3120-00-182-8635
Self-Aligning Plain Bearing
3120001828635 001828635 15SF24X8 4808387 EA46743
A detachable assembly in or on which a journal, gudgeon, pivot, or the like moves. It is used to carry a load and to reduce sliding friction. It does not employ rolling elements. The item consists of a bored precision ground ball (or spherical plain bearing) around which an outer ring is fitted. The assembly may be either separable or nonseparable. Excludes BEARING, PLAIN, ROD END and BEARING, PLAIN, SPHERICAL. View more Self-Aligning Plain Bearing
August 2023
3
Marketplace 3120-00-182-8635
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3120-00-182-8635 5+ Documents (More...)
Photo 1/4 3120-00-182-8635 Photo 2/4 3120-00-182-8635 Photo 3/4 NSN 3120-00-182-8635 (Identification
Every Day 15SF24X8 RQST NE Updated Every Day EA46743 RQST NE Updated Every Day 3120-00-182-8635 RQST
Self-Aligning Plain Bearing 3120001828635 RQST NE Updated Every Day 3120-00-182-8635 RQST https
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 3120-00-182-8635
Restrictions 3120-00-182-8635
3120-00-182-8635 is a Self-Aligning Plain Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3120-00-182-8635
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3120-00-182-8635
- US Army (A919)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- A180
- Supplementary Receivers:
- AZ
- US Air Force (FGGG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- FGCX
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Supplementary Collaborators:
- HD
Approved Sources 3120-00-182-8635
- Part Number
- Manufacturer
- Status
- 15SF24X8
- Manufacturer
- 21335 - Timken Co (Active)
- Primary Buy
- Primary Buy
- 4808387
- 0AHU0 - Kalmar Ac Inc (Active)
- Secondary Buy
- Secondary Buy
- EA46743
- 60380 - Timken Aerospace, Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 15SF24X8
- 60380 - Timken Aerospace, Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3120-00-182-8635
- Characteristic
- Specifications
- FIIG
- Specifications
- A045A0
- Bore Diameter [ABXV]
- 1.5003 Inches Minimum And 1.5008 Inches Maximum
- Hardness Rating [CQFM]
- 55.0 Rockwell C Minimum Inner Member And 57.0 Rockwell C Maximum Inner Member
- Material [MATT]
- Steel Inner Member
- Material [MATT]
- Steel Outer Race Member
- Outer Member Outside Diameter [AGGF]
- 2.4370 Inches Minimum And 2.4375 Inches Maximum
- Outer Member Width [AGGH]
- 1.1200 Inches Minimum And 1.1250 Inches Maximum
- Inner Member Width [AGGJ]
- 1.3070 Inches Minimum And 1.3120 Inches Maximum
- Lubrication Feature [CTLM]
- Groove External Inner Member
- Lubrication Feature [CTLM]
- Groove External Outer Member
- Lubrication Feature [CTLM]
- Perforation Outer Race Member
- Lubrication Material [ADZG]
- Dry Film Molybdenum Disulfide
- Special Features [FEAT]
- Fractured /One Place Only/ Outer Race Member
- Style Designator [STYL]
- Without Insert Or Liner
- Surface Treatment [SFTT]
- Phosphate Inner Member
DLA Procurement Analysis 3120-00-182-8635
Management Data 3120-00-182-8635
Army
- Materiel Category and Inventory Manager:
- T
- Industrial Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3120-00-182-8635
Freight Information 3120-00-182-8635
3120-00-182-8635 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 114850. A Sub NMFC of X. It has a NMFC Description of BEARING/BUSHING O/T BALL/ROLLER I/S. 3120-00-182-8635 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58880 which rates the freight between FCL and LCL. 3120-00-182-8635 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3120-00-182-8635 is not classified as a special type of cargo when transported by water. 3120-00-182-8635 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3120-00-182-8635
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 3120-00-182-8635 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
