4030-00-373-1119
Shackle
4030003731119 003731119 MIL-S-24214 M24214 TY1 GR A CL3 0.625 IN
An open or closed link of various shapes with extended legs. Each leg has a transverse hole to accommodate a pin, bolt, or the like, which may or may not be furnished. Excludes clevis (as modified). View more Shackle
May 2023
6
Marketplace 4030-00-373-1119
Request a Quotation from participating marketplace vendors
Related Documents 4030-00-373-1119 5+ Documents (More...)
Photo 1/3 NSN 4030-00-373-1119 (Identification) 2/3 NSN 4030-00-373-1119 (Identification) 3/3 -
MIL-S-24214 SHACKLE 13 EA NS Request Quotation Updated Every Day 4030-00-373-1119 RQST NE Updated Every
Shackle 4030003693736003693736,MIL-S-24214 Updated Every MIL-S-24214 SHACKLE 13 EA NS Request https/
/fsg-40/fsc-4030/us 4030-00-373-1119 Shackle 4030003731119 003731119,MIL-S-24214MIL-S-24214 SHACKLE
Shackle 4030003693736003693736,MIL-S-24214 Updated Every MIL-S-24214 SHACKLE 13 EA NS Request https/
/fsg-40/fsc-4030/us 4030-00-373-1119 Shackle 4030003731119 003731119,MIL-S-24214MIL-S-24214 SHACKLE
Shackle 4030003731119 003731119,MIL-S-24214MIL-S-24214 SHACKLE RQST NS Shackle 4030003694038003694038
Shackle 4030003731119 003731119,MIL-S-24214MIL-S-24214 SHACKLE RQST NS Shackle 4030003694038003694038
/fsg-40/fsc-4030/us 4030-00-373-1119 Shackle 4030003731119 003731119,MIL-S-24214MIL-S-24214 SHACKLE Shackle
4030003693736003693736,MIL-S-24214 Updated Every MIL-S-24214 SHACKLE 13 EA NS Request https// https/
Restrictions 4030-00-373-1119
4030-00-373-1119 is a Shackle that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4030-00-373-1119
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 4030-00-373-1119
- Part Number
- Manufacturer
- Status
- M24214 TY1 GR A CL3 0.625 IN
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-S-24214
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 4030-00-373-1119
- Characteristic
- Specifications
- FIIG
- Specifications
- A105A0
- End Condition [AHNV]
- Threaded
- Breaking Strength [BZQQ]
- 22100.0 Pounds Minimum
- Closure Head Style [CTWJ]
- Hexagon
- Material [MATT]
- Steel Or Steel Comp 1020
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And A Grade And 3 Class
- Opening Width [ABPP]
- 1.000 Inches Minimum And 1.125 Inches Maximum
- Inside Length [ADJU]
- 2.281 Inches Minimum And 2.531 Inches Maximum
- Locking Device Type [AZAF]
- Cotter Pin And Nut
- Material Diameter [AJRB]
- 0.625 Inches Minimum
- Material Document And Classification [MDCL]
- Astm A322 Assn Std 1St Material Response Or Astm A576 Assn Std 2Nd Material Response
- Style Designator [STYL]
- Anchor
- Surface Treatment Document And Classification [STDC]
- Astm A153 Assn Std 1St Treatment Response Or Qq-Z-325,Cl 2 Fed Spec 2Nd Treatment Response And Qq-Z-325,Cl 2 Fed Spec 3Rd Treatment Response
- Surface Treatment [SFTT]
- Zinc Or Zinc And Chromate
Similar Supply Items to 4030-00-373-1119
Freight Information 4030-00-373-1119
4030-00-373-1119 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 105200. A Sub NMFC of X. It has a NMFC Description of FITTINGS CABLE/CHAIN/ROPE I/S. 4030-00-373-1119 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. 4030-00-373-1119 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 54160 which rates the freight between FCL and LCL. 4030-00-373-1119 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 4030-00-373-1119 is not classified as a special type of cargo when transported by water. 4030-00-373-1119 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
