4320-00-115-4060
Centrifugal Pump Impeller
4320001154060 001154060 A1205-793
An item consisting of blades or paddles equally spaced around the periphery of a hub, rotor, or wheel. It is the rotating part of a PUMP, CENTRIFUGAL. View more Centrifugal Pump Impeller
May 2023
6
Marketplace 4320-00-115-4060
Request a Quotation from participating marketplace vendors
Related Documents 4320-00-115-4060 2+ Documents (More...)
RQST NE Updated Every Day 4320-00-115-4060 RQST Updated Every Day 4320-00-115-4060 RQST NE Related Documents
4320-00-115-4060 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-43/fsc-4320/us 4320-00-115-4060
Restrictions 4320-00-115-4060
4320-00-115-4060 is a Centrifugal Pump Impeller that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4320-00-115-4060
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4320-00-115-4060
- US Navy (N9BC)
- Effective Date:
- 1 Apr 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4320-00-115-4060
- Part Number
- Manufacturer
- Status
- A1205-793
- Manufacturer
- 64392 - Weil Pump Co Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 4320-00-115-4060
- Characteristic
- Specifications
- FIIG
- Specifications
- T114-C
- Blade Quantity [AJLB]
- 5
- Blade Type [ANCT]
- Forward Curve
- Design Type [APGF]
- Single Width
- Hub Location [BDJW]
- Front Side
- Hub Location [BDJW]
- Back Side
- Hub Bore Diameter [BDDS]
- 1.000 Inches Nominal
- Hub Bore Diameter [BDDS]
- 2.250 Inches Nominal
- Hub Length [AJLJ]
- 0.562 Inches Nominal
- Hub Length [AJLJ]
- 1.000 Inches Nominal
- Hub Projection Length Beyond Wheel Side [CPWW]
- 1.000 Inches Nominal
- Hub Quantity [BLKK]
- 2
- Material [MATT]
- Copper Alloy
- Mounting Method [AXGY]
- Key
- Keyway Length [AFYS]
- 1.719 Inches Nominal
- Keyway Quantity [AEVE]
- 1
- Keyway Type [CPWX]
- Rectangular
- Keyway Width [ABRR]
- 0.250 Inches Nominal
- Keyway Depth [ABRV]
- 0.125 Inches Nominal
- Rotation Direction For Which Designed [AYSY]
- Clockwise
- Overall Diameter [ADAV]
- 8.000 Inches Nominal
- Overall Width [ABMK]
- 2.750 Inches Nominal
DLA Procurement Analysis 4320-00-115-4060
Management Data 4320-00-115-4060
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4320-00-115-4060
Freight Information 4320-00-115-4060
4320-00-115-4060 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 120800. A Sub NMFC of Z. It has a NMFC Description of ENGINES, INTERNAL COMBUSTION, NOI. 4320-00-115-4060 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61410 which rates the freight between FCL and LCL. 4320-00-115-4060 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4320-00-115-4060 is not classified as a special type of cargo when transported by water. 4320-00-115-4060 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4320-00-115-4060
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 4320-00-115-4060 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
