3120-01-162-9812
Sleeve Bearing Half
3120011629812 011629812 B488800
A half of a two-piece split type BEARING, SLEEVE. View more Sleeve Bearing Half
May 2023
4
Marketplace 3120-01-162-9812
Request a Quotation from participating marketplace vendors
Related Documents 3120-01-162-9812 2+ Documents (More...)
RQST NE Updated Every Day 3120-01-162-9812 RQST Updated Every Day 3120-01-162-9812 RQST NE Related Documents
3120-01-162-9812 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-31/fsc-3120/us 3120-01-162-9812
www.nsnlookup.com /fsg-31/fsc-3120/uk 3120-99-647-1720 Sleeve Bushing Half 3120996471720996471720 B488800
Sleeve Bearing Half 3120011629812 011629812 $1 a day Upgrade your Account Upgrade 3120-01-162-9812Sleeve
Restrictions 3120-01-162-9812
3120-01-162-9812 is a Sleeve Bearing Half that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3120-01-162-9812
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3120-01-162-9812
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- KE
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
Approved Sources 3120-01-162-9812
- Part Number
- Manufacturer
- Status
- B488800
- Manufacturer
- K0378 - Rolls-Royce Plc (Active)
- Primary Buy
- Primary Buy
Datasheet 3120-01-162-9812
- Characteristic
- Specifications
- FIIG
- Specifications
- A045A0
- Body Inside Diameter [ADAS]
- 14.50 Millimeters Minimum And 14.625 Millimeters Maximum
- Body Outside Diameter [ADAR]
- 23.875 Millimeters Minimum And 24.000 Millimeters Maximum
- Corner Shape [BZLX]
- Chamfered Outside Left Corner
- Corner Shape [BZLX]
- Chamfered Outside Right Corner
- Corner Shape [BZLX]
- Round Left Flange Body Corner
- Corner Shape [BZLX]
- Round Right Flange Body Corner
- Corner Shape [BZLX]
- Square Inside Right Corner
- Corner Shape [BZLX]
- Square Inside Left Corner
- Corner Shape [BZLX]
- Square Left Flange Outside Right Corner
- Corner Shape [BZLX]
- Square Right Flange Outside Left Corner
- Material [MATT]
- Aluminum Alloy Overall
- Style Designator [STYL]
- Half Sleeve, External Flanges Both Ends, Internal Flange At Both Ends
- Left Internal Flange Width [AGFK]
- 4.5 Millimeters Nominal
- Left Flange Outside Diameter [AGFQ]
- 29.0 Millimeters Nominal
- Left Flange Width [AGFS]
- 2.5 Millimeters Nominal
- Left Internal Flange Hole Diameter [AGFH]
- 13.500 Millimeters Minimum And 13.625 Millimeters Maximum
- Material Document And Classification [MDCL]
- L65,Fscm K0378 Mfr Ref Single Material Response Overall
- Right Flange Outside Diameter [AGFR]
- 29.0 Millimeters Nominal
- Right Flange Width [AGFT]
- 2.5 Millimeters Nominal
- Right Internal Flange Hole Diameter [AGFJ]
- 13.500 Millimeters Minimum And 13.625 Millimeters Maximum
- Right Internal Flange Width [AGFL]
- 4.5 Millimeters Nominal
- Overall Length [ABHP]
- 14.0 Millimeters Nominal
- Chamfer Length [AAZP]
- Unable To Decode
- Radius [ABGG]
- Unable To Decode
- Chamfer Angle [CSYT]
- Unable To Decode
- Surface Finish [CSYM]
- 63.0 Microinches Overall
- Surface Treatment [SFTT]
- Anodize Overall
DLA Procurement Analysis 3120-01-162-9812
Management Data 3120-01-162-9812
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3120-01-162-9812
Freight Information 3120-01-162-9812
3120-01-162-9812 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 114870. A Sub NMFC of X. It has a NMFC Description of BEARING/BUSHING METAL. 3120-01-162-9812 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58890 which rates the freight between FCL and LCL. 3120-01-162-9812 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3120-01-162-9812 is not classified as a special type of cargo when transported by water. 3120-01-162-9812 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3120-01-162-9812
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
