3110-01-585-6966
Tapered Roller Bearing
3110015856966 015856966 11628998
A cylindrical device in which the inner cone or outer cup turns upon a single or double row of tapered hardened rollers which roll easily in a race, thus minimizing friction and designed to carry a radial load and capable of sustaining axial thrust. Excludes BEARING, ROLLER, THRUST. View more Tapered Roller Bearing
January 2023
1
Marketplace 3110-01-585-6966
Request a Quotation from participating marketplace vendors
Related Documents 3110-01-585-6966 3+ Documents (More...)
3110-01-585-6966 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-01-585-6966
Tapered Roller Bearing 3110015856966 11628998 A cylindrical device in which the inner cone or outer
011381374.3110 CONE AND ROLLERS,TAPERED ROLLER BEARING 1 EA NS Request Quotation Updated Every Day 11628998
3110-01-138-1374 2+ Documents ( More... ) https https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-01-585-6966
-1 CUP,TAPERED ROLLER BEARING 12 EA NS Request Quotation Subscribe to View Vendor Details... 11628998
-1 CUP,TAPERED ROLLER BEARING 21 EA NS Request Quotation Updated Every Day 11628998-1 RQST NE Updated
Restrictions 3110-01-585-6966
3110-01-585-6966 is a Tapered Roller Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-01-585-6966
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-01-585-6966
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jun 2010
Approved Sources 3110-01-585-6966
- Part Number
- Manufacturer
- Status
- 11628998
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 3110-01-585-6966
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Backface Corner Radius [AGWU]
- 0.1300 Inches Nominal
- Bore Diameter [ABXV]
- 3.6250 Inches Minimum And 3.6260 Inches Maximum
- Cone Corner Radius [AGWW]
- 0.1400 Inches Nominal
- Cone Width [AGWX]
- 1.3750 Inches Nominal
- Cup Width [AGWY]
- 1.0313 Inches Nominal
- Material [MATT]
- Steel Cage
- Material [MATT]
- Steel Comp 8720 Cone
- Material [MATT]
- Steel Comp 4720 Roller
- Material [MATT]
- Steel Comp 4720 Cup
- Overall Outside Diameter [ADGA]
- 5.7500 Inches Minimum And 5.7510 Inches Maximum
- Overall Width [ABMK]
- 1.3125 Inches Minimum And 1.3205 Inches Maximum
- Standout Width [AGWV]
- 0.2812 Inches Nominal
- Style Designator [STYL]
- Straight Bore, Keyway Cone, Normal Angle
Similar Supply Items to 3110-01-585-6966
Freight Information 3110-01-585-6966
3110-01-585-6966 has freight characteristics managed by the Republic of Korea.. 3110-01-585-6966 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
