4030-01-589-9822
Cargo Hook
4030015899822 015899822 FE7590-173-4
A strongly constructed item having a short leg extending from its base toward the point of the item to prevent the sling or line from slipping off the item. Some styles are furnished with swivels, links, and the like, for special uses. Excludes items with safety throat closures that completely close the opening. For items with safety throat closures, see HOOK, HOIST. View more Cargo Hook
November 2023
1
Product Information 4030-01-589-9822
FE7590 Cargo Hook
The FE7590 cargo hook system is used for lifting and transporting external loads by helicopter, vertical replenishment or firefighting. It is proven around the world in service and for diverse missions, and is available for installation on a range of popular helicopters.
With a lifting capacity of 9,000 lb (4091 kg), the FE7590 cargo hook is ideal for vertical replenishment, firefighting and a range of other missions.
Design
- Cadmium plated load beam
- Electrical components shielded for electromagnetic compatibility
- Internal mechanism in sealed housing
- Trunnion mount
- Optional fixed keeper solutions (satisfies keeperless requirements)
Safety
- Electrical release, pilot, normal: solenoid
- Electrical release, pilot, emergency: cartridge actuated device
- Optional load sensing
- Optional indicator display
Marketplace 4030-01-589-9822
Request a Quotation from participating marketplace vendors
Related Documents 4030-01-589-9822 5+ Documents (More...)
4030-01-589-9822 4+ Documents ( More... ) https//www.nsnlookup.com /fsg-40/fsc-4030/us 4030-01-589-9822
/fsg-40/fsc-4030/us 4030-01-589-9822 from its base toward the point RQST NE Updated Every Day 4030-01
Cargo Hook 4030015899822 015899822 Upgrade for $1 a day Upgrade your Account Upgrade 4030-01-589
-9822Cargo Hook4030015899822 015899822 FE7590-173 https//www.nsnlookup.com /fsg-40/fsc-4030/us 4030-01
Cargo Hook 4030015899822 015899822 //www.nsnlookup.com /fsg-40/fsc-4030/us 4030-01 https//www.nsnlookup.com
Restrictions 4030-01-589-9822
4030-01-589-9822 is a Cargo Hook that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4030-01-589-9822
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 2010
Approved Sources 4030-01-589-9822
- Part Number
- Manufacturer
- Status
- FE7590-173-4
- Manufacturer
- 08484 - Breeze-Eastern Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 4030-01-589-9822
- Characteristic
- Specifications
- FIIG
- Specifications
- A105A0
- Special Features [FEAT]
- 16 Amps
- Part Name Assigned By Controlling Agency [CXCY]
- Hook, Cargo
Similar Supply Items to 4030-01-589-9822
Freight Information 4030-01-589-9822
4030-01-589-9822 has freight characteristics managed by the Republic of Korea.. 4030-01-589-9822 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
