3110-01-203-1707
Cylindrical Roller Bearing
3110012031707 012031707 MR1908C102 9341M38P02 9341M38P04 MR1908C101 9341M38P01
A nonadjustable roller bearing consisting of a single or multiple-row of hardened cylindrical rollers and a retainer used with or without inner or oute r rings. Excludes BEARING, ROLLER, AIRFRAME. View more Cylindrical Roller Bearing
November 2023
14
Marketplace 3110-01-203-1707
Request a Quotation from participating marketplace vendors
Related Documents 3110-01-203-1707 2+ Documents (More...)
NE Updated Every Day 9341M38P02 RQST NE Updated Every Day MR1908C101 RQST NE Updated Every Day 3110-01
/us 3110-01-203-1707 Cylindrical Roller Bearing 3110012031707 MR1908C1029341M38P029341M38P049341M38P01MR1908C101
Cylindrical Roller Bearing 3110012031707 RQST Updated Every Day 3110-01-203-1707 RQST NE https/
AssyUOMTechnical DocumentQuantative ExpressionDefense Logistics Agency (DS)IZDiscontinued-Use 3110-01-203-1707
Restrictions 3110-01-203-1707
3110-01-203-1707 is a Cylindrical Roller Bearing that is an aviation critical safety item or flight safety critical aircraft part. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-01-203-1707
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-01-203-1707
- US Air Force (FXGG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- KE
- Poland (WP01)
- Effective Date:
- 1 May 2007
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2008
- Greece (ZU01)
- Effective Date:
- 1 May 2008
Approved Sources 3110-01-203-1707
- Part Number
- Manufacturer
- Status
- 9341M38P02
- Manufacturer
- 07482 - General Electric Company (Active)
- Source Control
- Source Control
- 9341M38P02
- 38443 - Skf Usa Inc. (Active)
- Primary Buy
- Primary Buy
- MR1908C102
- 38443 - Skf Usa Inc. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 9341M38P04
- 07482 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- MR1908C101
- 38443 - Skf Usa Inc. (Active)
- Transferred
- Transferred
- 9341M38P01
- 07482 - General Electric Company (Active)
- Transferred
- Transferred
Datasheet 3110-01-203-1707
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- End Item Identification [AGAV]
- Acft Eng F-110
- Bore Diameter [ABXV]
- 1.5746 Inches Minimum And 1.5748 Inches Maximum
- Bore Shape [AGZD]
- Straight
- Material [MATT]
- Steel Comp 4340 Cage
- Material [MATT]
- Steel Inner Ring
- Material [MATT]
- Steel Outer Ring
- Material [MATT]
- Steel Roller
- Outer Ring Width [AGVT]
- 0.5374 Inches Minimum And 0.5524 Inches Maximum
- Inner Ring Width [AGVU]
- 0.4674 Inches Minimum And 0.4724 Inches Maximum
- Internal Clearance [AKVV]
- 0.0012 Inches Minimum Radial And 0.0018 Inches Maximum Radial
- Locating Feature [AGZF]
- Nonlocating
- Material Document And Classification [MDCL]
- Ams-6359 Assn Std 1St Material Response Cage
- Material Document And Classification [MDCL]
- Ams-6491 Assn Std 3Rd Material Response Outer Ring
- Material Document And Classification [MDCL]
- Ams-6491 Assn Std 4Th Material Response Roller
- Material Document And Classification [MDCL]
- Ams-6491 Fed Std 2Nd Material Response Inner Ring
- Retainer Fabrication Method [AGYF]
- Machined
- Overall Outside Diameter [ADGA]
- 3.7000 Inches Minimum And 3.7200 Inches Maximum
- Special Features [FEAT]
- Silver Plate Cage 0.001-0.002 Thk Per Ams 2412 On Functional Rubbing Contact Surfaces;Outer Ring Is Extended In 4 Places To Provide Mounting Tabs,Each Tab 0.5800 In. Min 0.6200 In. Max Wide,Each Tab Has A Drilled Hole 0.274 In. Diam Min 0.283 In. Diam Max
- Standard Tolerance Designation [CTFZ]
- Rbec No.5
- Style Designator [STYL]
- Cylindrical Inner Ring, One Lip Outer Ring, Separable
- Surface Finish [AGYE]
- Ground
Weapon Systems (WSDC) 3110-01-203-1707
DLA Procurement Analysis 3110-01-203-1707
- Last Stock Position:
- 9 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3110-01-203-1707
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- PR
- F11O GE 100 ENGINE
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3110-01-203-1707
Freight Information 3110-01-203-1707
3110-01-203-1707 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-01-203-1707 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 3110-01-203-1707 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-01-203-1707 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-01-203-1707 is not classified as a special type of cargo when transported by water. 3110-01-203-1707 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-01-203-1707
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 3110-01-203-1707 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
