3413-01-353-4818
Upright Drilling Machine
3413013534818 013534818 354170 354166
A drilling machine with vertical single or multiple spindle(s). View more Upright Drilling Machine
November 2023
9
Marketplace 3413-01-353-4818
Request a Quotation from participating marketplace vendors
Related Documents 3413-01-353-4818 5+ Documents (More...)
/fsg-34/fsc-3413/us
354166 RQST NE Updated Every Day 3413-01-353-4818 RQST NE Updated Every Day 3413-01-353-4818 RQST Updated
Photo 1/4 3413-01-353-4818 Photo 2/4 3413-01-353-4818 Photo 3/4 3413-01-353-4818 Photo 4/4 - - 354166
354170 View Vendor Details... 354166 https//www.nsnlookup.com /fsg-34/fsc-3413/us 3413-01-353-4818 Upright
013534818 354170 354166 Request a Quotation from participating marketplace vendors Request Subscribe
-4320/ca 4320-21-000-8132 Upgrade 3413-01-353-4818Upright Drilling Machine3413013534818 013534818 354170
https//www.nsnlookup.com /fsg-34/fsc-3413/us 3413-01-353-4818 Upright Drilling Machine 3413013534818
JavaScript in your web browser . 6680-14-290-1788Tachometer Generator6680142901788 142901788PVC1500-354170
Upright Drilling Machine 3413013534818 www.nsnlookup.com /fsg-34/fsc-3413/us 3413-01-353-4818 https
to enable JavaScript in your web browser . 5955-15-190-7884Quarzo5955151907884 151907884HC6UHCS29-354166
Upright Drilling Machine 3413013534818 participating marketplace vendors Request Subscribe https
Restrictions 3413-01-353-4818
3413-01-353-4818 is a Upright Drilling Machine that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3413-01-353-4818
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3413-01-353-4818
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
Approved Sources 3413-01-353-4818
- Part Number
- Manufacturer
- Status
- 354170
- Manufacturer
- 3ZFY8 - Jpw Industries Inc. (Active)
- Primary Buy
- Primary Buy
- 354170
- 60985 - Jet Equipment & Tools Inc (Replaced)
- Original Design
- Original Design
- 354166
- 60985 - Jet Equipment & Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3413-01-353-4818
- Characteristic
- Specifications
- FIIG
- Specifications
- T317-F
- Drill Chuck Size Accommodated [BNSC]
- 3/4 In. Keys
- Drilling Capability [BNRY]
- 1.000 In. Drilling Capacity
- Base Working Surface Type [BNSF]
- Slotted
- Column Type [BNRZ]
- Round
- Current Type [ACDC]
- Ac
- Feed Type [AQDD]
- Power
- Frequency In Hertz [FREQ]
- 60.0
- Head Type [AJGD]
- Radial Swinging/Sliding
- Mounting Type [AAXX]
- Floor
- Main Drive Type [BNQL]
- Electric Motor
- Phase [FAAZ]
- Single
- Voltage In Volts [ELEC]
- 115.0 Or 230.0
- Spindle Speed Quantity [BTSZ]
- 12
- Spindle Speed Range In Rpm [BTTB]
- +180.0/+4200.0
- Spindle Travel Distance [BNRL]
- 4.625 Inches Nominal
- Spindle Type [BQLR]
- Threaded End For Drill Chuck
Weapon Systems (WSDC) 3413-01-353-4818
DLA Procurement Analysis 3413-01-353-4818
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3413-01-353-4818
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3413-01-353-4818
Freight Information 3413-01-353-4818
3413-01-353-4818 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 131670. A Sub NMFC of Z. It has a NMFC Description of TOOLS PWR O/T PWR HND TOOLS. 3413-01-353-4818 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61060 which rates the freight between FCL and LCL. 3413-01-353-4818 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 3413-01-353-4818 is not classified as a special type of cargo when transported by water. 3413-01-353-4818 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3413-01-353-4818
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 3413-01-353-4818 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE8E518V2298
- 18 Apr 2018
- Subscribe
- 7
- Subscribe
- Subscribe
- Subscribe
- SPE8E517V0288
- 27 Oct 2016
- Subscribe
- 6
- Subscribe
- Subscribe
- Subscribe
- SPE8E516M1058
- 29 Feb 2016
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
- SPE8E516V0600
- 17 Dec 2015
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE8E516V0243
- 04 Nov 2015
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE8E516V0003
- 01 Oct 2015
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
- SPE8E515V0920
- 23 Feb 2015
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
- SPE8E515V0509
- 06 Dec 2014
- Subscribe
- 1
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 3413-01-353-4818 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
