3110-00-406-0684
Tapered Roller Bearing Cone And Rollers
3110004060684 004060684 M38545
An assembled inner component of a tapered roller bearing, consisting of a cone (which provides a contact surface for the rolling elements of the bearing), a complement of tapered rollers (the rolling elements), and frequently a retainer (which spaces the rolling elements). View more Tapered Roller Bearing Cone And Rollers
May 2023
6
Marketplace 3110-00-406-0684
Request a Quotation from participating marketplace vendors
Related Documents 3110-00-406-0684 2+ Documents (More...)
M38545 CONE AND ROLLERS,TAPERED ROLLER BEARING 2 EA NS Request Quotation Updated Every Day M38545 RQST
NE Updated Every Day 3110-00-406-0684 RQST NE Updated Every Day 3110-00-406-0684 RQST Updated Every
Restrictions 3110-00-406-0684
3110-00-406-0684 is a Tapered Roller Bearing Cone And Rollers that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-00-406-0684
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-406-0684
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
Approved Sources 3110-00-406-0684
- Part Number
- Manufacturer
- Status
- M38545
- Manufacturer
- 60038 - The Timken Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 3110-00-406-0684
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Material [MATT]
- Steel Overall
- Style Designator [STYL]
- Normal Angle
- Bore Diameter [ABXV]
- 1.3125 Inches Nominal
- Cone Corner Radius [AGWW]
- 0.1400 Inches Nominal
- Cone Width [AGWX]
- 0.8125 Inches Nominal
- Standard Tolerance Designation [CTFZ]
- Afbma Class 2
- Retainer Fabrication Method [AGYF]
- Pressed
- Special Features [FEAT]
- Duty Class M Series
Similar Supply Items to 3110-00-406-0684
Freight Information 3110-00-406-0684
3110-00-406-0684 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-406-0684 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 3110-00-406-0684 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-406-0684 is not classified as a special type of cargo when transported by water. 3110-00-406-0684 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
