4210-01-232-3078
Fire Protection Sprinkler Head
4210012323078 012323078 MIL-S-24660 MIL-S-24660-18
An automatic device specifically designed for the discharge of water, chemical powder/foam, or vaporizing liquid in a sprayed, fogged, or directionalized patterns. Normally used in fixed fire protection systems. View more Fire Protection Sprinkler Head
November 2023
7
Product Information 4210-01-232-3078
Ultra-Wide Full Cone Fire Suppression Nozzles
MIL-S-24660 Approved
DESIGN FEATURES
- Two-turn spiral
- Ultra-wide spray coverage very close to the nozzle
- One-piece design/no internal parts
- Excellent choice for deluge applications where there is little distance between nozzle and material being protected
- Marine applications include deluge, foam, and water wall systems where the nozzles are subject to extreme weather conditions and exposure to seawater
SPRAY PATTERN:
- The spray pattern of the spiral nozzle is formed by the fluid shearing along with the turns of the spiral, which produce multiple concentric cones. These cones form 2 to 3 bands of relatively coarse droplets surrounded by wider bands of relatively fine droplets.
- Provides wide spray coverage and fine atomization
Marketplace 4210-01-232-3078
Request a Quotation from participating marketplace vendors
Related Documents 4210-01-232-3078 5+ Documents (More...)
BUY NE FedMall Updated Every Day 4210-01-232-3078 RQST NE Updated Every Day 4210-01-232-3078 RQST
) https//www.nsnlookup.com /fsg-42/fsc-4210/us 4210-01-232-3078 Fire Protection Sprinkler Head 4210012323078
Fire Protection Sprinkler Head 4210012323078 Upgrade your Account Upgrade 4210-01-232-3078Fire
Protection Sprinkler Head4210012323078 012323078 MIL-S-24660 MIL-S-24660-18 An automatic device specifically
MIL-S-24660-16 An automatic device specifically designed for the discharge of water, chemical https/
Fire Protection Sprinkler Head 4210012323078 MIL-S-24660-18 An automatic device specifically designed
-32 HEAD MIL-S-24660-32 An automatic device specifically designed for the discharge of water, chemical
powder https//www.nsnlookup.com /fsg-42/fsc-4210/us 4210-01-232-3078 Fire Protection Sprinkler Head
-16 https//www.nsnlookup.com /fsg-42/fsc-4210/us 4210-01-232-3078 Fire Protection Sprinkler Head
4210012323078 automatic device specifically designed for the discharge of water, chemical powder MIL-S
Restrictions 4210-01-232-3078
4210-01-232-3078 is a Fire Protection Sprinkler Head that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 4210-01-232-3078
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4210-01-232-3078
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
Approved Sources 4210-01-232-3078
- Part Number
- Manufacturer
- Status
- MIL-S-24660-18
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-S-24660
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 4210-01-232-3078
- Characteristic
- Specifications
- FIIG
- Specifications
- T278-N
- Connection Thread Series [ATGF]
- Npt
- Flow Capacity At Specified Pressure Rating [BXNX]
- 19 Gal Per Min At 100 Psi
- Head Type [AJGD]
- Sprinkler
- Material [MATT]
- Copper Alloy
- Nondefinitive Spec/Std Data [ZZZT]
- 18 Size
- Integral Strainer [AHZW]
- Not Included
Weapon Systems (WSDC) 4210-01-232-3078
DLA Procurement Analysis 4210-01-232-3078
- Last Stock Position:
- 34 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4210-01-232-3078
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4210-01-232-3078
Freight Information 4210-01-232-3078
4210-01-232-3078 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 178080. A Sub NMFC of X. It has a NMFC Description of SPRINKLER HEADS AUTO FIRE EXT. 4210-01-232-3078 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87480 which rates the freight between FCL and LCL. 4210-01-232-3078 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 796 for ocean manifesting and military sealift. 4210-01-232-3078 is not classified as a special type of cargo when transported by water. 4210-01-232-3078 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4210-01-232-3078
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- No Requirement
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 4210-01-232-3078 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
