4140-00-255-7799
Circulating Fan
4140002557799 002557799 MIL-DTL-68 41210 MAGNETIC MIL-DTL-68G TA12 CLASS 1 TA12 MAGNETIC TA12 MAGNETIC 4140PL1215450
A nonpositive displacement mechanical device having an axial fan impeller with or without a protective enclosure. It is designed to circulate air under free-airflow conditions, and may be equipped with a baffle(s) to deflect the air radially. It may be suspended from the ceiling, attached to the wall, or stand on a horizontal surface. View more Circulating Fan
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
32
32
NATO Data Quality
Product Information 4140-00-255-7799
Fan Circulating - Navy
Non-oscillating, fully enclosed.
Designed to circulate air under free airflow conditioning.
Mounting: ceiling, bulkhead, deck or stand.
Power: 115 VAC, 45 Watt, 0.6Amp, 60 Hz.
Baffle can be fitted to deflect air radially.
Two speeds
Marketplace 4140-00-255-7799
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Global Test Supply
TA12 FLIR TA12 Protective Carrying Case for FLIR Test Accessories STK NE $55.99 Distributor Buy Now
41210MAGNETIC FAN,CIRCULATING 2 EA NS
MIL-F-68 FAN,CIRCULATING 2 EA NS
TA12MAGNETIC FAN,CIRCULATING 2 EA NS
CLASS1TA12MAGNETI FAN,CIRCULATING 2 EA NS
Updated Every Day 4140-00-255-7799 RQST NE
Updated Every Day 4140-00-255-7799 RQST
Updated Every Day 4140-00-255-7799 RQST NE
Related Documents 4140-00-255-7799 5+ Documents (More...)
MIL-DTL-68 41210 MAGNETIC MIL-DTL-68G TA12 CLASS 1 TA12 MAGNETIC TA12 MAGNETIC 4140PL1215450 A nonpositive
vendors Request Global Test Supply TA12 FLIR TA12 Restrictions 4140-00-255-7799 DEMIL: A https//www.nsnlookup.com
Circulating Fan 4140002557799002557799 FLIR TA12 Restrictions 4140-00-255-7799 DEMIL: A https/
vendors Request Global Test Supply TA12 FLIR TA12 Restrictions 4140-00-255-7799 DEMIL: A https//www.nsnlookup.com
Circulating Fan 4140002557799002557799 FLIR TA12 Restrictions 4140-00-255-7799 DEMIL: A https/
from United States (US) Jan 1900 4140-00-111-5685 https//www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-255-7799
Circulating Fan 4140002557799 002557799 Equipment from United States (US) Jan 1900 4140- https/
4140001115685001115685 (US) Jan 1900 4140-01-055-8544 Tubeaxial Fan 1 Jan 1900 4140 7799 Circulating Fan 4140002557799
Circulating Fan 4140002557799 002557799 Equipment from United States (US) Jan 1900 4140- https/
4140001115685001115685 (US) Jan 1900 4140-01-055-8544 Tubeaxial Fan 1 Jan 1900 4140 7799 Circulating Fan 4140002557799
Related Documents 4140-00-555-3714 1+ Documents https//www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-255-7799
Circulating Fan 4140002557799 002557799 www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-555- https
Circulating Fan 4140002557799 002557799 www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-555- https
States (US) Jan 1900 4140-00 https/ 4140-00-944-7321 https//www.nsnlookup.com /fsg-41/fsc-4140/us 4140-00-255-7799
Circulating Fan 4140002557799 002557799 Jan 1900 4140 7799 Circulating Fan 4140002557799 https/
Circulating Fan 4140002557799 002557799 Jan 1900 4140 7799 Circulating Fan 4140002557799 https/
Jan 1900 4140-00-111-5685 Vaneaxial Fan 1 Jan 1900 4140-00-944-7321 Tubeaxial Fan 1 Jan 1900 4140-00-255-7799
Restrictions 4140-00-255-7799
4140-00-255-7799 is a Circulating Fan that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4140-00-255-7799
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4140-00-255-7799
- US Army (A920)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- A186
- US Coast Guard (C918)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- C003
- US Marine Corps (MC47)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTKEJBHD
