3950-01-558-4225
Chain Hoist
3950015584225 015584225 4047
A device designed to be suspended above deck, floor or ground level having one or more revolving whelped wheels over which a chain is passed for the purpose of raising or lowering a load. May be suspended so as to travel on a fixed track. View more Chain Hoist
May 2023
2
Marketplace 3950-01-558-4225
Request a Quotation from participating marketplace vendors
Related Documents 3950-01-558-4225 2+ Documents (More...)
) https//www.nsnlookup.com /fsg-39/fsc-3950/us 3950-01-558-4225 Chain Hoist 3950015584225 015584225,4047
Photo 1/3 3950-01-558-4225 Photo 2/3 3950-01-558-4225 Photo 3/3 - - - 1.
Restrictions 3950-01-558-4225
3950-01-558-4225 is a Chain Hoist that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 3950-01-558-4225
- Canada (ZC01)
- Effective Date:
- 1 Nov 2007
Approved Sources 3950-01-558-4225
- Part Number
- Manufacturer
- Status
- 4047
- Manufacturer
- 13743 - Columbus Mckinnon Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 3950-01-558-4225
- Characteristic
- Specifications
- FIIG
- Specifications
- A02800
- Operation Method [APHE]
- Hand
- Inclosure Type [AKNA]
- Open
- Hook Quantity [ATWT]
- 2
- Suspension Mounting Method [AWEH]
- Hook
- Maximum Lift Height [AGBP]
- 5.0 Feet
- Raised Position Distance Between Suspension Hook And Load Hook Bearing Surface [AWEW]
- 16.9375 Inches Nominal
- Maximum Load Rating [AYXK]
- 95.0 Pounds
- Special Features [FEAT]
- Aluminum Alloy Construction And Powder Coat Finish; Weatherproof For Outdoor Service; Hoistaloy Hardened Steel Link Type Load Chain; Weatherized Weston Type Automatic Breaking System; One Hand Operation; Free Wheeling; Lever Length 21.250 Inch; Reeving 2; Hook Throat Openings 1.21875 Inch
- Part Name Assigned By Controlling Agency [CXCY]
- Hoist Chain; Cm Puller
Similar Supply Items to 3950-01-558-4225
Freight Information 3950-01-558-4225
3950-01-558-4225 has freight characteristics managed by the Department of the Air Force.. 3950-01-558-4225 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
