3415-00-727-2322
Reciprocating Surface Grinding Machine
3415007272322 007272322 C 3415-4101-1804
May 2023
10
Marketplace 3415-00-727-2322
Request a Quotation from participating marketplace vendors
Related Documents 3415-00-727-2322 5+ Documents (More...)
Update Count 10 NATO Data Quality 3415-00-727-2322 Photo 1/2 3415-00-727-2322 Photo 2/2 - - 1.
C GRINDING MACHINE,SURFACE,RECIPROCATING 6 EA NS Request Quotation Updated Every Day 3415-00-727-2322
/fsg-34/fsc-3415/us
Reciprocating Surface Grinding Machine,C Request Quotation Updated Every Day 3415-00-727-2322 https
//www.nsnlookup.com /fsg-34/fsc-3415/us 3415-01-419-2210 Reciprocating Surface Grinding Machine,C Request
Restrictions 3415-00-727-2322
3415-00-727-2322 is a Reciprocating Surface Grinding Machine that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3415-00-727-2322
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3415-00-727-2322
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 3415-00-727-2322
- Part Number
- Manufacturer
- Status
- C
- Manufacturer
- 63971 - Waterbury Farrell Div Of Textron Inc (Obsolete)
- Original Design
- Original Design
- 3415-4101-1804
- 99998 - Defense Supply Center Richmond (Active)
- NATO Reference
- NATO Reference
Datasheet 3415-00-727-2322
- Characteristic
- Specifications
- FIIG
- Specifications
- T284-C
- Current Type [ACDC]
- Ac
- Frequency In Hertz [FREQ]
- 60.0
- Head Cross Travel [BPSY]
- 18.000 Inches Nominal
- Head Feed Type [BPSZ]
- Power
- Head Vertical Adjustment [BPSX]
- 28.000 Inches Nominal
- Horsepower Rating [ANCY]
- 30.0
- Maximum Distance From Spindle Center/End To Work Surface Top [BPTB]
- 38.000 Inches
- Mounting Type For Which Designed [BCNX]
- Floor
- Power Source [ATJK]
- Electric Motor
- Phase [FAAZ]
- Three
- Voltage In Volts [ELEC]
- 220.0
- Wheel Maximum Diameter [BNBW]
- 20.000 Inches
- Work Surface Feed Method [BPST]
- Power
- Work Surface Length [BPSK]
- 48.000 Inches Nominal
- Work Surface Longitudinal Travel [BPSP]
- 56.000 Inches Nominal
- Work Surface Width [BPSM]
- 18.000 Inches Nominal
- Spindle Diameter [AHDQ]
- 6.000 Inches Nominal
- Spindle Position [BPSG]
- Horizontal
NATO Stock Numbers Related to 3415-00-727-2322
Freight Information 3415-00-727-2322
3415-00-727-2322 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 3415-00-727-2322 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 3415-00-727-2322 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 72E for ocean manifesting and military sealift. 3415-00-727-2322 is classified as a Protected/Sensitive Non-Hazardous Non-ESD Commodity when transported by water. 3415-00-727-2322 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3415-00-727-2322
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 156.0" H x 96.0" W x 108.0" L
- --
- --
- --
- Special Requirements
- 156.0" H x 96.0" W x 108.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
