3940-01-442-9789
Tackle Block
3940014429789 014429789 7D3-05679 7D5-05660 REV B ITEM 9
A mechanical device, consisting of a pulley(s) or sheave(s) encased in a shell or frame which may be provided with a means such as a hook, eye, strap, screw, etc., by which it may be attached to an object. It is used to change direction of a running rope and/or to gain a mechanical advantage. View more Tackle Block
May 2023
2
Marketplace 3940-01-442-9789
Request a Quotation from participating marketplace vendors
Related Documents 3940-01-442-9789 5+ Documents (More...)
(Identification) 1/2 NSN 3940-01-442-9789 (Identification) 2/2 - - 1.
United States (US) 4. 3940-01-442-9789 Marketplace Restrictions Approved Sources Datasheet Management
https//www.nsnlookup.com /fsg-39/fsc-3940/us 3940-01-442-9789 Tackle Block 3940014429789 014429789 Upgrade
for $1 a day Upgrade your Account Upgrade 3940-01-442-9789Tackle Block3940014429789 014429789 7D3-05679
REV B 7D3-05679 REV B ITEM NO 10 0005044 An externally threaded fastener designed for insertion into
https//www.nsnlookup.com /fsg-39/fsc-3940/us 3940-01-442-9789 Tackle Block 3940014429789 014429789 Upgrade
https//www.nsnlookup.com /fsg-39/fsc-3940/us 3940-01-442-9789 Tackle Block 3940014429789 014429789 Upgrade
for $1 a day Upgrade your Account Upgrade 3940-01-442-9789Tackle Block3940014429789 014429789 7D3-05679
Tackle Block 3940014429789 014429789 a day Upgrade your Account Upgrade 3940-01-442-9789Tackle
Block3940014429789 014429789 7D3-05679 7D5-05660 (Active) Primary Buy RNCC 3 RNVC 2 MEDALS DAC 2 7D5-
Restrictions 3940-01-442-9789
3940-01-442-9789 is a Tackle Block that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3940-01-442-9789
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3940-01-442-9789
- US Navy (N9BZ)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
Approved Sources 3940-01-442-9789
- Part Number
- Manufacturer
- Status
- 7D3-05679
- Manufacturer
- 34712 - Lake Shore Systems, Inc. (Active)
- Primary Buy
- Primary Buy
- 7D5-05660 REV B ITEM 9
- 34712 - Lake Shore Systems, Inc. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 3940-01-442-9789
- Characteristic
- Specifications
- FIIG
- Specifications
- A12900
- Style Designator [STYL]
- Hoister Pattern
- Shell Length [AMRQ]
- 20.000 Inches Nominal
- Sheave Outside Diameter [AMRR]
- 14.000 Inches Nominal
- Center Pin Diameter [AMRT]
- 0.500 Inches Nominal
- Block Type [AMCL]
- Regular
- Material And Location [ANNQ]
- Steel Overall
- Sheave Quantity [AMCQ]
- 1
- Bearing Type [ACSK]
- Plain
- Sheave Bearing Lubrication Method [AMWZ]
- Pressure Grease Fitting
- Tackle Accommodated Type [AMCT]
- Wire Rope
- Maximum Tackle Diameter Accommodated [AMXC]
- 0.500 Inches
- Tackle Locking Device [AMXD]
- Not Included
- Antitoppling Device [AMDC]
- Not Included
- Attachment Style [AMXF]
- Swivel Jaw And Guy Eyes
- Special Features [FEAT]
- 40.72 In. From Center Point Of Sheave To Load Bearing Surface Of Hook; Steel Construction With Plastic Shimsagavgaoe10 Davit
- End Item Identification [AGAV]
- Manufacturer Name, Hook Block Assembly
DLA Procurement Analysis 3940-01-442-9789
Management Data 3940-01-442-9789
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3940-01-442-9789
Freight Information 3940-01-442-9789
3940-01-442-9789 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127300. A Sub NMFC of X. It has a NMFC Description of PULLEY BLOCKS/TCKLE/SNATCH/FAIRLDRS. 3940-01-442-9789 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64560 which rates the freight between FCL and LCL. 3940-01-442-9789 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 793 for ocean manifesting and military sealift. 3940-01-442-9789 is not classified as a special type of cargo when transported by water. 3940-01-442-9789 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 3940-01-442-9789 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
