3110-00-124-2374
Airframe Ball Bearing
3110001242374 001242374 MS27645-6G AS27645 KS6 AN200KS6 AS27645-6G
A cylindrical item in which the inner or outer ring turns upon row(s) of hardened BALL, BEARING which roll on a raceway, thus minimizing friction. These items are characterized by their noncorrosive qualities, lightness of weight, inch dimensions rather than metric, inner rings generally projecting beyond the faces of the outer ring, or a very narrow width inner ring having an outside diameter slightly larger than the bore diameter. Designed primarily for use in aircraft assemblies, such as control systems and surfaces of aircraft. Excludes BEARING, BALL, ANNULAR. View more Airframe Ball Bearing
November 2023
27
Marketplace 3110-00-124-2374
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3110-00-124-2374 5+ Documents (More...)
Airframe Ball Bearing 3110001242374 001242374 3110-00-124-2374 3110001242374 001242374 is a cylindrical
Airframe Ball Bearing 3110001242374 001242374 3110-00-124-2374 3110001242374 001242374 is a cylindrical
2594697-3 940.83.28.607 AN200KS3 KS3 MS27645-3G AS27645 https//www.nsnlookup.com /fsg-31/fsc-3110/us
3110-00-042-4803 Airframe Ball Bearing 3110000424803 000424803 AS27645 BEARING,BALL,AIRFRAME 340 EA
AS27645 BEARING,BALL,AIRFRAME 340 EA NS Request Quotation FedMall Updated Every 15 Minutes 3110-01-122
-3G KS3FS50160 SAE-AS27645-3G 829724 KS3FS160 2594697-3 940.83.28.607 AN200KS3 KS3 MS27645-3G AS27645
Restrictions 3110-00-124-2374
3110-00-124-2374 is a Airframe Ball Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-00-124-2374
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-124-2374
- US Air Force (FGGG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FGCX
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTKE
- Brazil (YA01)
- Effective Date:
- 1 Dec 2008
- South Africa (ZD01)
- Effective Date:
- 1 Oct 2009
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 3110-00-124-2374
- Part Number
- Manufacturer
- Status
- MS27645-6G
- Manufacturer
- 0U583 - Sae International (Active)
- Primary Buy
- Primary Buy
- AS27645
- 0U583 - Sae International (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AS27645
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- KS6
- 3NPS1 - Rbc Aircraft Products, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AN200KS6
- 88044 - Aeronautical Standards Group (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS27645-6G
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- KS6
- 21335 - Timken Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AS27645-6G
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3110-00-124-2374
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Material [MATT]
- Steel Ball
- Material [MATT]
- Steel Inner Ring
- Material [MATT]
- Steel Outer Ring
- Material [MATT]
- Steel Corrosion Resisting Shield
- Surface Treatment [SFTT]
- Cadmium All External/Exposed Metal Surfaces
- Style Designator [STYL]
- Single Row Self Aligning Single Row Inner Ring Extended Both Sides
- Bore Diameter [ABXV]
- 0.3750 Inches Nominal
- Overall Outside Diameter [ADGA]
- 1.4375 Inches Nominal
- Outer Ring Width [AGVT]
- 0.4690 Inches Nominal
- Inner Ring Width [AGVU]
- 0.6200 Inches Nominal
- Lubrication Material [ADZG]
- Grease
- Lubrication Material Document And Classification [LMDC]
- Mil-G-23827 Mil Spec Single Material Response
- Shield Quantity [AGYK]
- 2
- Alignment Type [AGZA]
- Self-Aligning
- Self-Alignment Location [AHAW]
- Internal
- Load Direction [AGZC]
- Radial
Weapon Systems (WSDC) 3110-00-124-2374
DLA Procurement Analysis 3110-00-124-2374
- Last Stock Position:
- 31 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3110-00-124-2374
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 3110-00-124-2374
Freight Information 3110-00-124-2374
3110-00-124-2374 has freight characteristics managed by Germany.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-124-2374 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 3110-00-124-2374 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-124-2374 is not classified as a special type of cargo when transported by water. 3110-00-124-2374 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-124-2374
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- No Requirement
- Not Applicable
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 3110-00-124-2374 1 Records
Contracting Technical Data File (CTDF) 3110-00-124-2374 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
