3110-00-103-5636
Annular Ball Bearing
3110001035636 001035636 6205Z/C3/HA 7505LR1C8 5012-T2-1
A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME. View more Annular Ball Bearing
May 2023
5
Marketplace 3110-00-103-5636
Request a Quotation from participating marketplace vendors
Related Documents 3110-00-103-5636 5+ Documents (More...)
Photo 1/2 NSN 3110-00-103-5636 (Identification) 2/2 - - 1.
BUY NE FedMall Updated Every Day 7505LR1C8 RQST NE Updated Every Day 3110-00-103-5636 RQST NE Updated
Annular Ball Bearing 3110001035636 001035636 $1 a day Upgrade your Account Upgrade 3110-00-103-
5636Annular Ball Bearing3110001035636 001035636 6205Z www.nsnlookup.com /fsg-31/fsc-3110/us 3110-00-103
Annular Ball Bearing 3110001035636 001035636 day Upgrade your Account Upgrade 3110-00-103-5636Annular
Ball Bearing3110001035636 001035636 6205Z/C3/HA Restrictions Approved Sources Datasheet Management https
Restrictions 3110-00-103-5636
3110-00-103-5636 is a Annular Ball Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3110-00-103-5636
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-103-5636
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
Approved Sources 3110-00-103-5636
- Part Number
- Manufacturer
- Status
- 6205Z/C3/HA
- Manufacturer
- 52676 - Skf Usa Inc. (Active)
- Primary Buy
- Primary Buy
- 7505LR1C8
- 43334 - General Motors Corp Delco Moraine (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5012-T2-1
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3110-00-103-5636
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Material [MATT]
- Steel Overall
- Style Designator [STYL]
- Non-Loading Groove, Non-Separable
- Overall Width [ABMK]
- 15.0 Millimeters Nominal
- Bore Diameter [ABXV]
- 25.0 Millimeters Nominal
- Overall Outside Diameter [ADGA]
- 52.0 Millimeters Nominal
- Lubrication Material [ADZG]
- Grease
- Lubrication Material Document And Classification [LMDC]
- Andok C,Fscm 29700 Mfr Ref Single Material Response
- Standard Tolerance Designation [CTFZ]
- Abec No.1
- Bore Shape [AGZD]
- Straight
- Surface Finish [AGYE]
- Ground
- Retainer Fabrication Method [AGYF]
- Pressed
- Shield Quantity [AGYK]
- 1
- Load Direction [AGZC]
- Radial
- Internal Fit-Up Designation [AGZH]
- Loose
- Special Features [FEAT]
- 50 To 75 Pct Full Specified Lubricant
Weapon Systems (WSDC) 3110-00-103-5636
DLA Procurement Analysis 3110-00-103-5636
Management Data 3110-00-103-5636
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3110-00-103-5636
Freight Information 3110-00-103-5636
3110-00-103-5636 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-103-5636 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-103-5636 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-103-5636 is not classified as a special type of cargo when transported by water. 3110-00-103-5636 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-103-5636
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 3110-00-103-5636 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
