4310-01-198-9365
Reciprocating Compressor Unit
4310011989365 011989365 E71 10HT8G
An assembled unit consisting of a commonly mounted reciprocating compressor(s) and a prime mover(s). For items with additional equipment which extends the function of the unit beyond the delivery of compressed air or gas, see PNEUMATIC TOOL AND COMPRESSOR OUTFIT, or more specific names, as applicable. Excludes AUXILIARY SET, ENGINE DRIVEN. View more Reciprocating Compressor Unit
May 2023
4
Marketplace 4310-01-198-9365
Request a Quotation from participating marketplace vendors
Related Documents 4310-01-198-9365 5+ Documents (More...)
E71 COMPRESSOR UNIT,RECIPROCATING 19 EA NS Request Quotation Updated Every Day 4310-01-198-9365 RQST
NE Updated Every Day 4310-01-198-9365 RQST Updated Every Day 4310-01-198-9365 RQST NE Related Documents
/fsg-59/fsc-5945/us
Reciprocating Compressor Unit 4310011989365 Day 4310-01-198-9365 RQST NE Related Documents https
Relay 5945012267505012267505 Quality NSN 5945-01-226-7505 (Generic Image) 1/1 1. https Every Day 4310-01-198-9365
Reciprocating Compressor Unit 4310011989365 CharacteristicSpecificationsFIIGA23900End Item Identification
[AGAV] 4310-01-198-9365 https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-225-8254 Check Valve 4820012258254012258254
Reciprocating Compressor Unit 4310011989365 Request Quotation Subscribe to View Vendor Details.
https//www.nsnlookup.com CharacteristicSpecificationsFIIGA530B0End Item Identification [AGAV] 4310-01-198-9365
Restrictions 4310-01-198-9365
4310-01-198-9365 is a Reciprocating Compressor Unit Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4310-01-198-9365
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4310-01-198-9365
- US Army (A402)
- Effective Date:
- 1 Oct 1997
- Former MOE Rule:
- A002
- Supplementary Receivers:
- AJAZ
Approved Sources 4310-01-198-9365
- Part Number
- Manufacturer
- Status
- E71
- Manufacturer
- 55921 - Curtis-Toledo Inc. (Active)
- Primary Buy
- Primary Buy
- 10HT8G
- 55921 - Curtis-Toledo Inc. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 4310-01-198-9365
- Characteristic
- Specifications
- FIIG
- Specifications
- A026A0
- Duty Cycle In Percent [AAXJ]
- 100
- Brake Power Required [CXNT]
- 10.0 Horsepower
- Compressed Gas Cooling Medium [AAXQ]
- Air
- Compressor Cooling Medium [AAXR]
- Air
- Compressor Speed At Rated Capacity In Rpm [AAYS]
- 925.0
- Cooling System Design [AAXP]
- Single
- Control Device Type [BDML]
- Automatic Start-Stop
- Cylinder Arrangement Style [AAYA]
- "W" Design
- Cylinder Quantity [AAXZ]
- 3
- Current Type And Rating In Amps [CQJY]
- 28.0 Ac
- Discharge Flow Rate [AAXL]
- 25.000 Cubic Feet Per Minute
- Discharge Pressure [AAXM]
- 175.000 Pounds Per Square Inch Gage
- Gas Cooling Equipment Type [AAXU]
- Air Type Intercooler
- Gas For Which Designed [AAXK]
- Air
- Features Provided [CBBL]
- Fungus Resistant Treatment
- Frequency In Hertz [FREQ]
- 60.0
- Compressor Quantity [AAXG]
- 1
- Mounting Type [AAXX]
- Horizontal Tank
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class And 25Cfm At 175Psi Size
- Intake Connection Quantity [AAYT]
- 1
- Prime Mover Cooling Medium [AAXS]
- Air
- Prime Mover Type [AKDJ]
- Electric Motor
- Reciprocating Compressor Design [AAXY]
- Single Acting
- Receiver Tank Capacity [AAYR]
- 10.70 Cubic Feet
- Safety Device Type [BPRZ]
- Relief Valve
- Silencer Type [AAZA]
- Inlet
- Phase [FAAZ]
- Three
- Unloader Type [AAXV]
- Automatic
- Voltage In Volts And Current Type [CSBH]
- 230.0 Ac
- Stage Quantity [AAYD]
- 2
Management Data 4310-01-198-9365
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Sep 2012
- Department of the Army (DA)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- M
- Ammunition weapons, and tracked combat vehicles weapons, special weapons, chemical and fire control materiel
- Appropriation and Budget Activity:
- Q
- Other Support Equipment
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- L5
- Other Weapons Categories
Other Managed Component of Tool Set
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Similar Supply Items to 4310-01-198-9365
Freight Information 4310-01-198-9365
4310-01-198-9365 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 118100. A Sub NMFC of Z. It has a NMFC Description of COMPRESSORS, AIR, NOI, OR AIR ENDS. 4310-01-198-9365 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4310-01-198-9365 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 60340 which rates the freight between FCL and LCL. 4310-01-198-9365 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4310-01-198-9365 is not classified as a special type of cargo when transported by water. 4310-01-198-9365 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4310-01-198-9365
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 72.0" H x 33.0" W x 51.0" L
- --
- --
- --
- Special Requirements
- 72.0" H x 33.0" W x 51.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
