3415-01-212-6467 is a Utility Grinding Machine that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 3415-01-212-6467

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3415-01-212-6467

US Air Force (FGGG)
Effective Date:: 1 Jul 2006
Former MOE Rule:: FGCX; AMC 3 AMSC D IMC Z IMCACTY TG

US Navy (N9BG)
Effective Date:: 1 Jul 2006
Former MOE Rule:: N9GD
Supplementary Collaborators:: HD; AMC 3 AMSC D IMC Z IMCACTY HD

Canada (ZC01)
Effective Date:: 1 Feb 2009

Approved Sources 3415-01-212-6467

Part Number
Manufacturer
Status
500: 05472 - Baldor Electric Co (Replaced); Original Design; RNCC 3 RNVC 9 DAC E
00781568127339: 46UR5 - Abb Motors & Mechanical Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
500: 46UR5 - Abb Motors & Mechanical Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
00781568127339: 05472 - Baldor Electric Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC U

Datasheet 3415-01-212-6467

Characteristic
Specifications
FIIG: T284-A
Mounting Type For Which Designed [BCNX]: Bench
Spindle End Type [BMYP]: Double
Spindle Diameter [AHDQ]: 0.750 Inches Nominal
Spindle Speed In Rpm [BMYR]: 3600.0 Nominal
Maximum Wheel Diameter Accommodated [BMYS]: 6.000 Inches
Maximum Wheel Thickness Accommodated [BMYT]: 1.500 Inches
Power Source [ATJK]: Electric Motor
Quantity [NMBR]: 1
Horsepower Rating [ANCY]: 0.5
Current Type [ACDC]: Ac
Voltage In Volts [ELEC]: 115.0
Frequency In Hertz [FREQ]: 60.0
Phase [FAAZ]: Single

Weapon Systems (WSDC) 3415-01-212-6467

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 3415-01-212-6467

Last Stock Position:: 1 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3415-01-212-6467

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 3415-01-212-6467

Freight Information 3415-01-212-6467

3415-01-212-6467 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 3415-01-212-6467 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 3415-01-212-6467 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72E for ocean manifesting and military sealift. 3415-01-212-6467 is not classified as a special type of cargo when transported by water. 3415-01-212-6467 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3415-01-212-6467

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Electrical Instrument; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Procurement History 3415-01-212-6467 7 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE8E516M1500: 16 May 2016; Subscribe; 6; Subscribe; Subscribe
SPE8E516M1316: 15 Apr 2016; Subscribe; 1; Subscribe; Subscribe
SPE8E516V1219: 24 Feb 2016; Subscribe; 1; Subscribe; Subscribe
SPE8E516V0976: 02 Feb 2016; Subscribe; 1; Subscribe; Subscribe
SPE8E515M3248: 04 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE8E515V2051: 31 Jul 2015; Subscribe; 1; Subscribe; Subscribe
SPE8E515V1261: 14 Apr 2015; Subscribe; 1; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 3415-01-212-6467 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: J

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 3415-01-212-6467

Related Documents 3415-01-212-6467 2+ Documents (More...)

Restrictions 3415-01-212-6467
