4030-01-109-3024
Cargo Hook
4030011093024 011093024 70800-02503 FE7590-55 FE7590-1 70800-02503-103
A strongly constructed item having a short leg extending from its base toward the point of the item to prevent the sling or line from slipping off the item. Some styles are furnished with swivels, links, and the like, for special uses. Excludes items with safety throat closures that completely close the opening. For items with safety throat closures, see HOOK, HOIST. View more Cargo Hook
November 2023
6
Product Information 4030-01-109-3024
FE7590 Cargo Hook
The FE7590 cargo hook system is used for lifting and transporting external loads by helicopter, vertical replenishment or firefighting. It is proven around the world in service and for diverse missions, and is available for installation on a range of popular helicopters.
With a lifting capacity of 9,000 lb (4091 kg), the FE7590 cargo hook is ideal for vertical replenishment, firefighting and a range of other missions.
Design
- Cadmium plated load beam
- Electrical components shielded for electromagnetic compatibility
- Internal mechanism in sealed housing
- Trunnion mount
- Optional fixed keeper solutions (satisfies keeperless requirements)
Safety
- Electrical release, pilot, normal: solenoid
- Electrical release, pilot, emergency: cartridge actuated device
- Optional load sensing
- Optional indicator display
Marketplace 4030-01-109-3024
Request a Quotation from participating marketplace vendors
Related Documents 4030-01-109-3024 5+ Documents (More...)
4030-01-109-3024 RQST Updated Every Day 4030-01-109-3024 RQST NE Related Documents 4030-01-109-3024
RQST Updated Every Day 4030-01-109-3024 RQST NE Related Documents 4030-01-109-3024 RQST NE Updated
www.nsnlookup.com /fsg-53/fsc-5310/us 5310-01-694-8057 https//www.nsnlookup.com /fsg-40/fsc-4030/us 4030-01-109-3024
Cargo Hook 4030011093024 011093024 a day Upgrade your Account Upgrade 4030-01-109-3024Cargo Hook4030011093024
FE7590-145 HOOK,CARGO 1 EA NS Request Quotation 70800-02503-111 HOOK,CARGO 1 EA NS Request Quotation
-111 HOOK,CARGO 1 EA NS Request Quotation 70800-02503-111 HOOK,CARGO 1 EA NS Request Quotation Day
FE7590-120A 70800-02503-107 A strongly constructed metal item having a relatively narrow, shallow
Cargo Hook 4030011093024 011093024 FE7590-55 FE7590-1 70800-02503-103 A strongly constructed item
Restrictions 4030-01-109-3024
4030-01-109-3024 is a Cargo Hook Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4030-01-109-3024
- US Army (A702)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BF
- Brazil (YA01)
- Effective Date:
- 1 Dec 2008
Approved Sources 4030-01-109-3024
- Part Number
- Manufacturer
- Status
- 70800-02503
- Manufacturer
- 81996 - Us Army Aviation And Missile Command (Active)
- Reparable Source Control
- Reparable Source Control
- FE7590-55
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Primary Reparable
- Primary Reparable
- FE7590-1
- 01276 - Danfoss Power Solutions Ii, Llc (Active)
- Secondary Reparable
- Secondary Reparable
- 70800-02503-103
- 78286 - Sikorsky Aircraft Corporation (Active)
- Secondary Reparable
- Secondary Reparable
Datasheet 4030-01-109-3024
- Characteristic
- Specifications
- FIIG
- Specifications
- A105A0
- Reference Number Differentiating Characteristics [ZZZY]
- As Differentiated By Source Control Dwg No. 70800-02503
Management Data 4030-01-109-3024
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- F
- When Exhausted Use 4030-01-456-4792
- F
- Department of the Army (DA)
- L
- R
- Refer To Net Price 14955.00
- NET PRICE 14955.00
- R
Army
- Materiel Category and Inventory Manager:
- H
- Aircraft, Air Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- BE
- Rotary Wing Aircraft
UH-60
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 4030-01-109-3024
Freight Information 4030-01-109-3024
4030-01-109-3024 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 184850. A Sub NMFC of X. It has a NMFC Description of TOOLS:HOOKS GRAB/HOIST/ROOT ETC. 4030-01-109-3024 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 90740 which rates the freight between FCL and LCL. 4030-01-109-3024 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 4030-01-109-3024 is not classified as a special type of cargo when transported by water. 4030-01-109-3024 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4030-01-109-3024
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 19.8" H x 11.3" W x 5.5" L
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 32.0" H x 22.3" W x 15.0" L
- --
- --
- --
- Special Requirements
- 32.0" H x 22.3" W x 15.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
