3110-00-144-8942

Annular Ball Bearing

3110001448942 001448942 319 177002-49 395 6319J 6319 543401 543414 3319X1A 51-601-978-019 HR3838 95BC03 1319 319687-200 A-A59585 6319CE1TX9 319K 903319 319S 318795-8 AA59585-219JABT 700348 3319 60502P542 72-6970-294 FFB171

A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME. View more Annular Ball Bearing

Managed by United States

NSN Created on 1 Jan 1961

Data Last Changed
November 2023

NATO Update Count
43

NATO Data Quality

3110-00-144-8942 BEARING,BALL,ANNULAR 3110001448942 001448942 1/2 — 3110-00-144-8942 Photo 1/2

STYL Style 10A for 3110-00-144-8942 2/2 — NSN 3110-00-144-8942 (Identification) 2/2

Marketplace 3110-00-144-8942

Need Help?
Request a Quotation from participating marketplace vendors

Global Test Supply

395 TPI 395 Handheld Refractometer STK NE $71.95 Distributor Buy Now

Global Test Supply

319 TPI 319 Digital Pocket Thermometer, -58 to 300°F STK NE $19.73 Distributor Buy Now

Subscribe to View Vendor Details...

1319 BEARING,BALL,ANNULAR 7 EA NS

6319 BEARING,BALL,ANNULAR 72 EA NS

395 BEARING,BALL,ANNULAR 1 EA NS

319 BEARING,BALL,ANNULAR 28 EA NS

3319 BEARING,BALL,ANNULAR 40 EA NS

319-S BEARING,BALL,ANNULAR 32 EA NS

Subscribe to View Vendor Details...

FF-B171 BEARING,BALL,ANNULAR 78 EA NS

6319 BEARING,BALL,ANNULAR 4 EA NS

331-9 BEARING,BALL,ANNULAR 1 EA NS

A-A59585 BEARING,BALL,ANNULAR 19 EA NS

Subscribe to View Vendor Details...

3319GM BEARING,BALL,ANNULAR RQST NS

Subscribe to View Vendor Details...

A-A-59585 BEARING,BALL,ANNULAR 1 EA NS

Subscribe to View Vendor Details...

319 BEARING,BALL,ANNULAR 1 EA NS

Updated Every 15 Minutes

3110-00-144-8942 BUY NE

Updated Every Day

319 RQST NE

Updated Every Day

177002-49 RQST NE

3110-00-144-8942 RQST NE

Updated Every Day

3110-00-144-8942 RQST

Updated Every Day

3110-00-144-8942 RQST NE

Restrictions 3110-00-144-8942

3110-00-144-8942 is a Annular Ball Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 3110-00-144-8942

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3110-00-144-8942

US Army (A919)
Effective Date:: 1 Sep 2006
Former MOE Rule:: A180
Supplementary Receivers:: AZ; AMC 1 AMSC C IMC Z IMCACTY CD

US Coast Guard (C911)
Effective Date:: 1 Sep 2006
Former MOE Rule:: C005; AMC 1 AMSC C

US Air Force (FGGG)
Effective Date:: 1 Sep 2006
Former MOE Rule:: FGCX; AMC 1 AMSC C IMC Z IMCACTY TG

NASA (G900)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC L

US Navy (N9BG)
Effective Date:: 1 Sep 2006
Former MOE Rule:: N9GD
Supplementary Collaborators:: HD; AMC 1 AMSC C IMC Z IMCACTY GH

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Jul 1997

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

Approved Sources 3110-00-144-8942

Part Number
Manufacturer
Status
177002-49: 21335 - Timken Co (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
177002-49: 52676 - Skf Usa Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
6319: 52676 - Skf Usa Inc. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
319: 21335 - Timken Co (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC E
395: 43991 - Fag Bearings Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6319J: 52676 - Skf Usa Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6319: 72957 - Elliott Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
543401: 79500 - Westinghouse Electric Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
543414: 79500 - Westinghouse Electric Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
3319X1A: 43334 - General Motors Corp Delco Moraine (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6319: 80038 - Equitable Bearing Co Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
543401: 65054 - Westinghouse Electric Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
51-601-978-019: 25681 - Itt Goulds Pumps, Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
HR3838: 51228 - Ecolaire Inc Baldwin-Hamilton Co Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
95BC03: 70413 - Anti-Friction Bearing Mfg Assn Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
1319: 21760 - Schatz Bearing Corporation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
3319X1A: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
319687-200: 10001 - Navair And Navsea Managed Original (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
A-A59585: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
6319CE1TX9: 53035 - Nsk Corp Bearing Div (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
319K: 21335 - Timken Co (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
903319: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
319S: 38443 - Skf Usa Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
318795-8: 10001 - Navair And Navsea Managed Original (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
AA59585-219JABT: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
700348: 21450 - Army Weapons Command (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
3319: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
60502P542: 65177 - Patterson Pump Co (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
51-601-978-019: 92392 - Allis-Chalmers Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
3319: 43334 - General Motors Corp Delco Moraine (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
543414: 65054 - Westinghouse Electric Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
72-6970-294: 50024 - Coltec Industries Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
FFB171: 81348 - Federal Specifications Promulgated (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
177002-49: 10001 - Navair And Navsea Managed Original (Active); Vendor Drawing; RNCC 7 RNVC 2 DAC 1

Datasheet 3110-00-144-8942

Characteristic
Specifications
FIIG: A044A0
Bore Diameter [ABXV]: 95.00 Millimeters Nominal
Bore Shape [AGZD]: Straight
Material [MATT]: Steel Overall
Nondefinitive Spec/Std Data [ZZZT]: 111 Type And 1 Class And 00 Grade
Internal Fit-Up Designation [AGZH]: Standard
Load Direction [AGZC]: Radial
Retainer Fabrication Method [AGYF]: Pressed
Overall Outside Diameter [ADGA]: 200.00 Millimeters Nominal
Overall Width [ABMK]: 45.0 Millimeters Nominal
Standard Tolerance Designation [CTFZ]: Abec No.1
Style Designator [STYL]: Non-Loading Groove, Non-Separable
Surface Finish [AGYE]: Ground

Weapon Systems (WSDC) 3110-00-144-8942

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 3110-00-144-8942

Last Stock Position:: 3 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3110-00-144-8942

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

T: Industrial Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 3110-00-144-8942

Freight Information 3110-00-144-8942

3110-00-144-8942 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-144-8942 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-144-8942 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-144-8942 is not classified as a special type of cargo when transported by water. 3110-00-144-8942 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3110-00-144-8942

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; --

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 3110-00-144-8942 2 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE4A623PG014: 11 Mar 2023; Subscribe; 20; Subscribe; Subscribe
SPE4A516M7751P00001: 02 Aug 2016; Subscribe; 20; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 3110-00-144-8942 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: L

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: Y
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
