3120-00-678-3230
Sleeve Bearing Half Set
3120006783230 006783230 5702616
Two or more identical or different sizes or types of BEARING HALF, SLEEVE packaged or grouped together for single issue as a unit, for replacement of worn and/or damaged bearings. See BEARING HALF, SLEEVE. Excludes BEARING SET, SLEEVE. View more Sleeve Bearing Half Set
June 2025
30
Product Information 3120-00-678-3230
Main Crankshaft Bearing Shell Set for AVDS-1790-2 Series Engine
Size: Standard
Piece Count: 14 Pieces
Kit Contents:
- 1 EA 8724996 Bearing Half with Thrust Bearing
- 6 EA 8724987 Bearing Half Main Journal
- 6 EA 8724986 Bearing Half Main Journal
- 1 EA 8724995 Bearing Halfwith Thrust Bearing
Marketplace 3120-00-678-3230
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3120-00-678-3230 1+ Documents (More...)
United States (US) 4. 3120-00-678-3230 Marketplace Restrictions Approved Sources Datasheet Management
BEARING HALF SET,SLEEVE 83 EA NS Request Quotation 5702616 BEARING HALF SET,SLEEVE 1 EA NS Request
Restrictions 3120-00-678-3230
3120-00-678-3230 is a Sleeve Bearing Half Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3120-00-678-3230
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3120-00-678-3230
- US Army (A919)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZ
- US Air Force (FGGG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FGCX
- US Marine Corps (MC41)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Sep 2011
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jul 1995
- Turkey (ZW01)
- Effective Date:
- 1 Jan 2002
Approved Sources 3120-00-678-3230
- Part Number
- Manufacturer
- Status
- 5702616
- Manufacturer
- 02978 - Renk America Llc (Active)
- Primary Buy
- Primary Buy
- 5702616
- 5F475 - Miba Bearings Us Llc (Active)
- Primary Buy
- Primary Buy
- 5702616
- R1120 - Satair A/S (Active)
- Secondary Buy
- Secondary Buy
- 5702616
- 3NNX8 - Brighton Cromwell Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 3120006783230
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 5702616
- 19207 - U S Army Tank Automotive Command (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 3120-00-678-3230
- Characteristic
- Specifications
- FIIG
- Specifications
- A23800
- Component Quantity [AJJW]
- 14
- Component Document Origin [AJJX]
- Government
- Document Source [AJJY]
- 19207
- Document Type [AJJZ]
- Package List
- Document Identification [AYDR]
- 5702616
- Component Document Page Number [AJKB]
- 2-24
Weapon Systems (WSDC) 3120-00-678-3230
DLA Procurement Analysis 3120-00-678-3230
- Last Stock Position:
- 42 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3120-00-678-3230
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2023
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Jan 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- JT
- Tanks
Recovery Vehicle, M51/M74/M88
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 3120-00-678-3230
Freight Information 3120-00-678-3230
3120-00-678-3230 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114850. A Sub NMFC of X. It has a NMFC Description of BEARING/BUSHING O/T BALL/ROLLER I/S. 3120-00-678-3230 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. 3120-00-678-3230 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 58880 which rates the freight between FCL and LCL. 3120-00-678-3230 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3120-00-678-3230 is not classified as a special type of cargo when transported by water. 3120-00-678-3230 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3120-00-678-3230
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 6.0" H x 6.0" W x 4.0" L
- --
- --
- --
- Any Suitable Process
- 6.0" H x 6.0" W x 4.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 3120-00-678-3230 13 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623F6302P00001
- 19 Jan 2023
- Subscribe
- 225
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F6302
- 19 Jan 2023
- Subscribe
- 225
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F6302P00001
- 19 Jan 2023
- Subscribe
- 225
- Subscribe
- Subscribe
- Subscribe
- SPE4A622P6831
- 13 Dec 2021
- Subscribe
- 25
- Subscribe
- Subscribe
- Subscribe
- SPE4A622P6831P00002
- 13 Dec 2021
- Subscribe
- 27
- Subscribe
- Subscribe
- Subscribe
- SPE4A621PH458
- 26 Apr 2021
- Subscribe
- 85
- Subscribe
- Subscribe
- Subscribe
- SPE4A617P6223
- 23 Jan 2017
- Subscribe
- 75
- Subscribe
- Subscribe
- Subscribe
- SPE4A717P3316
- 15 Dec 2016
- Subscribe
- 394
- Subscribe
- Subscribe
- Subscribe
- SPE4A617V1793P00003
- 25 Oct 2016
- Subscribe
- 65
- Subscribe
- Subscribe
- Subscribe
- SPE4A616MF849
- 30 Jun 2016
- Subscribe
- 183
- Subscribe
- Subscribe
- Subscribe
- SPE7L016M1702
- 29 Mar 2016
- Subscribe
- 19
- Subscribe
- Subscribe
- Subscribe
- SPE4A616MA241P00001
- 23 Mar 2016
- Subscribe
- 137
- Subscribe
- Subscribe
- Subscribe
- SPE4A616M2249P00002
- 04 Nov 2015
- Subscribe
- 240
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 3120-00-678-3230 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
