4210-01-231-7168
Fire Protection Sprinkler Head
4210012317168 012317168 MIL-S-24660 MIL-S-24660-32
An automatic device specifically designed for the discharge of water, chemical powder/foam, or vaporizing liquid in a sprayed, fogged, or directionalized patterns. Normally used in fixed fire protection systems. View more Fire Protection Sprinkler Head
November 2023
6
Product Information 4210-01-231-7168
Ultra-Wide Full Cone Fire Suppression Nozzles
MIL-S-24660 Approved
DESIGN FEATURES
- Two-turn spiral
- Ultra-wide spray coverage very close to the nozzle
- One-piece design/no internal parts
- Excellent choice for deluge applications where there is little distance between nozzle and material being protected
- Marine applications include deluge, foam, and water wall systems where the nozzles are subject to extreme weather conditions and exposure to seawater
SPRAY PATTERN:
- The spray pattern of the spiral nozzle is formed by the fluid shearing along with the turns of the spiral, which produce multiple concentric cones. These cones form 2 to 3 bands of relatively coarse droplets surrounded by wider bands of relatively fine droplets.
- Provides wide spray coverage and fine atomization
Marketplace 4210-01-231-7168
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 4210-01-231-7168 5+ Documents (More...)
MIL-S-24660-32 HEAD,SPRINKLER,FIRE PROTECTION 59 EA NS Request Quotation Subscribe to View Vendor Details
MIL-S-24600-32 HEAD 48 EA NS Request Quotation 325293 HEAD SPRINKLER 1 EA NS Request Quotation MIL-S-24660
MIL-S-24660-16 An automatic device specifically designed for the discharge of water, chemical https/
https//www.nsnlookup.com /fsg-42/fsc-4210/us 4210-01-231-7168 Fire Protection Sprinkler Head 4210012317168
Upgrade -28 An automatic device specifically designed for the discharge of water, chemical powder MIL-S-24660
-16 An automatic device specifically designed for the discharge of water, chemical powder MIL-S-24660
https//www.nsnlookup.com /fsg-42/fsc-4210/us 4210-01-231-7168 Fire Protection Sprinkler Head 4210012317168
MIL-S-24660-32 An automatic device specifically designed for the discharge of water, chemical powder
Fire Protection Sprinkler Head 4210012317168 MIL-S-24660-32 An automatic device specifically designed
chemical powder -32 An automatic device specifically designed for the discharge of water, chemical MIL-S-24660
Restrictions 4210-01-231-7168
4210-01-231-7168 is a Fire Protection Sprinkler Head that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 4210-01-231-7168
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4210-01-231-7168
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTHD
Approved Sources 4210-01-231-7168
- Part Number
- Manufacturer
- Status
- MIL-S-24660-32
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-S-24660
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 4210-01-231-7168
- Characteristic
- Specifications
- FIIG
- Specifications
- T278-N
- Connection Thread Series [ATGF]
- Npt
- Connection Thread Location [ARFH]
- External
- Connection Thread Size [ANKC]
- 1/2 In.-14
- Flow Capacity At Specified Pressure Rating [BXNX]
- 40 Gal Per Min At 50 Psi
- Head Type [AJGD]
- Sprinkler
- Material [MATT]
- Copper Alloy
- Integral Strainer [AHZW]
- Not Included
Weapon Systems (WSDC) 4210-01-231-7168
DLA Procurement Analysis 4210-01-231-7168
- Last Stock Position:
- 367 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4210-01-231-7168
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 4210-01-231-7168
Freight Information 4210-01-231-7168
4210-01-231-7168 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 178080. A Sub NMFC of X. It has a NMFC Description of SPRINKLER HEADS AUTO FIRE EXT. 4210-01-231-7168 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 87480 which rates the freight between FCL and LCL. 4210-01-231-7168 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 796 for ocean manifesting and military sealift. 4210-01-231-7168 is not classified as a special type of cargo when transported by water. 4210-01-231-7168 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4210-01-231-7168
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 2.0" H x 2.0" W x 2.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 2.0" H x 2.0" W x 2.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
Procurement History 4210-01-231-7168 1 Records
Contracting Technical Data File (CTDF) 4210-01-231-7168 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
