4120-01-136-2214
Air Conditioner
4120011362214 011362214 A9KH-115P
A self-contained unit designed to perform the functions of cooling, circulating, filtering, dehumidifying or otherwise processing of air. It may also be equipped to perform the additional functions of heating or humidifying. It may be the air cycle type used in aircraft or the vapor cycle type applicable to ground or aerospace equipment. Excludes ENVIRONMENTAL CONTROL UNIT, PERSONNEL, SELF-CONTAINED. View more Air Conditioner
May 2023
6
Marketplace 4120-01-136-2214
Request a Quotation from participating marketplace vendors
Related Documents 4120-01-136-2214 5+ Documents (More...)
RQST NE Updated Every Day 4120-01-136-2214 RQST Updated Every Day 4120-01-136-2214 RQST NE Related Documents
4120-01-136-2214 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-41/fsc-4120/us 4120-01-136-2214
Air Conditioner 4120011362214 011362214 EaEnd Item Identification [AGAV] 4120-01-136-2214 https
Datasheet 5910-01-255-6364 CharacteristicSpecificationsFIIGA23900End Item Identification [AGAV] 4120-01-136-2214
Day 4120-01-219-8760 RQST Updated Every Day 4120- https//www.nsnlookup.com /fsg-41/fsc-4120/us 4120-01-136-2214
Air Conditioner 4120011362214 011362214 for $1 a day Upgrade your Account Upgrade 4120-01-136-2214Air
Air Conditioner 4120011362214 011362214 Upgrade your Account Upgrade 4120-01-136-2214Air https/
Sources Datasheet Management CharacteristicSpecificationsFIIGA23900End Item Identification [AGAV] 4120-01-136-2214
Air Conditioner 4120011362214 011362214 Upgrade your Account Upgrade 4120-01-136-2214Air https/
2 Ea; 5910000990541 Capacitor, Fixed, Ceramic Dielectric 1 EaEnd Item Identification [AGAV] 4120-01-136-2214
Restrictions 4120-01-136-2214
IUID Required
4120-01-136-2214 is a Air Conditioner that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.
End Users 4120-01-136-2214
- US Army (A502)
- Effective Date:
- 1 Oct 1997
- Former MOE Rule:
- A002
- Supplementary Receivers:
- AJ
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 1995
Approved Sources 4120-01-136-2214
- Part Number
- Manufacturer
- Status
- A9KH-115P
- Manufacturer
- 57107 - A R E Mfg Co Inc (Obsolete)
- Original Design
- Original Design
Datasheet 4120-01-136-2214
- Characteristic
- Specifications
- FIIG
- Specifications
- A505G0
- Electric Motor Quantity [AWLX]
- 3
- Cabinet Material [CYGG]
- Aluminum-Copper Free
- Compressor Unit Type [AZSD]
- Closed
- Condenser Cooling Type [AZAD]
- Air
- Coolant Type [ARNA]
- Genetron-115
- Cooling Capacity In Btu Per Hour [CYJE]
- 9000.0 Nominal
- Current Type [ACDC]
- Ac
- Frequency Rating [ACZB]
- 60.0 Hertz Nominal
- Mounting Type [AAXX]
- Floor
- Nominal Cooling Capacity [AZSF]
- 370.0 Cubic Feet Per Minute
- Power Source [ATJK]
- Electric Motor
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Cooling Tower-Not Incl.;Evaporator Condender-Not Incl.;Accessories-Not Incl.;Sgl Pkg,Compact Horizontal Unit
- Usage Design [ALCD]
- Compressor,Condenser Fan,Evaporator Fan
- Voltage Rating [AMSE]
- 115.0 Volts Nominal
- Surface Treatment [SFTT]
- Lacquer
Management Data 4120-01-136-2214
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 2014
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Jan 2013
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- 3
- Reversal Of Phrase Code S 4120-00-916-9404
- 3
- Department of the Army (DA)
- L
- J
- Interchangeable With 4120-00-411-5442
- J
- Department of the Army (DA)
- L
- J
- Interchangeable With 4120-01-456-6954
- J
- Department of the Army (DA)
- L
- J
- Interchangeable With 4120-01-219-8760
- J
- Department of the Army (DA)
- L
- J
- Interchangeable With 4120-01-250-3719
- J
- Department of the Army (DA)
- L
- J
- Interchangeable With 4120-01-326-4370
- J
Army
- Materiel Category and Inventory Manager:
- G
- Communications and Electronics Equipment, Electronics Materiel
- Appropriation and Budget Activity:
- Q
- Other Support Equipment
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- W5
- Line of Communication and Base Support Systems
Air Conditioning (AC) & Support Equipment
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- RN
- GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC)
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
NATO Stock Numbers Related to 4120-01-136-2214
Freight Information 4120-01-136-2214
4120-01-136-2214 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114125. A Sub NMFC of Z. It has a NMFC Description of AIR COOLER/CONDITIONER/HEAT PUMP. 4120-01-136-2214 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 4120-01-136-2214 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 58510 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 4120-01-136-2214 is not classified as a special type of cargo when transported by water. 4120-01-136-2214 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4120-01-136-2214
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 0.1" H x 0.1" W x 0.1" L
- --
- --
- --
- Special Requirements
- 0.1" H x 0.1" W x 0.1" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
