3110-00-581-2719
Cylindrical Roller Bearing
3110005812719 005812719 9272M55 9671M26P09 9272M55P01 AAVF9233RON-101 1538M14P01 R1834E107 5RUH1834-7 464618 9671M26P08
A nonadjustable roller bearing consisting of a single or multiple-row of hardened cylindrical rollers and a retainer used with or without inner or oute r rings. Excludes BEARING, ROLLER, AIRFRAME. View more Cylindrical Roller Bearing
Managed by United States
NSN Created on 19 Dec 1974
Data Last Changed
May 2023
May 2023
NATO Update Count
20
20
NATO Data Quality
Marketplace 3110-00-581-2719
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 3110-00-581-2719 5+ Documents (More...)
9272M55 9671M26P09 9272M55P01 AAVF9233RON-101 1538M14P01 R1834E107 5RUH1834-7 464618 9671M26P08 A nonadjustable
Every Day 9671M26P09 RQST NE Updated Every Day 3110-00-581-2719 RQST NE Updated Every Day 3110-00-581
A nonadjustable Every Day 9671M26P09 RQST NE Updated Every Day 3110-00-581-2719 RQST NE Updated Every
Every Day 9671M26P09 RQST NE Updated Every Day 3110-00-581-2719 RQST NE Updated Every Day 3110-00-581
A nonadjustable Every Day 9671M26P09 RQST NE Updated Every Day 3110-00-581-2719 RQST NE Updated Every
Cylindrical Roller Bearing 3110001010336 Roller Bearing3110001010336 001010336 463835 R1834-E-107 9671M26P08
464618 9671M26P06 9671M26P09 L43697P01 1853M96P01 A nonadjustable roller bearing consisting of a single
enable JavaScript in your web browser . 3110-01-481 https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
464618 9671M26P06 9671M26P09 L43697P01 1853M96P01 A nonadjustable roller bearing consisting of a single
enable JavaScript in your web browser . 3110-01-481 https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
464618 9671M26P06 9671M26P09 L43697P01 1853M96P01 A nonadjustable roller bearing consisting of a single
Cylindrical Roller Bearing 3110005812719 9272M55P01 AAVF9233RON-101 1538M14P01 R1834E107 5RUH1834
(Active) Primary Buy RNCC 3 RNVC 2 DAC 5 9671M26P09 07482 https//www.nsnlookup.com /fsg-83/fsc-8315/
Cylindrical Roller Bearing 3110005812719 9272M55P01 AAVF9233RON-101 1538M14P01 R1834E107 5RUH1834
(Active) Primary Buy RNCC 3 RNVC 2 DAC 5 9671M26P09 07482 https//www.nsnlookup.com /fsg-83/fsc-8315/
https//www.nsnlookup.com
/fsg-48/fsc-4810/fr
/fsg-48/fsc-4810/fr
4810-14-366-7709 Directional Control Linear Valve Slide
5990-00-683-1091Transmitter Synchro5990006831091 006831091 CG10BS10 129526 -01 CGC10BS40 129526-03 464618
Request Subscribe to View Vendor Details... 129526 https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
Cylindrical Roller Bearing 3110005812719 www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
Request Subscribe to View Vendor Details... 129526 https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
Cylindrical Roller Bearing 3110005812719 www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
5990-00-683-1091Transmitter Synchro5990006831091 006831091 CG10BS10 129526 -01 CGC10BS40 129526-03 464618
Upgrade your Account Upgrade 8315-01-643 https https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
Cylindrical Roller Bearing 3110005812719 Directional Control Linear Valve Slide 5990-00-683-1091Transmitter
Upgrade your Account Upgrade 8315-01-643 https https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-581-2719
Cylindrical Roller Bearing 3110005812719 Directional Control Linear Valve Slide 5990-00-683-1091Transmitter
Restrictions 3110-00-581-2719
IUID Required
3110-00-581-2719 is a Cylindrical Roller Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-00-581-2719
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-581-2719
- US Air Force (FXX4)
- Effective Date:
- 1 Sep 2000
- US Navy (NSXS)
- Effective Date:
- 1 Sep 2000
- Supplementary Receivers:
- GG
- Australia (ZA)
- Germany (ZG)
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH)
- Republic of Korea (ZH01)
- Effective Date:
- 1 Feb 2003
