Premium Information is available for this item - Upgrade for $1 a day
3439-01-054-9640
Welding Rod
3439010549640 010549640 AMS5837 AMS5837 0.062
A filler metal in wire or rod form used in welding where the fusing or melting heat is supplied through the medium of a gas flame or Tungsten Inert Gas welding (TIG) wherein the filler metal does not serve as a carrier for the electric current. See also ELECTRODE,WELDING. For a collection of welding rods, see WELDING ROD SET. View more Welding Rod
Managed by United States
NSN Created on 29 Jan 1978
Data Last Changed
November 2023
November 2023
NATO Update Count
28
28
NATO Data Quality
Marketplace 3439-01-054-9640
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 3439-01-054-9640 5+ Documents (More...)
AMS5837 AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing or melting
AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing or melting heat is
AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing or melting heat is
AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing or melting heat is
AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing or melting heat is
how to enable JavaScript in your web browser . 3439-99-543-0924Welding Rod3439995430924 995430924 AMS5837
AMS5837 0.046 36 IN.
,AMS5837 https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-054-9640 Welding Rod 3439010549640 010549640
AMS5837 0.046 36 IN.
,AMS5837 https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-054-9640 Welding Rod 3439010549640 010549640
AMS5837 0.125 A filler metal in wire or rod form used in welding where the fusing or melting heat is
0.046 36 IN. https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-054-9640 Welding Rod 3439010549640
010549640,AMS5837 AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing
0.046 36 IN. https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-054-9640 Welding Rod 3439010549640
010549640,AMS5837 AMS5837 0.062 A filler metal in wire or rod form used in welding where the fusing
AMS5837 0.046 36 IN.
/fsc-3439/us 3439-01-137-8523 Welding Rod 3439011378523011378523,AMS5837 AMS5837AMS5837 0.046 36 IN.
AMS5837 0.046 36 IN.
/fsc-3439/us 3439-01-137-8523 Welding Rod 3439011378523011378523,AMS5837 AMS5837AMS5837 0.046 36 IN.
AMS5837 0.046 36 IN.
Upgrade for $1 a day Upgrade your Account Upgrade 3439-01-138-7548Welding Rod3439011387548 011387548 AMS5837
https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-138-7548 Welding Rod 3439011387548011387548 AMS5837
https//www.nsnlookup.com /fsg-34/fsc-3439/uk 3439-99-543-0924 Welding Rod 3439995430924 995430924,AMS5837
https//www.nsnlookup.com /fsg-34/fsc-3439/us 3439-01-138-7548 Welding Rod 3439011387548011387548 AMS5837
https//www.nsnlookup.com /fsg-34/fsc-3439/uk 3439-99-543-0924 Welding Rod 3439995430924 995430924,AMS5837
Restrictions 3439-01-054-9640
3439-01-054-9640 is a Welding Rod that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). The precious metals content of this item is unknown.
Import and Export 3439-01-054-9640
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3439-01-054-9640
- US Air Force (FGGG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- FGCX
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTKE
- Poland (WP01)
- Effective Date:
- 1 Jan 2007
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Sep 2015
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 3439-01-054-9640
- Part Number
- Manufacturer
- Status
- AMS5837
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AMS5837
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Original Design
- Original Design
- AMS5837 0.062
- 0U583 - Sae International (Active)
- Secondary Buy
- Secondary Buy
- AMS5837 0.062
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3439-01-054-9640
- Characteristic
- Specifications
- FIIG
- Specifications
- A283A0
- Material [MATT]
- Nickel Alloy Filler
- Material Document And Classification [MDCL]
- Ams5837 Mil Std Single Material Response Filler
- Filler Metal Chemical Composition In Percent [CRPP]
- 60.00 Nickel Nominal First Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 23.00 Chromium Nominal Second Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 10.00 Molybdenum Nominal Third Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 5.00 Iron Nominal Fourth Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 1.00 Cobalt Nominal Fifth Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 0.50 Magnesium Nominal Sixth Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 0.50 Silicon Nominal Seventh Element
- Filler Metal Chemical Composition In Percent [CRPP]
- 0.10 Carbon Nominal Eighth Element
- Physical Form [AGXW]
- Straight
- Length [ABRY]
- 36.000 Inches Nominal
- Shape [SHPE]
- Round
- Outside Diameter [ABKV]
- 0.062 Inches Nominal
- Process Type For Which Designed [CSNF]
- Shielded Metal Arc
- Weld Position For Which Designed [ARSC]
- All Positions
Weapon Systems (WSDC) 3439-01-054-9640
DLA Procurement Analysis 3439-01-054-9640
- Last Stock Position:
- 100 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3439-01-054-9640
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- CO
- Subscribe
- 1
- CO
- Oct 2021
- Department of the Air Force (DF)
- CO
- Subscribe
- 1
- CO
- Oct 2020
- Department of the Air Force (DF)
- CO
- Subscribe
- 1
- CO
- Oct 2019
- Department of the Air Force (DF)
- CO
- Subscribe
- 1
- CO
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- Department of the Navy (DN)
- N
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- Defense Logistics Agency (DS)
- I
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- H
- Item that is hazardous under typical use or handling
Similar Supply Items to 3439-01-054-9640
Freight Information 3439-01-054-9640
3439-01-054-9640 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 104390. A Sub NMFC of Z. It has a NMFC Description of BARS, RODS OR WIRE, WELDING. 3439-01-054-9640 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 96520 which rates the freight between FCL and LCL. 3439-01-054-9640 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 746 for ocean manifesting and military sealift. 3439-01-054-9640 is not classified as a special type of cargo when transported by water. 3439-01-054-9640 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3439-01-054-9640
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- Any Suitable Container
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 3439-01-054-9640 1 Records
Contracting Technical Data File (CTDF) 3439-01-054-9640 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
