3990-01-095-8769
Load Binder
3990010958769 010958769 NP5033 069 BX-300 48305 BU1420 4410-00300
A levered device designed to take up the slack in a rope, chain, cable, or band encircling a load for the purpose of securely restraining the material. It may include the rope, chain, cable or band. See also BAR, EXTENSION, LOAD BINDER.Excludes HOIST, CHAIN. View more Load Binder
October 2025
8
Marketplace 3990-01-095-8769
Request a Quotation from participating marketplace vendors
Related Documents 3990-01-095-8769 5+ Documents (More...)
Updated Every Day 3990-01-095-8769 RQST NE Updated Every Day 3990-01-095-8769 RQST Updated Every Day
3990-01-095-8769 RQST NE Related Documents 3990-01-095-8769 5+ Documents ( More... ) https//www.nsnlookup.com
Electrical Contact Brush 5977002384747,48305 Electrica https//www.nsnlookup.com /fsg-39/fsc-3990/us 3990-01-095-8769
Load Binder 3990010958769 010958769 Card Assembly5998251376036 251376036 712 48305 https//www.nsnlookup.com
Restrictions 3990-01-095-8769
3990-01-095-8769 is a Load Binder that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 3990-01-095-8769
- US Army (A920)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A186
- Supplementary Receivers:
- AZ
- US Air Force (FGGI)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- FGKZ
- US Navy (N9BZ)
- Effective Date:
- 1 May 2006
Approved Sources 3990-01-095-8769
- Part Number
- Manufacturer
- Status
- NP5033 069
- Manufacturer
- 61796 - Cemen Tech, Inc. (Active)
- Primary Buy
- Primary Buy
- BX-300
- 79805 - Acco-Babcock Inc Hoist And Crane Div (Active)
- Primary Buy
- Primary Buy
- 48305
- 93922 - Columbus Mckinnon Corporation (Active)
- Primary Buy
- Primary Buy
- 4410-00300
- 79805 - Acco-Babcock Inc Hoist And Crane Div (Active)
- Primary Buy
- Primary Buy
- BU1420
- 0SW64 - Buffers Usa, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 4410-00300
- 72671 - Acco Babcock Inc American Chain Div (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- BX-300
- 72671 - Acco Babcock Inc American Chain Div (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- NP5033 069
- 05643 - Barber-Greene Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- NP5033 069
- 0MKW7 - Minnpar, Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 3990-01-095-8769
- Characteristic
- Specifications
- FIIG
- Specifications
- T160-G
- Tightening Device [ALML]
- Lever
- Take-Up Length [AJRW]
- 4.500 Inches Nominal
- Chain Grab Hook [ALSA]
- Included
- Chain Size [ALSB]
- 0.375 Inches Nominal
- Safe Operating Load Rating [ALSC]
- 5400.000 Pounds Nominal
- Lever [ALSD]
- Included
- Lever Length [ALSE]
- 16.000 Inches Nominal
- Swivel Quantity [ALSG]
- 2
- Take-Up Spring [ALSH]
- Not Included
- Special Features [FEAT]
- Grade 40; Min Breaking Strength 19,000 Lbs
Weapon Systems (WSDC) 3990-01-095-8769
DLA Procurement Analysis 3990-01-095-8769
- Last Stock Position:
- 68 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3990-01-095-8769
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3990-01-095-8769
Freight Information 3990-01-095-8769
3990-01-095-8769 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095740. A Sub NMFC of X. It has a NMFC Description of LOAD BINDERS IRON NOI IN PKGS. 3990-01-095-8769 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 50120 which rates the freight between FCL and LCL. 3990-01-095-8769 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 885 for ocean manifesting and military sealift. 3990-01-095-8769 is not classified as a special type of cargo when transported by water. 3990-01-095-8769 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3990-01-095-8769
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 3990-01-095-8769 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE8EF21V0347
- 29 Apr 2021
- Subscribe
- 39
- Subscribe
- Subscribe
- Subscribe
- SPE8EF18V0626
- 17 May 2018
- Subscribe
- 207
- Subscribe
- Subscribe
- Subscribe
- SPE8EF18V0193
- 06 Jan 2018
- Subscribe
- 54
- Subscribe
- Subscribe
- Subscribe
- SPE8EF18V0076
- 14 Nov 2017
- Subscribe
- 224
- Subscribe
- Subscribe
- Subscribe
- SPE8EF17P0065
- 07 Oct 2016
- Subscribe
- 480
- Subscribe
- Subscribe
- Subscribe
- SPE8EF16M0025P00001
- 06 Oct 2015
- Subscribe
- 280
- Subscribe
- Subscribe
- Subscribe
- SPE8EF15M0099
- 10 Nov 2014
- Subscribe
- 280
- Subscribe
- Subscribe
- Subscribe
- SPM8EF13V0262
- 19 Feb 2013
- Subscribe
- 262
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 3990-01-095-8769 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
