3439-00-061-2898

Welding Electrode

3439000612898 000612898 AWSA5.1-78 E6027 0.250 AWS A5.1/A5.1M JETWELD 2 1/4 HOBART NO. 27 1/4 A-A-51151 AWSA5.1-12 E6027 0.250 AIRCO 6027 1/4 QQ-E-450 AP6027IP 1/4 SW-27 1/4

A coated or uncoated filler metal or an uncoated nonfiller material in wire or solid rod form. It is used in welding where the fusing or melting heat is supplied through the medium of an electric arc wherein the rod serves as carrier of the electric current. For a collection of welding electrodes, see WELDING ELECTRODE SET. Excludes ELECTRODE, CUTTING, SOLID. View more Welding Electrode

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
August 2023

NATO Update Count
7

NATO Data Quality

3439-00-061-2898 ELECTRODE,WELDING 3439000612898 000612898 1/1 — 3439-00-061-2898 Photo 1/1

Marketplace 3439-00-061-2898

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

QQ-E-450 ELECTRODE,WELDING 14 CO NS

Subscribe to View Vendor Details...

QQ-E-450 ELECTRODE,WELDING 1 CO NS

Updated Every 15 Minutes

3439-00-061-2898 BUY NE

Updated Every Day

3439-00-061-2898 RQST NE

Updated Every Day

3439-00-061-2898 RQST

Updated Every Day

3439-00-061-2898 RQST NE

Restrictions 3439-00-061-2898

3439-00-061-2898 is a Welding Electrode that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.

Import and Export 3439-00-061-2898

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3439-00-061-2898

US Army (A921)
Effective Date:: 1 Jul 2006
Former MOE Rule:: A182; AMC 1 AMSC G IMC Z IMCACTY BF

US Air Force (FGGG)
Effective Date:: 1 Jul 2006
Former MOE Rule:: FGCX; AMC 1 AMSC G IMC Z IMCACTY TG

US Navy (N9BG)
Effective Date:: 1 Dec 2013
Supplementary Collaborators:: GG; AMC 1 AMSC G IMC Z IMCACTY GH

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Approved Sources 3439-00-061-2898

Part Number
Manufacturer
Status
AWSA5.1-78 E6027 0.250: 31505 - American Welding Society, Inc. (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC E
AWS A5.1/A5.1M: 31505 - American Welding Society, Inc. (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC 5
JETWELD 2 1/4: 36232 - Lincoln Electric Holdings Inc (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC 5
HOBART NO. 27 1/4: 28835 - Hobart Bros Co (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC 5
AWSA5.1-12 E6027 0.250: 31505 - American Welding Society, Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
A-A-51151: 58536 - Federal Commercial Item Description (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
AIRCO 6027 1/4: 52111 - Airco Welding Products Div Of The (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
QQ-E-450: 81348 - Federal Specifications Promulgated (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
AP6027IP 1/4: 00742 - Air Products & Chemicals, Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
SW-27 1/4: 84021 - The Esab Group Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5

Datasheet 3439-00-061-2898

Characteristic
Specifications
FIIG: A283A0
Current Type [ACDC]: Ac Or Dc
Flux Coating Type [ASBT]: Shielded Arc
Nondefinitive Spec/Std Data [ZZZT]: 2 Class And Mil-6027 Type
Outside Diameter [ABKV]: 0.250 Inches Nominal
Material [MATT]: Steel Filler
Length [ABRY]: 18.000 Inches Nominal
Material Document And Classification [MDCL]: Awsa5.1-78,Cl E6027 Assn Std Single Material Response Filler
Polarity Characteristic [ASBS]: Reverse Or Straight
Shape [SHPE]: Round
Physical Form [AGXW]: Straight
Weld Position For Which Designed [ARSC]: Horizontal

Subscribe
View Data

DLA Procurement Analysis 3439-00-061-2898

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3439-00-061-2898

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Defense Logistics Agency (DS); CO; Subscribe; 1
Oct 2021: Department of the Navy (DN); CO; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); CO; Subscribe; 1
Oct 2019: Department of the Air Force (DF); CO; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): A; K; U/I Contains 10 Lb; 00000000010LB
Department of the Air Force (DF): F; K; U/I Contains 10 Lb; 00000000010LB
Department of the Navy (DN): N; K; U/I Contains 10 Lb; 00000000010LB
Defense Logistics Agency (DS): I; K; U/I Contains 10 Lb; 00000000010LB

Army

Materiel Category and Inventory Manager:

E: General Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 3439-00-061-2898

Freight Information 3439-00-061-2898

3439-00-061-2898 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 104390. A Sub NMFC of Z. It has a NMFC Description of BARS, RODS OR WIRE, WELDING. 3439-00-061-2898 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 96520 which rates the freight between FCL and LCL. 3439-00-061-2898 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 746 for ocean manifesting and military sealift. 3439-00-061-2898 is not classified as a special type of cargo when transported by water. 3439-00-061-2898 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3439-00-061-2898

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; Special requirement – See specific instructions or drawings provided; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Contracting Technical Data File (CTDF) 3439-00-061-2898 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: N

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
