4130-00-541-8254
Air Conditioning Filter Element
4130005418254 005418254 7660683 120991 B7660683
A replaceable device designed to remove dust, pollen or other foreign matter from the air passing through it. The removal of particles is accomplished by porous fibrous or shredded material (metallic or nonmetallic) which is loosely woven or matted and confined in a frame or retained between perforated sheets of firmer material. It is designed to fit into air conditioners, ventilation systems and hot air furnaces. It may have facilities for radio frequency/electromagnetic interference shielding. The filter may be cleaned by the use of compressed air, blown through the filter element, or by using water and a suitable detergent for cleaning purposes which would extend the life of the filter. View more Air Conditioning Filter Element
May 2023
25
Marketplace 4130-00-541-8254
Request a Quotation from participating marketplace vendors
Related Documents 4130-00-541-8254 5+ Documents (More...)
RQST NE Updated Every Day 4130-00-541-8254 RQST Updated Every Day 4130-00-541-8254 RQST NE Related
Documents 4130-00-541-8254 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-41/fsc-4130/us 4130
Air Conditioning Filter Element 005418254 a day Upgrade your Account Upgrade 4130-00-541-8254Air
Conditioning Filter Element4130005418254 005418254 ) https//www.nsnlookup.com /fsg-41/fsc-4130/us 4130
to enable JavaScript in your web browser . 5325-14-352-7526Retaining Ring5325143527526 143527526 120991
enable JavaScript in your web browser . 7490-00-051 -4442Unwinder Ass Flange7490000514442 000514442 120991
Air Conditioning Filter Element 005418254 )M4Reversal Of Phrase Code A 1230-00-692-1461US Marine
Restrictions 4130-00-541-8254
4130-00-541-8254 is a Air Conditioning Filter Element that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4130-00-541-8254
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4130-00-541-8254
- US Air Force (FGGI)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FGKZ
- US Marine Corps (MC47)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 4130-00-541-8254
- Part Number
- Manufacturer
- Status
- 7660683
- Manufacturer
- 19200 - Combat Capabilities Development (Active)
- Primary Buy
- Primary Buy
- 120991
- 00736 - Falls Filtration Technologies, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B7660683
- 64959 - American Telephone And Telegraph Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- B7660683
- 70408 - At And T Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4130-00-541-8254
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Style Designator [STYL]
- Rectangular (Incl Square)
- Overall Width [ABMK]
- 9.875 Inches Nominal
- Body Thickness [ADPR]
- 0.938 Inches Nominal
- Body Overall Length [AZTL]
- 9.875 Inches Nominal
- Material [MATT]
- Aluminum Alloy 5056 Filtering Medium
- Material [MATT]
- Aluminum Alloy 3003 Frame
- Material Document And Classification [MDCL]
- Qq-A-359 Fed Spec Single Material Response Frame
- Surface Treatment [SFTT]
- Paint Filtering Medium
- Surface Treatment [SFTT]
- Paint Frame
- Filtering Media Design [CRXW]
- Crimped 1St Filtering Media Response
- Filtering Media Design [CRXW]
- Mesh 2Nd Filtering Media Response
- Design Type [APGF]
- Nonreusable
- Maximum Air Flow Rate [ABBD]
- 1200.0 Cubic Feet Per Minute
DLA Procurement Analysis 4130-00-541-8254
Management Data 4130-00-541-8254
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 1230-00-692-1461
- 4
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 1285-00-692-1461
- 4
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- TG
- AF SICA RESIDUAL MMAC-WR-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 4130-00-541-8254
Freight Information 4130-00-541-8254
4130-00-541-8254 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of F. It has a NMFC Description of FILTERS:FILTERS,NOI SUB6. 4130-00-541-8254 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 4130-00-541-8254 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 4130-00-541-8254 is not classified as a special type of cargo when transported by water. 4130-00-541-8254 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4130-00-541-8254
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4130-00-541-8254 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