- Poland (WP01)
- Effective Date:
- 1 Jan 2005
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Jun 1996
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4140-00-255-7799
- Part Number
- Manufacturer
- Status
- CLASS 1 TA12 MAGNETIC
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-68
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 41210 MAGNETIC
- 32682 - Penn Metal Fabricators Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MIL-DTL-68G
- 1KPC6 - Vidmark Distribution Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- TA12 MAGNETIC
- 02144 - Sunbeam Corp Phil Rich Fan Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 4140PL1215450
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- TA12
- D9182 - Zf Industrieantriebe Witten Gmbh (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4140-00-255-7799
- Characteristic
- Specifications
- FIIG
- Specifications
- A087A0
- Drive Type [AKCV]
- Direct
- Electrical Connection Type [AGBD]
- Wire Lead
- Diameter [ABMZ]
- 12.000 Inches Nominal
- Features Provided [CBBL]
- Safety Impeller Guard
- Frequency In Hertz [FREQ]
- 60.0
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- Ta12 Type And 1 Class
- Inclosure Type [AKNA]
- Fully Inclosed
- Prime Mover Power Rating [CSYL]
- 67.0 Watts
- Prime Mover Type [AKDJ]
- Electric Motor
- Prime Mover Drive Shaft Bearing Type [CWLY]
- Ball Or Sleeve
- Rotation Direction For Which Designed [AYSY]
- Clockwise
- Phase [FAAZ]
- Single
- Voltage In Volts And Current Type [CSBH]
- 115.0 Ac
- Speed Adjustments [ABBB]
- Two Speed
Weapon Systems (WSDC) 4140-00-255-7799
DLA Procurement Analysis 4140-00-255-7799
- Last Stock Position:
- 198 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4140-00-255-7799
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 4140-00-555-3714
- 0
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 1
- Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- C
- Type 2 (as required items)
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 4140-00-255-7799
4140-32-077-1695 4140-50-000-8963 4140-21-344-1803 4140-99-340-2016 4140-12-334-7225 4140-16-002-7414 4140-37-518-3338 4140-99-375-0148 4140-37-514-9796 4140-22-603-9600 4140-21-108-1006 4140-99-131-4515 4140-99-523-7796 4140-99-867-8688 4140-99-137-9584 4140-14-564-9751 4140-99-326-6001 4140-99-666-7892
Freight Information 4140-00-255-7799
4140-00-255-7799 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061920. A Sub NMFC of X. It has a NMFC Description of FANS ELEC NOI IN BARREL/BOX/CRATE. 4140-00-255-7799 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34690 which rates the freight between FCL and LCL. 4140-00-255-7799 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 752 for ocean manifesting and military sealift. 4140-00-255-7799 is not classified as a special type of cargo when transported by water. 4140-00-255-7799 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4140-00-255-7799
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 4140-00-255-7799 6 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE8E923P0550
- 26 Jan 2023
- Subscribe
- 324
- Subscribe
- Subscribe
- Subscribe
- SPE8E923P0550P00001
- 26 Jan 2023
- Subscribe
- 324
- Subscribe
- Subscribe
- Subscribe
- SPE8E922P1129
- 10 Jun 2022
- Subscribe
- 250
- Subscribe
- Subscribe
- Subscribe
- SPE8E922P0928
- 02 May 2022
- Subscribe
- 76
- Subscribe
- Subscribe
- Subscribe
- SPE8E922P0717
- 18 Mar 2022
- Subscribe
- 150
- Subscribe
- Subscribe
- Subscribe
- SPE8E922P0110
- 20 Oct 2021
- Subscribe
- 48
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 4140-00-255-7799 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
