, Repair, Requisition Restriction Code:
- BL
- Submit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipment
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4320-00-368-3186
Freight Information 4320-00-368-3186
4320-00-368-3186 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 128000. A Sub NMFC of X. It has a NMFC Description of PUMPS PWR NOI/WORKING HEADS/PARTS. 4320-00-368-3186 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 4320-00-368-3186 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64870 which rates the freight between FCL and LCL. 4320-00-368-3186 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-368-3186 is not classified as a special type of cargo when transported by water. 4320-00-368-3186 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4320-00-368-3186
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 40.0" H x 15.0" W x 13.0" L
- --
- --
- --
- Special Requirements
- 40.0" H x 15.0" W x 13.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- ASTM-D6251, Type III, Class 2, Overseas Cleated Plywood Box or ASTM-D6880, Class 2, Heavy Duty Nailed Wood Box
- Open for inspection or use only
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
