3443-00-723-8283
Power-Operated Punch Press
3443007238283 007238283 231
A machine which performs forming, blanking, perforating, and indenting operations on sheet metal by exerting pressure upon the material. For machines specifically designed to separate or divide the material, see SHEARING MACHINE (as modified). View more Power-Operated Punch Press
May 2023
4
Marketplace 3443-00-723-8283
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3443-00-723-8283 5+ Documents (More...)
operations on sheet metal Every Day 3443-00-723-8283 RQST Updated Every Day 3443-00-723-8283 RQST NE
231-2016 RQST NE Related Documents https//www.nsnlookup.com /fsg-34/fsc-3443/us 3443-01-231-2017 Punch
3443-01-231-2016 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-34/fsc-3443/us 3443-01-231-2016
RQST NE Updated Every Day 3443-01-231-2016 RQST Updated Every Day 3443-01-231-2016 RQST NE Related Documents
RQST NE Updated Every Day 3443-01-231-2017 RQST Updated Every Day 3443-01-231-2017 RQST NE Related Documents
3443-01-231-2017 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-34/fsc-3443/us 3443-01-231-2017
3443-01-231-2019 RQST Updated Every Day 3443-01-231-2019 RQST NE Related Documents 3443-01-231-2019
01-231-2019 RQST Updated Every Day 3443-01-231-2019 RQST https//www.nsnlookup.com /fsg-34/fsc-3443/us
Power-Operated Punch Press 3443007238283,231 www.nsnlookup.com /fsg-34/fsc-3443/us 3443-01-231-
Updated Every https Power-Operated Punch Press 3443007238283,231 2019 RQST NE Related Documents 3443-01-231
Restrictions 3443-00-723-8283
3443-00-723-8283 is a Power-Operated Punch Press that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3443-00-723-8283
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3443-00-723-8283
- MOE Rule:
- DCR3
- Effective Date:
- 1 Jul 1994
- US Air Force (F5CR)
- Effective Date:
- 1 Jul 1994
Approved Sources 3443-00-723-8283
- Part Number
- Manufacturer
- Status
- 231
- Manufacturer
- 65434 - Rw Acquisition, Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 3443-00-723-8283
- Characteristic
- Specifications
- FIIG
- Specifications
- T317-J
- Electric Motor Power Rating [ABYE]
- 2.000 Horsepower
- Bed Air Cushion [BNRG]
- Not Included
- Bed Front To Back Distance [BWKM]
- 12.000 Inches Nominal
- Bed Right To Left Distance [BWKN]
- 18.000 Inches Nominal
- Bolster Plate [BWKT]
- Included
- Current Type [ACDC]
- Ac
- Die Space [BWKS]
- 7.000 Inches Nominal
- Frequency In Hertz [FREQ]
- 60.0
- Mounting Method [AXGY]
- Floor
- Main Drive Type [BNQL]
- Electric Motor
- Pressure Capacity [AXAW]
- 20.000 Tons Nominal
- Quantity [NMBR]
- 1
- Recess Cross-Sectional Shape [BNRS]
- Round
- Recess Depth [ABMH]
- 2.000 Nominal Inches
- Recess Diameter [ABMD]
- 1.562 Inches Nominal
- Slide Recess For Punch Stem [BNRR]
- Included
- Slide Stroke Length [BWKL]
- 9.750 Inches Nominal
- Special Features [FEAT]
- 2.0 In. Stroke Length; 1.75 In Ram Adjustment; 160.0 Lb Fly Wheel; 3 V-Belt Drive; O/A Dimensions - 62.0 In. Depth; 28.0 In. Width; 66.0 In. Height; Non-Repeat Pin Type Clutch
- Phase [FAAZ]
- Three
- Voltage In Volts [ELEC]
- 220.0 Or 440.0
- Thickness [ABNM]
- 1.000 Inches Nominal
- Throat Depth [AQCL]
- 24.000 Inches Nominal
Management Data 3443-00-723-8283
Similar Supply Items to 3443-00-723-8283
Freight Information 3443-00-723-8283
3443-00-723-8283 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127160. A Sub NMFC of Z. It has a NMFC Description of PRESSES NOI. 3443-00-723-8283 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64450 which rates the freight between FCL and LCL. 3443-00-723-8283 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72E for ocean manifesting and military sealift. 3443-00-723-8283 is not classified as a special type of cargo when transported by water. 3443-00-723-8283 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
