Premium Information is available for this item - Upgrade for $1 a day

3110-00-144-8550

Annular Ball Bearing

3110001448550 001448550 FFB171 17553-71 111SQ6A7 L55N 111A 177003-93 111S L55NTF 8027587 171B632-1 111K

A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME. View more Annular Ball Bearing

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
39

NATO Data Quality

3110-00-144-8550 BEARING,BALL,ANNULAR 3110001448550 001448550 1/3 — 3110-00-144-8550 Photo 1/3

3110-00-144-8550 BEARING,BALL,ANNULAR 3110001448550 001448550 2/3 — 3110-00-144-8550 Photo 2/3

STYL Style 10A for 3110-00-144-8550 3/3 — NSN 3110-00-144-8550 (Identification) 3/3

Marketplace 3110-00-144-8550

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

FFB171 BEARING,BALL,ANNULAR 1 EA NS

Subscribe to View Vendor Details...

1755371 BEARING,BALL,ANNULAR 60 EA NS

Subscribe to View Vendor Details...

BB-1831 BEARING,BALL,ANNULAR 162 EA NS

Subscribe to View Vendor Details...

111S BEARING,BALL,ANNULAR 15 EA NS

Subscribe to View Vendor Details...

111K BEARING,BALL,ANNULAR 10 EA NS

Subscribe to View Vendor Details...

FF-B171 BEARING,BALL,ANNULAR 78 EA NS

Subscribe to View Vendor Details...

111K BEARING,BALL,ANNULAR 487 EA NS

Subscribe to View Vendor Details...

171B632-1 BEARING,BALL,ANNULAR 1 EA NS

Subscribe to View Vendor Details...

FFB171 BEARING,BALL,ANNULAR 5 EA NS

Subscribe to View Vendor Details...

FF-B-171 BEARING,BALL,ANNULAR 15 EA NS

FFB171 BEARING,BALL,ANNULAR 26 EA NS

3110-00-144-8550 RQST NE

Updated Every Day

3110-00-144-8550 RQST

Updated Every Day

3110-00-144-8550 RQST NE

Related Documents 3110-00-144-8550 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-31/fsc-3110/us

3110-00-144-8550 Annular Ball Bearing 3110001448550 001448550

FFB171 17553-71 111SQ6A7 L55N 111A 177003-93 111S L55NTF 8027587 171B632-1 111K A cylindrical device
Quotation Updated Every Day 111SQ6A7 RQST NE Updated Every Day L55N RQST NE Updated Every Day 111S RQST
NE Updated Every Day L55NTF RQST NE Updated Every Day 111K RQST NE Updated Every Day 3110-00-144-8550

https//www.nsnlookup.com
/fsg-66/fsc-6625/it

6625-15-221-0665 Ohmdecade Resi 6625152210665 152210665

enable JavaScript in your web browser . 6625-15-221-0665Ohmdecade Resi6625152210665 152210665 ESIDB62-111K
0665 Italy (ZR) Approved Sources 6625-15-221-0665 https//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-144-8550
Annular Ball Bearing 3110001448550 001448550 111K RQST NE Updated Every Day 3110-00-144-8550 https

https//www.nsnlookup.com
/fsg-31/fsc-3110/uk

3110-99-200-1876 Annular Ball Bearing 3110992001876 992001876

JavaScript in your web browser . 3110-99-200-1876Annular Ball Bearing3110992001876 992001876 98211CN KLNJ55 L55N
Annular Ball Bearing 3110001448550 001448550 Account Upgrade 3110-00-144-8550Annular Ball Bearing3110001448550
001448550 FFB171 17553-71 111SQ6A7 L55N BEARING,BALL,ANNULAR 26 EA NS Request Quotation Updated Every

https//www.nsnlookup.com
/fsg-66/fsc-6625/uk

6625-99-529-2794 Spectrum Analy Case 6625995292794 995292794

JavaScript in your web browser . 6625-99-529-2794Spectrum Analy Case6625995292794 995292794 E54112-111K
-43-000-4895 9 Millimeter Blank Cartridge 1305430004895 -0665 Part NumberManufacturerStatusESIDB62-111K
JavaScript in your web browser . 6625-99-529-2794Spectrum Analy Case6625995292794 995292794E54112-111K

https//www.nsnlookup.com
/fsg-66/fsc-6625/us

6625-01-057-0642 Decade Resistor 6625010570642 010570642

$1 a day Upgrade your Account Upgrade 6625-01-057-0642Decade Resistor6625010570642 010570642 SP1023-111K
SP1023-111K RESISTOR,DECADE 1 EA NS Request Quotation Subscribe to View Vendor Details...
SP1023-111K RESISTOR,DECADE RQST NS Request Quotation Updated Every Day 6625-01-057-0642 RQST NE Updated

Restrictions 3110-00-144-8550

3110-00-144-8550 is a Annular Ball Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 3110-00-144-8550

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3110-00-144-8550

Poland (WP01)
Effective Date:: 1 Nov 2004

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Apr 1991

Argentina (YF01)
Effective Date:: 1 Nov 2015

Kuwait (YK01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Jul 1997

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

Approved Sources 3110-00-144-8550

Part Number
Manufacturer
Status
111SQ6A7: 38443 - Skf Usa Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
L55N: 43991 - Fag Bearings Corporation (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
111A: 92563 - Mcgill Manufacturing Co, Inc (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
177003-93: 10001 - Navair And Navsea Managed Original (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
111S: 38443 - Skf Usa Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
L55NTF: 43991 - Fag Bearings Corporation (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
FFB171: 81348 - Federal Specifications Promulgated (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 4
8027587: 19207 - U S Army Tank Automotive Command (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
171B632-1: 24446 - General Electric Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
111A: 39317 - Mcgill Manufacturing Company Inc Use (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
111K: 21335 - Timken Co (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
17553-71: 29899 - Calgon Carbon Uv Technologies Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5

Datasheet 3110-00-144-8550

Characteristic
Specifications
FIIG: A044A0
Bore Diameter [ABXV]: 55.00 Millimeters Nominal
Bore Shape [AGZD]: Straight
Departure From Cited Designator [ZZZX]: As Modified By Overall Width
Material [MATT]: Steel Overall
Nondefinitive Spec/Std Data [ZZZT]: 111 Type And 1 Class And 00 Grade
Internal Fit-Up Designation [AGZH]: Standard
Load Direction [AGZC]: Radial
Retainer Fabrication Method [AGYF]: Pressed
Overall Outside Diameter [ADGA]: 100.00 Millimeters Nominal
Overall Width [ABMK]: 12.0 Millimeters Nominal
Standard Tolerance Designation [CTFZ]: Abec No.1
Style Designator [STYL]: Non-Loading Groove, Non-Separable
Surface Finish [AGYE]: Ground

Subscribe
View Data

DLA Procurement Analysis 3110-00-144-8550

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3110-00-144-8550

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Aug 2007: Department of the Navy (DN); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Navy (DN): N; V; Discontinued W/O Replacement
Defense Logistics Agency (DS): I; V; Discontinued W/O Replacement

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 3110-00-144-8550

Freight Information 3110-00-144-8550

3110-00-144-8550 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-144-8550 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-144-8550 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-144-8550 is not classified as a special type of cargo when transported by water. 3110-00-144-8550 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3110-00-144-8550

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; 2lb or less, one dimension 2" or less, other dimensions less than 24"; Above 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Contracting Technical Data File (CTDF) 3110-00-144-8550 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: N

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
