3439-00-262-2598
Welding Electrode
3439002622598 002622598 AWS A5.3/A5.3M AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125
A coated or uncoated filler metal or an uncoated nonfiller material in wire or solid rod form. It is used in welding where the fusing or melting heat is supplied through the medium of an electric arc wherein the rod serves as carrier of the electric current. For a collection of welding electrodes, see WELDING ELECTRODE SET. Excludes ELECTRODE, CUTTING, SOLID. View more Welding Electrode
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
November 2023
November 2023
NATO Update Count
27
27
NATO Data Quality
Marketplace 3439-00-262-2598
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 3439-00-262-2598 5+ Documents (More...)
AWS A5.3/A5.3M AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal
-99 E4043 7973A272AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or an AWS A5.3/A5.3M
AWSA5.3-80 E4043 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/32 10LB AWS A5.3/A5.3M-99
-99 E4043 7973A272AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or an AWS A5.3/A5.3M
AWSA5.3-80 E4043 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/32 10LB AWS A5.3/A5.3M-99
$1 a day Upgrade your Account Upgrade 3439-00-262-2599Welding Electrode3439002622599 002622599 AWS A5.3/A5.3M
Electrode 3439002622599002622599 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/ 32 10LB AWS A5.3/A5.3M
-99 E4043 7973A272 AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or https//www.nsnlookup.com
Electrode 3439002622599002622599 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/ 32 10LB AWS A5.3/A5.3M
-99 E4043 7973A272 AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or https//www.nsnlookup.com
$1 a day Upgrade your Account Upgrade 3439-01-139-3498Welding Electrode3439011393498 011393498 AWS A5.3/A5.3M
Welding Electrode 3439002622598 002622598 AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125
3439002622599 002622599 Account Upgrade 3439-00-262-2599Welding Electrode3439002622599 002622599 AWS A5.3/A5.3M
Welding Electrode 3439002622598 002622598 AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125
3439002622599 002622599 Account Upgrade 3439-00-262-2599Welding Electrode3439002622599 002622599 AWS A5.3/A5.3M
Upgrade your Account Upgrade 3439-00-602-5974Welding Rod3439006025974 006025974 AWSA5.3 E4043 AWS A5.3/A5.3M
Welding Electrode 3439002622598 002622598 AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125
coated or uncoated filler metal or an 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/32 10LB AWS A5.3/A5.3M
Welding Electrode 3439002622598 002622598 AWS A5.3/A5.3M-99 E4043 7973A272 AWSA5.3-80 E4043 0.125
coated or uncoated filler metal or an 0.156 5LB AWSA5.3-80 E4043 0.156 10LB MARCOLOY 500 5/32 10LB AWS A5.3/A5.3M
$1 a day Upgrade your Account Upgrade 3439-00-262-2597Welding Electrode3439002622597 002622597 AWS A5.3/A5.3M
Electrode 3439002622597002622597AWSA5.3-80 E4043 0.094MIL-E-15597 A coated or uncoated -99 E4043 7973A272
AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or an AWS A5.3/A5.3M https//www.nsnlookup.com
Electrode 3439002622597002622597AWSA5.3-80 E4043 0.094MIL-E-15597 A coated or uncoated -99 E4043 7973A272
AWSA5.3-80 E4043 0.125 A coated or uncoated filler metal or an AWS A5.3/A5.3M https//www.nsnlookup.com
Restrictions 3439-00-262-2598
3439-00-262-2598 is a Welding Electrode that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). The precious metals content of this item is unknown.
Import and Export 3439-00-262-2598
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3439-00-262-2598
- US Army (A921)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- A182
- Supplementary Receivers:
- BFCT
- US Air Force (FGGG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- FGCX
- NASA (G760)
- Effective Date:
- 1 Apr 1991
- NASA (G770)
- Effective Date:
- 1 Apr 1991
- NASA (G900)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC41)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTHD
- Spain (YB01)
- Effective Date:
- 1 Aug 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 3439-00-262-2598
- Part Number
- Manufacturer
- Status
- AWS A5.3/A5.3M
- Manufacturer
- 31505 - American Welding Society, Inc. (Active)
- Incomplete Reference
- Incomplete Reference
- AWS A5.3/A5.3M-99 E4043
- 31505 - American Welding Society, Inc. (Active)
- Primary Buy
- Primary Buy
- 7973A272
- 39428 - Mcmaster-Carr Supply Co (Active)
- Secondary Buy
- Secondary Buy
- AWSA5.3-80 E4043 0.125
- 31505 - American Welding Society, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3439-00-262-2598
- Characteristic
- Specifications
- FIIG
- Specifications
- A283A0
- Material [MATT]
- Aluminum Alloy Filler
- Material Document And Classification [MDCL]
- Awsa5.3-80,Cl E4043 Assn Std Single Material Response Filler
- Physical Form [AGXW]
- Straight
- Length [ABRY]
- 14.000 Inches Nominal
- Shape [SHPE]
- Round
- Outside Diameter [ABKV]
- 0.125 Inches Nominal
- Weld Position For Which Designed [ARSC]
- All Positions
- Current Type [ACDC]
- Dc
- Polarity Characteristic [ASBS]
- Reverse
- Flux Coating Type [ASBT]
- Shielded Arc
Weapon Systems (WSDC) 3439-00-262-2598
DLA Procurement Analysis 3439-00-262-2598
- Last Stock Position:
- 240 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3439-00-262-2598
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2023
- Department of the Navy (DN)
- CO
- Subscribe
- 1
- CO
- Oct 2022
- US Marine Corps (DM)
- CO
- Subscribe
- 1
- CO
- Oct 2021
- Defense Logistics Agency (DS)
- CO
- Subscribe
- 1
- CO
- Sep 2021
- Department of the Air Force (DF)
- CO
- Subscribe
- 1
- CO
- Oct 2020
- US Marine Corps (DM)
- CO
- Subscribe
- 1
- CO
- Oct 2019
- Department of the Air Force (DF)
- CO
- Subscribe
- 1
- CO
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- Department of the Air Force (DF)
- F
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- US Marine Corps (DM)
- M
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- Department of the Navy (DN)
- N
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
- Defense Logistics Agency (DS)
- I
- K
- U/I Contains 10 Lb
- 00000000010LB
- K
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- H
- Item that is hazardous under typical use or handling
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 3439-00-262-2598
Freight Information 3439-00-262-2598
3439-00-262-2598 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 104390. A Sub NMFC of Z. It has a NMFC Description of BARS, RODS OR WIRE, WELDING. 3439-00-262-2598 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 96520 which rates the freight between FCL and LCL. 3439-00-262-2598 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 746 for ocean manifesting and military sealift. 3439-00-262-2598 is not classified as a special type of cargo when transported by water. 3439-00-262-2598 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3439-00-262-2598
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Waterproof Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 3439-00-262-2598 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- K
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