- Italy (ZR)
- Italy (ZR01)
- Effective Date:
- 1 Jun 1997
- United States of America (ZZ)
Approved Sources 3110-00-581-2719
- Part Number
- Manufacturer
- Status
- 9272M55
- Manufacturer
- 07482 - General Electric Company (Active)
- Source Control
- Source Control
- 9671M26P09
- 07482 - General Electric Company (Active)
- Primary Buy
- Primary Buy
- 9272M55P01
- 07482 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- AAVF9233RON-101
- 21335 - Timken Co (Active)
- Secondary Buy
- Secondary Buy
- 1538M14P01
- 07482 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- R1834E107
- 07482 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- 5RUH1834-7
- 78118 - Mpb Corporation (Active)
- Secondary Buy
- Secondary Buy
- 9671M26P09
- 38443 - Skf Usa Inc. (Active)
- Secondary Buy
- Secondary Buy
- 464618
- 52676 - Skf Usa Inc. (Active)
- Secondary Buy
- Secondary Buy
- 9671M26P08
- 07482 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 9671M26P09
- 52676 - Skf Usa Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3110-00-581-2719
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- End Item Identification [AGAV]
- Acft Eng Tf-39
- Bore Diameter [ABXV]
- 6.6175 Inches Minimum And 6.6179 Inches Maximum
- Bore Shape [AGZD]
- Straight
- Material [MATT]
- Steel Comp 4340 Cage
- Material [MATT]
- Steel Comp M50 Inner Ring
- Material [MATT]
- Steel Comp M50 Outer Ring
- Material [MATT]
- Steel Comp M50 Roller
- Outer Ring Width [AGVT]
- 0.8940 Inches Minimum And 0.9000 Inches Maximum
- Inner Ring Width [AGVU]
- 2.2980 Inches Minimum And 2.3020 Inches Maximum
- Internal Clearance [AKVV]
- 0.0030 Inches Minimum Radial And 0.0035 Inches Maximum Radial
- Locating Feature [AGZF]
- Nonlocating
- Overall Outside Diameter [ADGA]
- 8.4040 Inches Minimum And 8.4045 Inches Maximum
- Special Features [FEAT]
- Silver Plate Cage0.001-0.002 Thk Per Ams 2410;Outer Ring Flanged Six Places Located As Follows Tab 1,3Deg 30Min From Top Verticle Cl,Tab 2,61Deg Totop Verticle Cl,Tab 3 126Deg To Top Verticle Cl,Tab 4 183 Deg 30 Min To Top Verticle Cl,Tab 5 241 Deg To Top Verticle Cl,Tab 6 306 Deg To Top Verticle Cl;Ea Tab 1.0250 Nom Wide 1.0500 Thk W/Two Holes 0.2800 Nom 0.2870 Dia Thru 90 Deg-110 Deg Csk To Provide Mounting Capability
- Style Designator [STYL]
- Cylindrical Inner Ring, Cylindrical Outer Ring, Separable
- Surface Finish [AGYE]
- Ground
Weapon Systems (WSDC) 3110-00-581-2719
DLA Procurement Analysis 3110-00-581-2719
Management Data 3110-00-581-2719
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Dec 2019
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- R
- Refer To Aft095req
- AFT095REQ
- R
- Defense Logistics Agency (DS)
- I
- 7
- Substitute For 3110-00-101-0336
- AAA
- 7
- Defense Logistics Agency (DS)
- I
- Dod I&S Family Master Nsn - - -
- ABA
- US Coast Guard (GP)
- C
- 7
- Substitute For 3110-00-101-0336
- 7
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- NY
- GENERAL ELECTRIC ENGINES & COMPONENTS, TF-39
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 3110-00-581-2719
3110-15-058-9052 3110-15-163-4817 3110-15-056-5183 3110-14-577-3273 3110-12-308-1960 3110-15-070-2268 3110-14-519-9909 3110-15-154-5766 3110-14-256-3800 3110-27-041-5370 3110-33-189-2134 3110-12-381-3118 3110-15-110-0806 3110-15-057-7548 3110-14-347-2892 3110-14-486-2754 3110-99-950-0268 3110-12-353-1520
Freight Information 3110-00-581-2719
3110-00-581-2719 has freight characteristics managed by the General Services Administration (GSA).It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-581-2719 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-581-2719 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 3110-00-581-2719 is not classified as a special type of cargo when transported by water. 3110-00-581-2719 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 3110-00-581-2719 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
