4320-00-269-0885
Centrifugal Pump Unit
4320002690885 002690885 SL4681
An assembled unit consisting of a commonly mounted centrifugal pump(s), prime mover(s), and the necessary components to provide for a complete operation. View more Centrifugal Pump Unit
May 2023
5
Marketplace 4320-00-269-0885
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-269-0885 2+ Documents (More...)
United States (US) 4. 4320-00-269-0885 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 4320-00-269-0885 RQST Updated Every Day 4320-00-269-0885 RQST NE Related Documents
Restrictions 4320-00-269-0885
4320-00-269-0885 is a Centrifugal Pump Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4320-00-269-0885
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-269-0885
- National Security Agency (DGX1)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- DAX1
- Supplementary Receivers:
- AX
Approved Sources 4320-00-269-0885
- Part Number
- Manufacturer
- Status
- SL4681
- Manufacturer
- 0UBG9 - Curtiss-Wright Electro-Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- SL4681
- 93232 - Curtiss-Wright Electro-Mechanical (Replaced)
- Original Design
- Original Design
Datasheet 4320-00-269-0885
- Characteristic
- Specifications
- FIIG
- Specifications
- A19400
- Centrifugal Pump Design [AHZE]
- Radial Flow
- Centrifugal Pump Impeller Quantity [AHZF]
- 1
- Centrifugal Pump Impeller Suction Type [AHZG]
- Double
- Cooling Method [AENK]
- Self Ventilated
- Current Rating In Amps [AMPS]
- 38.0
- Current Type [ACDC]
- Dc
- Discharge Connection Quantity [AAYV]
- 1
- Discharge Connection Type [AAYW]
- Round Flange
- Environmental Protection [ADZC]
- Dripproof
- Maximum Discharge Flow Rate [AHYV]
- 1175.0 Gallons Per Minute
- Media For Which Designed [ACKL]
- Water, Salt
- Operating Speed At Rated Capacity [AHYZ]
- 1150.0 Revolutions Per Minute
- Inclosure Type [AKNA]
- Partially Inclosed
- Intake Connection Type [AAYU]
- Round Flange
- Intake Connection Quantity [AAYT]
- 1
- Prime Mover Quantity [AAXH]
- 1
- Prime Mover Type [AKDJ]
- Electric Motor
- Prime Mover Cooling Medium [AAXS]
- Air
- Pump Quantity [AENC]
- 1
- Pumping Element Operating Position [AHZA]
- Vertical
- Reference Number Differentiating Characteristics [ZZZY]
- With 230 V Dc Motor And Controller
- Voltage In Volts [ELEC]
- 230.0
- Stage Quantity [AAYD]
- 1
- Total Head [AHYX]
- 22.000 Feet
DLA Procurement Analysis 4320-00-269-0885
Management Data 4320-00-269-0885
Similar Supply Items to 4320-00-269-0885
Freight Information 4320-00-269-0885
4320-00-269-0885 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 128000. A Sub NMFC of X. It has a NMFC Description of PUMPS PWR NOI/WORKING HEADS/PARTS. 4320-00-269-0885 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 4320-00-269-0885 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64870 which rates the freight between FCL and LCL. 4320-00-269-0885 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-269-0885 is not classified as a special type of cargo when transported by water. 4320-00-269-0885 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 4320-00-269-0885 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
