4140-00-563-0302
Centrifugal Fan
4140005630302 005630302 506-5590-004
A nonpositive displacement mechanical device having a centrifugal fan impeller inclosed within a housing. It is designed to move air or gas over a wide range of volumes and pressures. The air or gas is drawn in axially and discharged radially or drawn in radially and discharged axially by centrifugal force through an outlet in the housing. View more Centrifugal Fan
May 2023
10
Marketplace 4140-00-563-0302
Request a Quotation from participating marketplace vendors
Related Documents 4140-00-563-0302 5+ Documents (More...)
United States (US) 4. 4140-00-563-0302 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 4140-00-563-0302 RQST Updated Every Day 4140-00-563-0302 RQST NE Related Documents
Centrifugal Fan 4140005630302 005630302 $1 a day Upgrade your Account Upgrade 4140-00-563-0302Centrifugal
Fan4140005630302 005630302 506-5590-004 www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-563-0302 Centrifugal
Restrictions 4140-00-563-0302
4140-00-563-0302 is a Centrifugal Fan that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4140-00-563-0302
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4140-00-563-0302
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 4140-00-563-0302
- Part Number
- Manufacturer
- Status
- 506-5590-004
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 4140-00-563-0302
- Characteristic
- Specifications
- FIIG
- Specifications
- A087A0
- Drive Type [AKCV]
- Direct
- Ambient Temp At Full Rated Power [AEHY]
- -55.0 Deg Celsius And 85.0 Deg Celsius
- Discharge Direction [CXCB]
- Horizontal
- Frequency In Hertz [FREQ]
- 50.0 And 60.0
- Fsc Application Data [ZZZV]
- Amplifier,Part No. 5063623006
- Material [MATT]
- Copper Alloy Housing
- Material [MATT]
- Steel Blade
- Operating Speed At Rated Capacity In Rpm [AEQC]
- 3200.0
- Inclosure Type [AKNA]
- Fully Inclosed
- Prime Mover Drive Shaft Bearing Type [CWLY]
- Ball
- Prime Mover Power Rating [CSYL]
- 0.012 Horsepower
- Prime Mover Type [AKDJ]
- Electric Motor
- Quantity [NMBR]
- 1
- Rotation Direction For Which Designed [AYSY]
- Clockwise
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Operating Speed At Rated Capacity In Rpm 2Nd Reply 2650.0; Prime Mover Horsepower Rating 2Nd Reply 0.009
- Voltage In Volts And Current Type [CSBH]
- 115.0 Ac
- Stage Quantity [AAYD]
- 2
- Surface Treatment [SFTT]
- Cadmium Blade
Similar Supply Items to 4140-00-563-0302
Freight Information 4140-00-563-0302
4140-00-563-0302 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061920. A Sub NMFC of X. It has a NMFC Description of FANS ELEC NOI IN BARREL/BOX/CRATE. 4140-00-563-0302 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 4140-00-563-0302 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34690 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 752 for ocean manifesting and military sealift. 4140-00-563-0302 is not classified as a special type of cargo when transported by water. 4140-00-563-0302 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
