3110-00-133-6393
Bearing Retaining Plate
3110001336393 001336393 8449975
A comparatively flat rigid item, with or without a centrally located aperture, designed to hold an annular bearing or a sleeve bearing in a fitted inclosure. It must have drilled and/or tapped holes for mounting purposes. Excludes END BELL, ELECTRICAL ROTATING EQUIPMENT. View more Bearing Retaining Plate
May 2023
3
Marketplace 3110-00-133-6393
Request a Quotation from participating marketplace vendors
Related Documents 3110-00-133-6393 3+ Documents (More...)
Every Day 3110-00-133-6393 RQST NE Related Documents 3110-00-133-6393 1+ Documents ( More... ) https
//www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-133-6393 Bearing Retaining Plate 3110001336393 Photo
Restrictions 3110-00-133-6393
3110-00-133-6393 is a Bearing Retaining Plate that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-00-133-6393
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-133-6393
- National Security Agency (DGX1)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- DCX1
- Supplementary Receivers:
- CX
Approved Sources 3110-00-133-6393
- Part Number
- Manufacturer
- Status
- 8449975
- Manufacturer
- 19204 - Army, United States Department Of (Active)
- Primary Buy
- Primary Buy
Datasheet 3110-00-133-6393
- Characteristic
- Specifications
- FIIG
- Specifications
- A093A0
- Distance From Horizontal Centerline To Center Of Right Hole [CWJN]
- 0.749 Inches Nominal
- Distance From Vertical Centerline To Center Of Right Hole [CWHW]
- 0.749 Inches Nominal
- Distance Between Holes Along Length [ADNY]
- 1.498 Inches Nominal
- Distance Between Holes Along Width [ADNZ]
- 1.498 Inches Nominal
- Material [MATT]
- Aluminum Alloy 2024 Overall
- Mounting Hole Arrangement Style [ADFU]
- Four Holes
- Mounting Hole Diameter [ABTB]
- 0.280 Inches Minimum And 0.287 Inches Maximum
- Mounting Hole Type [CWJW]
- Round, Unthreaded
- Length [ABRY]
- 2.030 Inches Nominal
- Special Features [FEAT]
- Width,2.030 In.Nom;Thickness,0.063 In.Nom;Aperture Dia,0.992 In.Min/1.008 In.Max;Mounting Configuration,Equally Spaced On 1.498 In.Centers
- Style Designator [STYL]
- Square
- Surface Treatment [SFTT]
- Anodize Overall
DLA Procurement Analysis 3110-00-133-6393
Management Data 3110-00-133-6393
Similar Supply Items to 3110-00-133-6393
Freight Information 3110-00-133-6393
3110-00-133-6393 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-133-6393 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-133-6393 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-133-6393 is not classified as a special type of cargo when transported by water. 3110-00-133-6393 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-133-6393
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Container
